cobookman · November 25, 2021 14:26
diff --git a/README.md b/README.md
diff --git a/gen_cert.sh b/gen_cert.sh
 # This generates a self sigend certificate for your web service
 mkdir tls
 openssl req -nodes -new -x509 -keyout tls/server.key -out tls/server.cert
diff --git a/index.html b/index.html
 <!DOCTYPE html>
 <html>
 <head>
  <title>Speech PoC</title>
 </head>
 <body>
 <h2>Transcribed text</h2>
 <div id="socket-server">wss://35.193.65.170/translate</div>
 <div id="status"></div>
 <div id="log"></div>
 <script>
 (function(window) {
  var app = {
    socket: null,
    bufferSize: 4096,
    $status: window.document.getElementById("status"),
    $log: window.document.getElementById("log"),
    main: function() {
      if(!this.init()) {
        alert("Your browser does not support websockets / audio context.");
        return;
      }
      this.socket = new WebSocket("wss://35.193.65.170/translate");
      this.socket.addEventListener("open", this.onOpen.bind(this));
      this.socket.addEventListener("message", this.onMessage.bind(this));
      this.socket.addEventListener("close", this.onClose.bind(this));
    },
    init: function() {
      try {
        // Shims
        window.AudioContext = window.AudioContext || window.webkitAudioContext;
        navigator.getUserMedia = navigator.getUserMedia ||
                                 navigator.webkitGetUserMedia ||
                                 navigator.mozGetUserMedia ||
                                 navigator.msGetUserMedia;
      } catch (e) {
        console.error(e);
                          return false;
      }

      return (navigator.getUserMedia && window.AudioContext);
    },
    onOpen: function(event) {
      this.startRecording(this.onAudio.bind(this)).then(() => {
              this.$status.textContent = "Recording";
      }).catch((error) => {
        alert("Failed to start recording audio :'(");
        console.log(error);
      });
    },
    onMessage: function(event) {
      this.$log.innerHTML += [
        "<p class=\"message\">",
              "  <code>",
              "    " + event.data,
              "  </code>",
              "</p>"
      ].join("\n");
    },
    onClose: function(event) {
      this.$status.textContent = "Stopped Transcoding & Recording stopped";
    },
    /**
     * Starts recording audio from the computers microphone,
     * and has the data hit a javascript function.
     */
    startRecording: function(callback) {
      return navigator.mediaDevices.getUserMedia({"audio": true, "video": false}).then((stream) => {
        var context = new window.AudioContext();

        // send metadata on audio stream to backend
        this.socket.send(JSON.stringify({
          sampleRateHz: context.sampleRate,
          language: "en-US",
          format: "LINEAR16"
        }));

        // Capture mic audio data into a stream
        var audioIn = context.createMediaStreamSource(stream);

        // only record mono audio and call a js function after a buffer of
        // size this.bufferSize is full
        var recorder = context.createScriptProcessor(this.bufferSize, 1, 1);

        //specify the processing function
        recorder.onaudioprocess = callback;

        // connect audioIn data to the recorder
        audioIn.connect(recorder)

        // connect recorder's output to previous destination
        recorder.connect(context.destination);
      });
    },
    /**
     * Converts audio stored as float32 to be Linear 16 bit PCM
     * data. Aka FLOAT322->INT16
     */
    float32ToLinear16: function(float32Arr) {
      var int16 = new Int16Array(float32Arr.length);
      for (var i =0; i < float32Arr.length; ++i) {
        // force number in [-1, 1]
        var s = Math.max(-1, Math.min(1, float32Arr[i]));

        // convert 32 bit float -> 16 bit int.
        // 0x7fff = max 16 bit num. 0x8000 = min 16 bit num.
        int16[i] = s < 0 ? s * 0x8000 : s * 0x7FFF;
      }
      return int16;
    },
    onAudio: function(event) {
      var float32Audio = event.inputBuffer.getChannelData(0) || new Float32Array(this.bufferSize);
      var linear16 = this.float32ToLinear16(float32Audio);
      this.socket.send(linear16.buffer);
    }
  };
  app.main();
 })(window);
 </script>
 </body>
diff --git a/main.py b/main.py
 import json
 import queue
 import threading
 from tornado import websocket, web, ioloop, httpserver
 from google.cloud import speech
 from google.cloud import logging

 logger = logging.Client().logger("speech-poc")

 class IndexHandler(web.RequestHandler):
  def get(self):
    self.render("index.html")


 class AudioWebSocket(websocket.WebSocketHandler):
  def check_origin(self, origin):
    return True

  def open(self):
    self.transcoder = None
    print("WebSocket opened")

  def on_message(self, message):
    if self.transcoder is None:
      config = json.loads(message)
      print(config)

      self.transcoder = Transcoder(
        sample_rate=config["sampleRateHz"],
        language_code=config["language"])

