GXT 4.0.3 Load subtrees on expand, using custom loading logic.

TreeWithSimulatedLoadingExample.java

import java.io.Serializable;
import java.util.ArrayList;
import java.util.HashSet;
import java.util.List;
import java.util.Set;

import com.google.gwt.core.client.EntryPoint;
import com.google.gwt.core.client.GWT;
import com.google.gwt.core.client.Scheduler;
import com.google.gwt.core.client.Scheduler.ScheduledCommand;
import com.google.gwt.event.logical.shared.SelectionEvent;
import com.google.gwt.event.logical.shared.SelectionHandler;
import com.google.gwt.event.logical.shared.ValueChangeEvent;
import com.google.gwt.event.logical.shared.ValueChangeHandler;
import com.google.gwt.resources.client.ImageResource;
import com.google.gwt.user.client.Timer;
import com.google.gwt.user.client.ui.RootPanel;
import com.google.gwt.user.client.ui.Widget;
import com.sencha.gxt.core.client.IdentityValueProvider;
import com.sencha.gxt.core.client.ValueProvider;
import com.sencha.gxt.data.shared.ModelKeyProvider;
import com.sencha.gxt.data.shared.Store;
import com.sencha.gxt.data.shared.TreeStore;
import com.sencha.gxt.data.shared.loader.FilterConfig;
import com.sencha.gxt.widget.core.client.button.ButtonBar;
import com.sencha.gxt.widget.core.client.container.FlowLayoutContainer;
import com.sencha.gxt.widget.core.client.container.Viewport;
import com.sencha.gxt.widget.core.client.event.ExpandItemEvent;
import com.sencha.gxt.widget.core.client.event.ExpandItemEvent.ExpandItemHandler;
import com.sencha.gxt.widget.core.client.event.TriggerClickEvent;
import com.sencha.gxt.widget.core.client.event.TriggerClickEvent.TriggerClickHandler;
import com.sencha.gxt.widget.core.client.form.StoreFilterField;
import com.sencha.gxt.widget.core.client.tree.Tree;
import com.sencha.gxt.widget.core.client.tree.Tree.TreeNode;
import com.sencha.gxt.widget.core.client.tree.TreeView;

public class TreeWithSimulatedLoadingExample implements EntryPoint {

  // ---- add loading to tree grid
  public class TreeViewExt<M> extends TreeView<M> {
    /**
     * Display the loading icon
     */
    // ------ Turn on/off loading
    public void setLoading(M m, boolean turnon) {
      TreeNode<M> node = findNode(m);
      if (turnon) {
        onIconStyleChange(node, treeExt.getAppearance().loadingIcon());
      } else {
        // ----- Added a cast for TreeGrid method
        onIconStyleChange(node, treeExt.calculateIconStyle((Data) m));
      }
    }
  }

  public class TreeExt<M, C> extends Tree<M, C> {

    public TreeExt(TreeStore<M> store, ValueProvider<? super M, C> valueProvider) {
      super(store, valueProvider);
    }

    // ----- Change visibility to public
    @Override
    public ImageResource calculateIconStyle(M model) {
      return super.calculateIconStyle(model);
    }
  }

  /**
   * Mark which parents have been loaded. This will determine if the data has already been loaded.
   */
  private Set<Data> hasBeenLoadedList = new HashSet<Data>();

  private TreeStore<Data> treeStore;
  private TreeExt<Data, Data> treeExt;
  private TreeViewExt<Data> treeView;
  private KeyProvider keyProvider;
  private FlowLayoutContainer flowContainer;

  public Widget asWidget() {
    if (flowContainer == null) {
      keyProvider = new KeyProvider();
      treeStore = new TreeStore<Data>(keyProvider);

      final StoreFilterField<Data> filterField = new StoreFilterField<Data>() {
        @Override
        protected boolean doSelect(Store<Data> store, Data parent, Data item, String filter) {
          GWT.log("filter=" + filter.toLowerCase() + " name=" + item.getName().toLowerCase());
          return item.getName().toLowerCase().contains(filter);
        }
      };
      filterField.bind(treeStore);
      filterField.addTriggerClickHandler(new TriggerClickHandler() {
        @Override
        public void onTriggerClick(TriggerClickEvent event) {
          GWT.log("trigger click");
          // ~~~ workaround
          treeExt.getTreeStore().setEnableFilters(false);
        }
      });
      filterField.addValueChangeHandler(new ValueChangeHandler<Data>() {
        @Override
        public void onValueChange(ValueChangeEvent<Data> event) {
          GWT.log("value change");
        }
      });

      treeView = new TreeViewExt<Data>();

      // identity value provider to pass the model to the cell renderer
      treeExt = new TreeExt<Data, Data>(treeStore, new IdentityValueProvider<Data>("name")) {

        @Override
        protected boolean hasChildren(Data model) {
          // 2. ~~~~~~~ Determine if the node has children, and if so, means its a
          // folder with children
          // Note: this could be a boolean value to signify the node is a folder
          // with children
          return model.getChildCount() > 0;
        }
      };
      treeExt.setView(treeView);
      treeExt.setWidth(300);
      treeExt.setBorders(true);
      treeExt.setExpandOnFilter(false);

      treeExt.addExpandHandler(new ExpandItemHandler<Data>() {
        @Override
        public void onExpand(ExpandItemEvent<Data> event) {
          // ~~~~~~ 3. load more children on expansion
          Data parent = event.getItem();
          rpcRequestToGetChildNodes(parent);
        }
      });

