我們準備了兩個句子來進行這次實驗
sentences = ['helo attention','have a nice day']一開始先建立詞表與對應的單詞one-hot encoding
vocabs = ' '.join(sentences).split()
vocabs = list(set(vocabs))
one_hots = []
vocab_dict = {}
for i,vocab in enumerate(vocabs):
one_hots.append([0]*len(vocabs))
one_hots[i][i]=1
for i,(vocab,one_hot) in enumerate(zip(vocabs,one_hots)):
vocab_dict[vocab] = one_hot
print(vocab_dict){'nice': [1, 0, 0, 0, 0, 0], 'a': [0, 1, 0, 0, 0, 0], 'attention': [0, 0, 1, 0, 0, 0], 'helo': [0, 0, 0, 1, 0, 0], 'day': [0, 0, 0, 0, 1, 0], 'have': [0, 0, 0, 0, 0, 1]}
接著將兩個句子都轉換成one-hot encodeing，並且組成batch
# batch
batch_features = []
for sentence in sentences:
sentence_features = []
sentence_words = sentence.split()
for word in sentence_words:
word_embedding = vocab_dict[word]
sentence_features.append(word_embedding)
batch_features.append(sentence_features)
print(batch_features) # [['helo', 'attention'], ['have', 'a', 'nice', 'day']][[[0, 0, 0, 1, 0, 0], [0, 0, 1, 0, 0, 0]], [[0, 0, 0, 0, 0, 1], [0, 1, 0, 0, 0, 0], [1, 0, 0, 0, 0, 0], [0, 0, 0, 0, 1, 0]]]
batch需要對齊長度，將兩句輸入補齊到指定長度，並且轉換成tensor
# batch_pad
pad_to_length = 5
pad_embedding = [0]*len(vocabs) # [0,0,0,0,0,0]用作pad
for i,batch_feature in enumerate(batch_features):
while len(batch_feature) < pad_to_length:
batch_feature.append(pad_embedding)
inputs = torch.LongTensor(batch_features)
inputs.shapetorch.Size([2, 5, 6]) # batch,len,vocab_size
pytorch 內建的 nn.embeddings 是一個更快速的方法，可省略 one-hot encoding 步驟 https://pytorch.org/docs/stable/generated/torch.nn.Embedding.html
輸入包含補齊部分，等等運算的時候要忽略掉, 我們使用attention mask來做這件事情
"""
1 = 計算, 0 = 忽略
"""
attention_mask = []
for i,batch_feature in enumerate(batch_features):
_attention_mask = []
for one_hot in batch_feature:
if 1 in one_hot: # not pad feature
_attention_mask.append(1)
else: # pad feature
_attention_mask.append(0)
attention_mask.append(_attention_mask)
attention_mask = torch.LongTensor(attention_mask)
print(attention_mask)
attention_mask.shapetensor([[1, 1, 0, 0, 0],
[1, 1, 1, 1, 0]])
torch.Size([2, 5])
複習一下Attention公式
在 Self Attention 中，Q = K = V = sentence inputs,
d = Q 或 K 的維度，在這邊的作用是 scaling factor 避免 softmax 出來的值太過極端
class Atten(nn.Module):
def __init__(self):
super(Atten, self).__init__()
self.word_embeddings = nn.Linear(len(vocabs),4) # word embedding size for 4
self.d = 3 # embedding size 3 for q,k,v
self.q_w = nn.Linear(4,self.d)
self.k_w = nn.Linear(4,self.d)
self.v_w = nn.Linear(4,self.d)
def forward(self,x,attention_mask):
x = x.to(torch.float)
x = self.word_embeddings(x)
Q = self.q_w(x)
K = self.k_w(x)
V = self.v_w(x)
score = torch.matmul(Q,torch.transpose(K,1,2)) # batch_dot Q*K^trnas
score = score/math.sqrt(self.d)
print('Q*K before apply attention_mask\n',score)
attention_mask = attention_mask
attention_mask = attention_mask.unsqueeze(1).repeat(1,score.shape[1],1)
score = score*attention_mask # apply mask to score
print('Q*K after apply attention_mask\n',score)
score = score - torch.where(attention_mask > 0, torch.zeros_like(score), torch.ones_like(score) * float('inf')) # apply mask to softmax for thoese value is `0`