      # Start the transcoding of audio to text
      self.transcoder.start()
    else:
      self.transcoder.write(message)
      interim_results = self.transcoder.interim_results()
      if len(interim_results) != 0:
        print(interim_results)
        logger.log_struct({
            "request": "/translate",
            "interim_results": interim_results})
        self.write_message(json.dumps(interim_results))

  def on_close(self):
    self.transcoder.stop()
    self.transcoder = None


 class AudioStream(object):
  """An iteratable object which holds audio data that is pending processing."""

  def __init__(self):
    self.buff = queue.Queue()
    self.closed = False

  def __iter__(self):
    return self

  def __next__(self):
    return self.next()

  def write(self, data):
    self.buff.put(data)

  def close(self):
    self.closed = True
    self.buff.clear()

  def next(self):
    while not self.closed:
      chunk = self.buff.get()
      if chunk is not None:
        return chunk
    raise StopIteration


 class Transcoder(object):
  """Coordinates the translation of a raw audio stream."""

  def __init__(self, sample_rate, language_code,
               encoding=speech.enums.RecognitionConfig.AudioEncoding.LINEAR16):
    self.sample_rate = sample_rate
    self.language_code = language_code
    self.encoding = encoding
    self.closed = True
    self.audio = AudioStream()
    self.result_queue = queue.Queue()


  def write(self, data):
    """Write a chunk of audio to be translated."""
    self.audio.write(data)

  def start(self):
    """Start transcoding audio."""
    self.closed = False
    thread = threading.Thread(target=self._process)
    thread.start()

  def stop(self):
    """Stop transcoding audio."""
    self.closed = True
    self.audio.close()

  def _process(self):
    """Handles the setup of translation request, and retreving audio chunks in queue."""
    client = speech.SpeechClient()

    config = speech.types.RecognitionConfig(
        encoding=self.encoding,
        sample_rate_hertz=self.sample_rate,
        language_code=self.language_code)
    streaming_config = speech.types.StreamingRecognitionConfig(
        config=config,
        interim_results=True)

    # Give it a config and a generator which procduces audio chunks. in return
    # you get an iterator of results
    responses = client.streaming_recognize(streaming_config, self.generator())

    # This will block until there's no more interim translation results left
    for response in responses:
      self.result_queue.put(self._response_to_dict(response))

  def _response_to_dict(self, response):
    """Converts a response from streaming api to python dict."""
    if response is None:
      return []

    output = []
    for result in response.results:
      r = {}
      r["stability"] = result.stability
      r["is_final"] = result.is_final

      r["alternatives"] = []
      for alt in result.alternatives:
        r["alternatives"].append({
            "transcript": alt.transcript,
            "confidence": alt.confidence,
        })
      output.append(r)
    return output

  def interim_results(self, max_results=10):
    """Grabs interm results from the queue."""
    results = []
    while len(results) < max_results and not self.result_queue.empty():
      try:
        result = self.result_queue.get(block=False)
      except queue.QueueEmpty:
        return results
      results.append(result)
    return results

  def generator(self):
    """Generator that yields audio chunks."""
    for chunk in self.audio:
      yield speech.types.StreamingRecognizeRequest(audio_content=chunk)


 app = web.Application([
    (r"/", IndexHandler),
    (r"/index.html", IndexHandler),
    (r"/translate", AudioWebSocket),
 ])