      // ~~~~ single selection handler -----
      treeExt.getSelectionModel().addSelectionHandler(new SelectionHandler<Data>() {
        @Override
        public void onSelection(SelectionEvent<Data> event) {
          Data item = event.getSelectedItem();

          GWT.log("\t item selected name=" + item.getName());
        }
      });

      ButtonBar buttonBar = new ButtonBar();
      buttonBar.add(filterField);

      flowContainer = new FlowLayoutContainer();
      flowContainer.add(buttonBar);
      flowContainer.add(treeExt);

      // ~~~~~ 1. initial load - load the root nodes
      rpcRequestToGetRootNodes();
    }

    return flowContainer;
  }

  @Override
  public void onModuleLoad() {
    Viewport viewport = new Viewport();
    viewport.add(asWidget());
    RootPanel.get().add(viewport);
  }

  /**
   * Suggestion: Go fetch all the nodes form the server that match the server, include their parents and on return add
   * them to the tree store.
   */
  protected void rpcRequestToGetFilteredNodes(List<FilterConfig> filterConfig) {
    FilterConfig filter = filterConfig.get(0);
    String filterValue = filter.getValue();
    System.out.println("filterValue=" + filterValue);
  }

  /**
   * Pretend RPC call to get data from server
   */
  private void rpcRequestToGetRootNodes() {
    // Pretend this is an RPC call for initial load.
    Scheduler.get().scheduleDeferred(new ScheduledCommand() {
      @Override
      public void execute() {
        // RPC call to get root nodes
        List<Data> rootNodes = getRpcRequestWithDatas(null);
        // On RPC return add to treestore
        treeStore.add(rootNodes);
      }
    });
  }

  /**
   * Pretend RPC call to get data server and add it to treestore.
   *
   * Note: this won't replace child if it's already loaded.
   *
   * @param parent
   */
  private void rpcRequestToGetChildNodes(final Data parent) {
    if (hasBeenLoadedList.contains(parent)) {
      // only load the data once
      System.out.println("Skipping loading data for parent=" + parent);
      return;
    }

    // display the loading icon
    // ---- Turn on loading
    treeView.setLoading(parent, true);

    // Pretend this is an RPC call for initial load.
    Timer timerLikeRpc = new Timer() {
      @Override
      public void run() {
        // ---- Turn off loading
        treeView.setLoading(parent, false);

        // RPC call to get root nodes
        List<Data> childNodes = getRpcRequestWithDatas(parent);
        // On RPC return, add the nodes to the treestore
        // Since expanding can happen more than once, check to see if the node
        // exists already
        for (Data child : childNodes) {
          // check to see if the model has been already been loaded
          // (TODO if node changes to different branch, then it needs to removed and added)
          Data dataExists = treeStore.findModelWithKey(keyProvider.getKey(child));
          if (dataExists == null) {
            treeStore.add(parent, child);
            hasBeenLoadedList.add(parent);
          }
        }
      }
    };
    timerLikeRpc.schedule(1000);
  }

  /**
   * Server request goes to this
   */
  private List<Data> getRpcRequestWithDatas(Data parent) {
    List<Data> list = new ArrayList<Data>();

    if (parent == null) {
      Data a = new Data("0", "A", 0);
      a.setChildCount(5);

      Data b = new Data("1", "B", 1);
      b.setChildCount(4);

      Data c = new Data("2", "C", 2);
      c.setChildCount(3);

      list.add(a);
      list.add(b);
      list.add(c);

    } else {
      String k = parent.getName();

      int c = 0;
      if (k.contains("A")) {
        c = 5;
      } else if (k.contains("B")) {
        c = 4;
      } else {
        c = 3;
      }

      for (int i = 0; i < c; i++) {
        String id = parent.getId() + " : " + i;

        Data d = new Data(id, k + "+" + i, 3);
        d.setChildCount(0);
        list.add(d);

        System.out.println("id=" + id + " name=" + d.getName());

        // first child has some children
        if (i == 0 && d.getName().equals("A+0")) {
          d.setChildCount(5);
        }
      }
    }

    return list;
  }

  class KeyProvider implements ModelKeyProvider<Data> {
    @Override
    public String getKey(Data item) {
      return item.getId().toString();
    }
  }

  public class Data implements Serializable {
    private String id;
    private String name;
    private int value;
    /**
     * Record if this is a folder node and it has children it could load This could be a boolean value too. See
     * TreeGrid.hasChildren.
     */
    private int childCount;

    protected Data() {
    }

    public Data(String id, String name, int value) {
      this.id = id;
      this.name = name;
      this.value = value;
    }

    public String getId() {
      return id;
    }

    public void setId(String id) {
      this.id = id;
    }

    public String getName() {
      return name;
    }

    public void setName(String name) {
      this.name = name;
    }

    public int getValue() {
      return value;
    }

    public void setId(int value) {
      this.value = value;
    }

    @Override
    public String toString() {
      return name;
    }

    public void setChildCount(int childCount) {
      this.childCount = childCount;
    }

    public int getChildCount() {
      return childCount;
    }

  }

}
