bicubic_testing.nim

import ggplotnim, numericalnim, arraymancer, sequtils
import nimpyArraymancer


proc genRand(): Tensor[float] =
  result = randomTensor([10, 10], 75).asType(float)
          # [[43.0, 10.0],
          #  [22.0, 75.0]].toTensor()

proc grad(tIn: Tensor[float], xdiff: float = 1.0): Tensor[float] =
  let t = tIn.squeeze
  doAssert t.rank == 1, " no was " & $t
  result = newTensor[float](t.size.int)
  var
    yMinus, yPlus: float
    mxdiff = xdiff
  for i in 0 ..< t.size:
    if i == 0:
      yMinus = t[0]
      yPlus = t[1]
      mxdiff = xdiff
    elif i == t.size - 1:
      yMinus = t[i - 1]
      yPlus = t[i]
      mxdiff = xdiff
    else:
      yMinus = t[i - 1]
      yPlus = t[i + 1]
      mxdiff = xdiff * 2
    result[i] = (yPlus - 2 * t[i] + yMinus) / (mxdiff * mxdiff)

proc grad(t: Tensor[float], axis: int): Tensor[float] =
  ## given 2D tensor, calc gradient in axis direction
  result = newTensor[float](t.shape)
  for idx, ax in enumerateAxis(t, axis):
    ## TODO: eh, how to do this in one?
    case axis
    of 0: result[idx, _] = grad(ax, 1.0).unsqueeze(0)
    of 1: result[_, idx] = grad(ax, 1.0).unsqueeze(1)
    else: doAssert false

proc computeAlpha(f: Tensor[float]): Tensor[float] =
  var m1 = [[1, 0, 0, 0],
            [0, 0, 1, 0],
            [-3, 3, -2, -1],
            [2, -2, 1, 1]].toTensor.asType(float)
  var m2 = [[1, 0, -3, 2],
            [0, 0, 3, -2],
            [0, 1, -2, 1],
            [0, 0, -1, 1]].toTensor.asType(float)
  let fx = grad(f, 0)
  let fy = grad(f, 1)
  let fxy = grad(grad(f, 0), 1)
  var A = [[f[0, 0],  f[0, 1],  fy[0, 0],  fy[0, 1]],
           [f[1, 0],  f[1, 1],  fy[1, 0],  fy[1, 1]],
           [fx[0, 0], fx[0, 1], fxy[0, 0], fxy[0, 1]],
           [fx[1, 0], fx[1, 1], fxy[1, 0], fxy[1, 1]]].toTensor().asType(float)
  result = m1 * A * m2

proc computeAlpha(f: Tensor[float], fx, fy, fxy: Tensor[float],
                  x, y: int): Tensor[float] =
  var m1 = [[1, 0, 0, 0],
            [0, 0, 1, 0],
            [-3, 3, -2, -1],
            [2, -2, 1, 1]].toTensor.asType(float)
  var m2 = [[1, 0, -3, 2],
            [0, 0, 3, -2],
            [0, 1, -2, 1],
            [0, 0, -1, 1]].toTensor.asType(float)
  var A = [[f[x, y],  f[x, y + 1],  fy[x, y],  fy[x, y+1]],
           [f[x + 1, y],  f[x + 1, y + 1],  fy[x+1, y],  fy[x+1, y+1]],
           [fx[x, y], fx[x, y+1], fxy[x, y], fxy[x, y+1]],
           [fx[x+1, y], fx[x+1, y+1], fxy[x+1, y], fxy[x+1, y+1]]].toTensor().asType(float)
  result = m1 * A * m2

