Using Charts in your Express app with ChartJS

You can find the sample working code here

Installation

1. Set up ChartJS

For simplicity we'll just use CDN links to set up chartjs in your project. You can also read the docs here

Add this your respective .hbs file or the layout.hbs file in the <head> tag.

<script  src="https://cdnjs.cloudflare.com/ajax/libs/Chart.js/3.1.1/chart.min.js"  integrity_no="sha512-BqNYFBAzGfZDnIWSAEGZSD/QFKeVxms2dIBPfw11gZubWwKUjEgmFUtUls8vZ6xTRZN/jaXGHD/ZaxD9+fDo0A=="  crossorigin="anonymous"></script>

2. Add the Chart to your `hbs` file

Wherever you want to show the chart to the user , create a `<canvas>`

<canvas  id="myChart"  width="400"  height="400"></canvas>

We've used myChartas the id attribute of the element, but the name is not important, you can choose any sensible id value

3. Create a route that renders that particular hbs file with `canvas`

While passing variables to your hbs file ensure you JSON.stringify the variables you want the chart to use

//ROUTE TO SHOW BAR CHART

app.get("/", (req, res, next) => {
	// Assume we get some data from our DB
	let chartData = [12, 19, 3, 5, 2, 3]
	let chartLabels = ['Red', 'Blue', 'Yellow', 'Green', 'Purple', 'Orange']

	// Sending some data to the hbs page
	// since our data will be used in JS script in the hbs we will stringify it
	// this will ensure that we can use the data with the same encoding in the hbs page

	res.render("barChart.hbs", {
		chartData: JSON.stringify(chartData),
		chartLabels: JSON.stringify(chartLabels)
	});
});

In your hbs file you can access the chartData and chartLabels variable in the script tag this way

<script>
	console.log( {{{chartData}}} ) // prints [12, 19, 3, 5, 2, 3]
	console.log( {{{chartLabels}}} ) //prints ['Red', 'Blue', 'Yellow', 'Green', 'Purple', 'Orange']
</script>

to access any variable passed from handlebars we need to use the quotes and three curly opening/closing brackets

"{{{ VARIABLE }}}"

Add this script tag in the same `hbs` file where the `canvas` was added so that it loads the chart

<script>
	const ctx = document.getElementById('myChart').getContext('2d');

	// The value of 'charLabels' we get from our routes is ["Red", "Blue", "Yellow", "Green", "Purple", "Orange"]

	// the value of 'chartData' we get is [12,19,3,5,2,3]

	const myChart = new Chart(ctx, {
		type: 'bar',
		data: {
			labels: {{{chartLabels}}},
			datasets: [{
				label: '# of Votes',
				data: {{{chartData}}},
				backgroundColor: [
					'rgba(255, 99, 132, 0.2)',
					'rgba(54, 162, 235, 0.2)',
					'rgba(255, 206, 86, 0.2)',
					'rgba(75, 192, 192, 0.2)',
					'rgba(153, 102, 255, 0.2)',
					'rgba(255, 159, 64, 0.2)'
				],
				borderColor: [
					'rgba(255, 99, 132, 1)',
					'rgba(54, 162, 235, 1)',
					'rgba(255, 206, 86, 1)',
					'rgba(75, 192, 192, 1)',
					'rgba(153, 102, 255, 1)',
					'rgba(255, 159, 64, 1)'
				],
				borderWidth: 1
			}]
		},
		options: {
			scales: {
				y: {
					beginAtZero: true
				}
			}
		}
	});
</script>

The above code can also be found in the docs here

Your page should now look like this (except the nav elements)
