selecting series in Shiny with p_replace
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
| --- | |
| title: "Select Serie" | |
| output: | |
| flexdashboard::flex_dashboard: | |
| orientation: columns | |
| vertical_layout: fill | |
| runtime: shiny | |
| --- | |
| ```{r setup, include=FALSE} | |
| #' replace chart series interactively in Shiny | |
| #' idea from https://github.com/EKtheSage | |
| #' RE: https://github.com/JohnCoene/echarts4r/issues/325 | |
| library(flexdashboard) | |
| library(shiny) | |
| library(dplyr) | |
| library(echarty) | |
| ``` | |
| Column {.sidebar} | |
| ----------------------------------------------------------------------- | |
| ### Control | |
| ```{r} | |
| radioButtons('yvars', | |
| label = 'Select a Y Variable to Plot', | |
| selected = 'Sepal.Width', | |
| choices = c('Sepal.Width', 'Petal.Length', 'Petal.Width')) | |
| ``` | |
| Column | |
| ----------------------------------------------------------------------- | |
| ### Chart | |
| ```{r} | |
| dset <- legend <- series <- NULL | |
| output$chart <- ecs.render({ | |
| # add column color | |
| tmp <- data.frame(Species = as.vector(unique(iris$Species)), | |
| color = c("#387e78","#eeb422","#d9534f")) | |
| df <- iris %>% inner_join(tmp) | |
| p <- df %>% group_by(Species) %>% ec.init() | |
| p$x$opts$xAxis <- list(name='Sepal.Length', nameLocation='center') | |
| p$x$opts$yAxis <- list(name='Sepal.Width', nameRotate=90, nameLocation='center') | |
| # save valuable data from presets, reuse later | |
| dset <<- p$x$opts$dataset | |
| legend <<- p$x$opts$legend | |
| series <<- p$x$opts$series | |
| p | |
| }) | |
| observeEvent(input$yvars, { | |
| p <- ecs.proxy('chart') | |
| p$x$opts <- list( | |
| xAxis = list(name='Sepal.Length', nameLocation='center'), | |
| yAxis = list(name=input$yvars, nameRotate=90, nameLocation='center'), | |
| dataset = dset, | |
| legend = legend, | |
| series = lapply(series, function(s) { | |
| s$encode = list(y=input$yvars, x='Sepal.Length'); s }) | |
| ) | |
| p %>% ecs.exec('p_replace') | |
| }) | |
| ecs.output("chart") | |
| ``` |
Author
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
echarty solution. Original code from @EKtheSage.