proc bicubic(t: Tensor[float], size: int): Tensor[float] =
  result = newTensor[float]([size, size])
  let blockSizeX = size.float / t.shape[0].float
  let blockSizeY = size.float / t.shape[1].float
  let fx = grad(t, 0)
  let fy = grad(t, 1)
  let fxy = grad(grad(t, 0), 1)
  var
    tX: int
    tY: int
    alpha = t.computeAlpha(fx, fy, fxy, 0, 0)
  for y in 0 ..< size:
    tY = (y.float / blockSizeY).floor.int
    for x in 0 ..< size:
      if tX != (x.float / blockSizeX).floor.int:
        tX = (x.float / blockSizeX).floor.int
        alpha = t.computeAlpha(fx, fy, fxy, tX, tY)
      let xIn = (x mod blockSizeX.int).float / blockSizeX.float
      let yIn = (y mod blockSizeY.int).float / blockSizeY.float
      result[x, y] = dot([1.0, xIn, xIn*xIn, xIn*xIn*xIn].toTensor,
                         alpha * [1.0, yIn, yIn*yIn, yIn*yIn*yIn].toTensor)


proc splitXYZ(t: Tensor[float]): (Tensor[float], Tensor[float], Tensor[float]) =
  var
    x = newTensor[float](t.size.int)
    y = newTensor[float](t.size.int)
    z = newTensor[float](t.size.int)
  var i = 0
  for idx, val in t:
    x[i] = idx[0].float
    y[i] = idx[1].float
    z[i] = val.float
    inc i
  result = (x, y, z)

proc plot(t: Tensor[float], name: string) =
  let (x, y, z) = t.splitXYZ()
  let df = seqsToDf(x, y, z)
  ggplot(df, aes("x", "y", fill = "z")) +
    geom_raster() +
    scale_x_continuous() + scale_y_continuous() +
    scale_fill_continuous(scale = (low: 0.0, high: 70.0)) +
    xlim(0, t.shape[0] + 1) + ylim(0, t.shape[1] + 1) +
    ggsave(name & ".pdf", width = 900, height = 800)


let t = genRand()
echo t
echo grad(grad(t, 0), 1)
const Size = 1000
echo "bicubic calc:"
let res = bicubic(t, Size)
plot(res, "test_cubic")
echo "plot input"
plot(t, "test_input")


echo "calc scipy"
import nimpy
# create scipy interpolation for comparison:
let scipy = pyImport("scipy.interpolate")

let (x, y, z) = t.splitXYZ()
let sciInterp = scipy.interp2d(x.toRawSeq, y.toRawSeq, z.toRawSeq, "cubic")
let (xNew, yNew, _) = newTensor[float]([Size, Size]).splitXYZ()
let sciRes = callMethod(sciInterp, "__call__", linspace(0, 9, 1000).toRawSeq, linspace(0, 9, 1000).toRawSeq)

let np = pyImport("numpy")
let sb = newSafePyBuffer(np.ascontiguousarray(sciRes))
let sciT = toTensor[float](sb)
echo "plot scipy"
plot(sciT, "test_scipy_compare")

nimpyArraymancer.nim

import arraymancer,
       nimpy,
       nimpy / [raw_buffers, py_types]

type
  SafePyBuffer* = ref SafePyBufferObj
  SafePyBufferObj = object
    pyBuf*: RawPyBuffer
    shape*: seq[int]

when defined(gcDestructors):
  proc `=destroy`(s: var SafePyBufferObj) =
    if not s.pyBuf.buf.isNil:
      s.pyBuf.release()
else:
  proc finalizer(s: SafePyBuffer) =
    if not s.isNil and not s.pyBuf.buf.isNil:
      s.pyBuf.release()

proc newSafePyBuffer*(a: PyObject): SafePyBuffer =
  when defined(gcDestructors):
    new(result)
  else:
    new(result, finalizer)
  var buf: RawPyBuffer
  getBuffer(a, buf, PyBUF_WRITABLE or PyBUF_ND)
  let shapeArray = cast[ptr UncheckedArray[Py_ssize_t]](buf.shape)
  result.shape = newSeq[int](buf.ndim)
  for i in 0 ..< buf.ndim:
    result.shape[i] = shapeArray[i].int # py_ssize_t is csize
  result.pyBuf = buf

proc toTensor*[T](s: SafePyBuffer): Tensor[T] =
  result = fromBuffer[T](s.pyBuf.buf, s.shape)

Input:

Scipy:

Ours:
