oauth2.md

OAuth2

INTRODUCTION

CLIENT-SERVER 모델에서는 외부 application 이 서버의 제한된 리소스에 접근하려고 할때에 몇가지 문제가 있습니다.

• 사용자의 password 가 application 에 노출됩니다.(clear-text 로)
• application 은 사용자의 모든 권한을 얻게 됩니다.
• 특정 application 의 접근 권한을 취소 할 수 없습니다.
• 비밀번호 변경 시 모든 application 에서 비밀번호를 바꿔주어야 합니다.

TERMINOLOGY

• Resource Owner
• Resource Server
• Client
• Authorization Server

• UserAgent
• code
• access_token
• Authentication
• Authorization
• scope

OVERVIEW

 +--------+                               +---------------+
 |        |--(A)- Authorization Request ->|   Resource    |
 |        |                               |     Owner     |
 |        |<-(B)-- Authorization Grant ---|               |
 |        |                               +---------------+
 |        |
 |        |                               +---------------+
 |        |--(C)-- Authorization Grant -->| Authorization |
 | Client |                               |     Server    |
 |        |<-(D)----- Access Token -------|               |
 |        |                               +---------------+
 |        |
 |        |                               +---------------+
 |        |--(E)----- Access Token ------>|    Resource   |
 |        |                               |     Server    |
 |        |<-(F)--- Protected Resource ---|               |
 +--------+                               +---------------+

PROTOCOL END-POINT

• Authorization Endpoint
• Token Endpoint

AUTHORIZATION GRANT

• Authorization Code
• Implicit
• Resource Owner Password Credentials
• Client Credentials

AUTHORIZATION CODE GRANT

 +----------+
 | Resource |
 |   Owner  |
 |          |
 +----------+
      ^
      |
     (B)
 +----|-----+          Client Identifier      +---------------+
 |         -+----(A)-- & Redirection URI ---->|               |
 |  User-   |                                 | Authorization |
 |  Agent  -+----(B)-- User authenticates --->|     Server    |
 |          |                                 |               |
 |         -+----(C)-- Authorization Code ---<|               |
 +-|----|---+                                 +---------------+
   |    |                                         ^      v
  (A)  (C)                                        |      |
   |    |                                         |      |
   ^    v                                         |      |
 +---------+                                      |      |
 |         |>---(D)-- Authorization Code ---------'      |
 |  Client |          & Redirection URI                  |
 |         |                                             |
 |         |<---(E)----- Access Token -------------------'
 +---------+       (w/ Optional Refresh Token)

EXAMPLE REQUEST & RESPONSE

AUTHORIZATION REQUEST

GET /authorize?response_type=code&client_id=s6BhdRkqt3&state=xyz&redirect_uri=https%3A%2F%2Fclient%2Eexample%2Ecom%2Fcb HTTP/1.1
Host: server.example.com

AUTHORIZATION RESPONSE

HTTP/1.1 302 Found
Location: https://client.example.com/cb?code=SplxlOBeZQQYbYS6WxSbIA&state=xyz

또는

HTTP/1.1 302 Found
Location: https://client.example.com/cb?error=access_denied&state=xyz

ACCESS TOKEN REQUEST

POST /token HTTP/1.1
Host: server.example.com
Authorization: Basic czZCaGRSa3F0MzpnWDFmQmF0M2JW
Content-Type: application/x-www-form-urlencoded

grant_type=authorization_code&code=SplxlOBeZQQYbYS6WxSbIA&redirect_uri=https%3A%2F%2Fclient%2Eexample%2Ecom%2Fcb

ACCESS TOKEN RESPONSE

HTTP/1.1 200 OK
Content-Type: application/json;charset=UTF-8
Cache-Control: no-store
Pragma: no-cache

{
  "access_token":"2YotnFZFEjr1zCsicMWpAA",
  "token_type":"example",
  "expires_in":3600,
  "refresh_token":"tGzv3JOkF0XG5Qx2TlKWIA",
  "example_parameter":"example_value"
}

GITHUB: access_token=e72e16c7e42f292c6912e7710c838347ae178b4a&token_type=bearer

ACCESSING PROTECTED RESOURCES

GET /resource/1 HTTP/1.1
Host: example.com
Authorization: Bearer mF_9.B5f-4.1JqM

또는

GET /resource/1?access_token=...

SEE ALSO

• http://tools.ietf.org/html/rfc6749
• http://aaronparecki.com/articles/2012/07/29/1/oauth2-simplified
• http://developer.github.com/v3/oauth/

---

GITHUB 에서 사용하는 scope

(no scope)
user
user:email
user:follow
public_repo
repo
repo:status
delete_repo
notifications
gist