print('Q*K prepare for mask_softmax\n',score)
softmax = torch.nn.Softmax(dim=-1)
atten_prob = softmax(score)
print('Atten prob\n',atten_prob)
atten_score = torch.matmul(atten_prob,V)
print('Atten score\n',atten_score)
return {'atten_prob':atten_prob,'atten_score':atten_score}
model = Atten()
model(inputs,attention_mask)
print()Q*K before apply attention_mask
tensor([[[0.1090, 0.0262, 0.0775, 0.0775, 0.0775],
[0.0262, 0.0134, 0.0157, 0.0157, 0.0157],
[0.0775, 0.0157, 0.0803, 0.0803, 0.0803],
[0.0775, 0.0157, 0.0803, 0.0803, 0.0803],
[0.0775, 0.0157, 0.0803, 0.0803, 0.0803]],
[[0.2416, 0.2227, 0.0997, 0.1460, 0.1368],
[0.2227, 0.2057, 0.0888, 0.1347, 0.1253],
[0.0997, 0.0888, 0.0755, 0.0704, 0.0661],
[0.1460, 0.1347, 0.0704, 0.0953, 0.0861],
[0.1368, 0.1253, 0.0661, 0.0861, 0.0803]]], grad_fn=<DivBackward0>)
Q*K after apply attention_mask
tensor([[[0.1090, 0.0262, 0.0000, 0.0000, 0.0000],
[0.0262, 0.0134, 0.0000, 0.0000, 0.0000],
[0.0775, 0.0157, 0.0000, 0.0000, 0.0000],
[0.0775, 0.0157, 0.0000, 0.0000, 0.0000],
[0.0775, 0.0157, 0.0000, 0.0000, 0.0000]],
[[0.2416, 0.2227, 0.0997, 0.1460, 0.0000],
[0.2227, 0.2057, 0.0888, 0.1347, 0.0000],
[0.0997, 0.0888, 0.0755, 0.0704, 0.0000],
[0.1460, 0.1347, 0.0704, 0.0953, 0.0000],
[0.1368, 0.1253, 0.0661, 0.0861, 0.0000]]], grad_fn=<MulBackward0>)
Q*K prepare for mask_softmax
tensor([[[0.1090, 0.0262, -inf, -inf, -inf],
[0.0262, 0.0134, -inf, -inf, -inf],
[0.0775, 0.0157, -inf, -inf, -inf],
[0.0775, 0.0157, -inf, -inf, -inf],
[0.0775, 0.0157, -inf, -inf, -inf]],
[[0.2416, 0.2227, 0.0997, 0.1460, -inf],
[0.2227, 0.2057, 0.0888, 0.1347, -inf],
[0.0997, 0.0888, 0.0755, 0.0704, -inf],
[0.1460, 0.1347, 0.0704, 0.0953, -inf],
[0.1368, 0.1253, 0.0661, 0.0861, -inf]]], grad_fn=<SubBackward0>)
Atten prob
tensor([[[0.5207, 0.4793, 0.0000, 0.0000, 0.0000],
[0.5032, 0.4968, 0.0000, 0.0000, 0.0000],
[0.5155, 0.4845, 0.0000, 0.0000, 0.0000],
[0.5155, 0.4845, 0.0000, 0.0000, 0.0000],
[0.5155, 0.4845, 0.0000, 0.0000, 0.0000]],
[[0.2661, 0.2611, 0.2309, 0.2419, 0.0000],
[0.2650, 0.2605, 0.2318, 0.2427, 0.0000],
[0.2540, 0.2513, 0.2480, 0.2467, 0.0000],
[0.2586, 0.2557, 0.2398, 0.2458, 0.0000],
[0.2583, 0.2554, 0.2407, 0.2456, 0.0000]]], grad_fn=<SoftmaxBackward>)
Atten score
tensor([[[ 0.1579, 0.1980, -0.3929],
[ 0.1545, 0.1949, -0.3978],
[ 0.1569, 0.1970, -0.3944],
[ 0.1569, 0.1970, -0.3944],
[ 0.1569, 0.1970, -0.3944]],
[[ 0.2930, 0.1643, -0.3598],
[ 0.2927, 0.1644, -0.3600],
[ 0.2885, 0.1652, -0.3633],
[ 0.2905, 0.1648, -0.3617],
[ 0.2903, 0.1649, -0.3619]]], grad_fn=<UnsafeViewBackward>)
上面向量的row與col都是同一句，可以這樣理解他們的數值關係
have a nice day [PAD]
have 0.2661, 0.2611, 0.2309, 0.2419, 0.0000
a 0.2650, 0.2605, 0.2318, 0.2427, 0.0000
nice 0.2540, 0.2513, 0.2480, 0.2467, 0.0000
day 0.2586, 0.2557, 0.2398, 0.2458, 0.0000
[PAD] 0.2583, 0.2554, 0.2407, 0.2456, 0.0000
row部分可以看到我們使用 attention mask 遮蔽掉 [PAD] 部分，不參與 softmax 計算,
但是col的[PAD]還是會因為平行計算的關係與其他 token 進行運算
用colab玩一下吧 https://colab.research.google.com/drive/1g9G23KZGkZFpRGTLIaTkVHaMORN60-bq?usp=sharing