 if __name__ == "__main__":
  ssl_options = {
      "certfile":  "tls/server.cert",
      "keyfile": "tls/server.key",
  }
  server = httpserver.HTTPServer(
      app, xheaders=True, ssl_options=ssl_options)
  server.listen(443)
  ioloop.IOLoop.current().start()
diff --git a/requirements.txt b/requirements.txt
 google-cloud-speech==0.27.1
 google-cloud-logging==1.1.0
 tornado==4.5.1
	# This generates a self sigend certificate for your web service
	mkdir tls
	openssl req -nodes -new -x509 -keyout tls/server.key -out tls/server.cert
	<!DOCTYPE html>
	<html>
	<head>
	<title>Speech PoC</title>
	</head>
	<body>
	<h2>Transcribed text</h2>
	<div id="socket-server">wss://35.193.65.170/translate</div>
	<div id="status"></div>
	<div id="log"></div>
	<script>
	(function(window) {
	var app = {
	socket: null,
	bufferSize: 4096,
	$status: window.document.getElementById("status"),
	$log: window.document.getElementById("log"),
	main: function() {
	if(!this.init()) {
	alert("Your browser does not support websockets / audio context.");
	return;
	}
	this.socket = new WebSocket("wss://35.193.65.170/translate");
	this.socket.addEventListener("open", this.onOpen.bind(this));
	this.socket.addEventListener("message", this.onMessage.bind(this));
	this.socket.addEventListener("close", this.onClose.bind(this));
	},
	init: function() {
	try {
	// Shims
	window.AudioContext = window.AudioContext \|\| window.webkitAudioContext;
	navigator.getUserMedia = navigator.getUserMedia \|\|
	navigator.webkitGetUserMedia \|\|
	navigator.mozGetUserMedia \|\|
	navigator.msGetUserMedia;
	} catch (e) {
	console.error(e);
	return false;
	}

	return (navigator.getUserMedia && window.AudioContext);
	},
	onOpen: function(event) {
	this.startRecording(this.onAudio.bind(this)).then(() => {
	this.$status.textContent = "Recording";
	}).catch((error) => {
	alert("Failed to start recording audio :'(");
	console.log(error);
	});
	},
	onMessage: function(event) {
	this.$log.innerHTML += [
	"<p class=\"message\">",
	" <code>",
	" " + event.data,
	" </code>",
	"</p>"
	].join("\n");
	},
	onClose: function(event) {
	this.$status.textContent = "Stopped Transcoding & Recording stopped";
	},
	/**
	* Starts recording audio from the computers microphone,
	* and has the data hit a javascript function.
	*/
	startRecording: function(callback) {
	return navigator.mediaDevices.getUserMedia({"audio": true, "video": false}).then((stream) => {
	var context = new window.AudioContext();

	// send metadata on audio stream to backend
	this.socket.send(JSON.stringify({
	sampleRateHz: context.sampleRate,
	language: "en-US",
	format: "LINEAR16"
	}));

	// Capture mic audio data into a stream
	var audioIn = context.createMediaStreamSource(stream);

	// only record mono audio and call a js function after a buffer of
	// size this.bufferSize is full
	var recorder = context.createScriptProcessor(this.bufferSize, 1, 1);

	//specify the processing function
	recorder.onaudioprocess = callback;

	// connect audioIn data to the recorder
	audioIn.connect(recorder)

	// connect recorder's output to previous destination
	recorder.connect(context.destination);
	});
	},
	/**
	* Converts audio stored as float32 to be Linear 16 bit PCM
	* data. Aka FLOAT322->INT16
	*/
	float32ToLinear16: function(float32Arr) {
	var int16 = new Int16Array(float32Arr.length);
	for (var i =0; i < float32Arr.length; ++i) {
	// force number in [-1, 1]
	var s = Math.max(-1, Math.min(1, float32Arr[i]));

	// convert 32 bit float -> 16 bit int.
	// 0x7fff = max 16 bit num. 0x8000 = min 16 bit num.
	int16[i] = s < 0 ? s * 0x8000 : s * 0x7FFF;
	}
	return int16;
	},
	onAudio: function(event) {
	var float32Audio = event.inputBuffer.getChannelData(0) \|\| new Float32Array(this.bufferSize);
	var linear16 = this.float32ToLinear16(float32Audio);
	this.socket.send(linear16.buffer);
	}
	};
	app.main();
	})(window);
	</script>
	</body>
	import json
	import queue
	import threading
	from tornado import websocket, web, ioloop, httpserver
	from google.cloud import speech
	from google.cloud import logging

	logger = logging.Client().logger("speech-poc")

	class IndexHandler(web.RequestHandler):
	def get(self):
	self.render("index.html")


	class AudioWebSocket(websocket.WebSocketHandler):
	def check_origin(self, origin):
	return True

	def open(self):
	self.transcoder = None
	print("WebSocket opened")

	def on_message(self, message):
	if self.transcoder is None:
	config = json.loads(message)
	print(config)

	self.transcoder = Transcoder(
	sample_rate=config["sampleRateHz"],
	language_code=config["language"])

	# Start the transcoding of audio to text
	self.transcoder.start()
	else:
	self.transcoder.write(message)
	interim_results = self.transcoder.interim_results()
	if len(interim_results) != 0:
	print(interim_results)
	logger.log_struct({
	"request": "/translate",
	"interim_results": interim_results})
	self.write_message(json.dumps(interim_results))

	def on_close(self):
	self.transcoder.stop()
	self.transcoder = None


	class AudioStream(object):
	"""An iteratable object which holds audio data that is pending processing."""

	def __init__(self):
	self.buff = queue.Queue()
	self.closed = False

	def __iter__(self):
	return self

	def __next__(self):
	return self.next()

	def write(self, data):
	self.buff.put(data)

	def close(self):
	self.closed = True
	self.buff.clear()

	def next(self):
	while not self.closed:
	chunk = self.buff.get()
	if chunk is not None:
	return chunk
	raise StopIteration


	class Transcoder(object):
	"""Coordinates the translation of a raw audio stream."""

	def __init__(self, sample_rate, language_code,
	encoding=speech.enums.RecognitionConfig.AudioEncoding.LINEAR16):
	self.sample_rate = sample_rate
	self.language_code = language_code
	self.encoding = encoding
	self.closed = True
	self.audio = AudioStream()
	self.result_queue = queue.Queue()


	def write(self, data):
	"""Write a chunk of audio to be translated."""
	self.audio.write(data)

	def start(self):
	"""Start transcoding audio."""
	self.closed = False
	thread = threading.Thread(target=self._process)
	thread.start()

	def stop(self):
	"""Stop transcoding audio."""
	self.closed = True
	self.audio.close()

	def _process(self):
	"""Handles the setup of translation request, and retreving audio chunks in queue."""
	client = speech.SpeechClient()

	config = speech.types.RecognitionConfig(
	encoding=self.encoding,
	sample_rate_hertz=self.sample_rate,
	language_code=self.language_code)
	streaming_config = speech.types.StreamingRecognitionConfig(
	config=config,
	interim_results=True)

	# Give it a config and a generator which procduces audio chunks. in return
	# you get an iterator of results
	responses = client.streaming_recognize(streaming_config, self.generator())

	# This will block until there's no more interim translation results left
	for response in responses:
	self.result_queue.put(self._response_to_dict(response))

	def _response_to_dict(self, response):
	"""Converts a response from streaming api to python dict."""
	if response is None:
	return []

	output = []
	for result in response.results:
	r = {}
	r["stability"] = result.stability
	r["is_final"] = result.is_final

	r["alternatives"] = []
	for alt in result.alternatives:
	r["alternatives"].append({
	"transcript": alt.transcript,
	"confidence": alt.confidence,
	})
	output.append(r)
	return output

	def interim_results(self, max_results=10):
	"""Grabs interm results from the queue."""
	results = []
	while len(results) < max_results and not self.result_queue.empty():
	try:
	result = self.result_queue.get(block=False)
	except queue.QueueEmpty:
	return results
	results.append(result)
	return results

	def generator(self):
	"""Generator that yields audio chunks."""
	for chunk in self.audio:
	yield speech.types.StreamingRecognizeRequest(audio_content=chunk)


	app = web.Application([
	(r"/", IndexHandler),
	(r"/index.html", IndexHandler),
	(r"/translate", AudioWebSocket),
	])

	if __name__ == "__main__":
	ssl_options = {
	"certfile": "tls/server.cert",
	"keyfile": "tls/server.key",
	}
	server = httpserver.HTTPServer(
	app, xheaders=True, ssl_options=ssl_options)
	server.listen(443)
	ioloop.IOLoop.current().start()
	google-cloud-speech==0.27.1
	google-cloud-logging==1.1.0
	tornado==4.5.1
