Org-mode Syntax Cheat sheet

org-syntax-cheatsheet.org

org-syntax-cheatsheet.org

1 What else can be specified.

Also check Manual entry for export options

1.1 Summary:

• #+TITLE: the title to be shown (default is the buffer name)
• #+AUTHOR: the author (default taken from user-full-name)
• #+DATE: a date, an Org timestamp1, or a format string for format-time-string
• #+EMAIL: his/her email address (default from user-mail-address)
• #+DESCRIPTION: the page description, e.g. for the XHTML meta tag
• #+KEYWORDS: the page keywords, e.g. for the XHTML meta tag
• #+LANGUAGE: language for HTML, e.g. ‘en’ (org-export-default-language)
• #+TEXT: Some descriptive text to be inserted at the beginning.
• #+TEXT: Several lines may be given.
• #+OPTIONS: H:2 num:t toc:t \n:nil @:t ::t |:t ^:t f:t TeX:t …
• #+BIND: lisp-var lisp-val, e.g.: org-export-latex-low-levels itemize
• You need to confirm using these, or configure org-export-allow-BIND
  • #+LINK_UP: the “up” link of an exported page
  • #+LINK_HOME: the “home” link of an exported page
  • #+LaTeX_HEADER: extra line(s) for the LaTeX header, like \usepackage{xyz}
  • #+EXPORT_SELECT_TAGS: Tags that select a tree for export
  • #+EXPORT_EXCLUDE_TAGS: Tags that exclude a tree from export
  • #+XSLT: the XSLT stylesheet used by DocBook exporter to generate FO file
• #+SETUPFILE: path to setup file. (simplifies frequent use of the same options)
• #+STYLE: <link rel=”stylesheet” type=”text/css” href=”stylesheet.css” /> (for html export)

1.2 Meaning of the options

• H: set the number of headline levels for export
• num: turn on/off section-numbers
• toc: turn on/off table of contents, or set level limit (integer)
• \n: turn on/off line-break-preservation (DOES NOT WORK)
• @: turn on/off quoted HTML tags

???

turn on/off fixed-width sections

• |: turn on/off tables
• ^: turn on/off TeX-like syntax for sub- and superscripts. If you write “^:{}”, a_b will be interpreted, but the simple a_b will be left as it is.
• -: turn on/off conversion of special strings.
• f: turn on/off footnotes like this[1].
• todo: turn on/off inclusion of TODO keywords into exported text
• tasks: turn on/off inclusion of tasks (TODO items), can be nil to remove all tasks, todo to remove DONE tasks, or list of kwds to keep
• pri: turn on/off priority cookies
• tags: turn on/off inclusion of tags, may also be not-in-toc
• <: turn on/off inclusion of any time/date stamps like DEADLINES
• *: turn on/off emphasized text (bold, italic, underlined)
• TeX: turn on/off simple TeX macros in plain text
• LaTeX: configure export of LaTeX fragments. Default auto
• skip: turn on/off skipping the text before the first heading
• author: turn on/off inclusion of author name/email into exported file
• email: turn on/off inclusion of author email into exported file
• creator: turn on/off inclusion of creator info into exported file
• timestamp: turn on/off inclusion creation time into exported file
• d: turn on/off inclusion of drawers, or list drawers to include

1.3 CSS Support for HTML export

• p.author author information, including email
• p.date publishing date
• p.creator creator info, about org mode version
• .title document title
• .todo TODO keywords, all not-done states
• .done the DONE keywords, all states that count as done
• .WAITING each TODO keyword also uses a class named after itself
• .timestamp timestamp
• .timestamp-kwd keyword associated with a timestamp, like SCHEDULED
• .timestamp-wrapper span around keyword plus timestamp
• .tag tag in a headline
• ._HOME each tag uses itself as a class, “@” replaced by “_”
• .target target for links
• .linenr the line number in a code example
• .code-highlighted for highlighting referenced code lines
• div.outline-N div for outline level N (headline plus text))
• div.outline-text-N extra div for text at outline level N
• .section-number-N section number in headlines, different for each level
• div.figure how to format an inlined image
• pre.src formatted source code
• pre.example normal example
• p.verse verse paragraph
• div.footnotes footnote section headline
• p.footnote footnote definition paragraph, containing a footnote
• .footref a footnote reference number (always a <sup>)
• .footnum footnote number in footnote definition (always <sup>)

1.4 LaTeX Support

By default, the LaTeX output uses the class article.

• #+LaTeX_CLASS: article
• #+LaTeX_CLASS_OPTIONS: [a4paper]
• #+LaTeX_HEADER: \usepackage{xyz}
• #+LaTeX: Literal LaTeX code for export
• #+BEGIN_LaTeX All lines between these markers are exported literally
• #+CAPTION: A long table

  .....	.....
  .....	.....

• #+CAPTION: A long table

  .....	.....
  .....	.....

• #+CAPTION: The black-body emission of the disk around HR 4049

  ./img/sed-hr4049.pdf



• Beamer class support
• Embedded Latex

2 References

2.1 Org Babel

Babel for org-mode

2.2 Org

Tutorials Worg main site.

3 Heading with tags

3.1 TODO Heading 2: Set a deadline and a schedule

3.1.1 DONE [66%] Heading 3: a list with checkboxes

1. [X] task 1
2. [X] task 2
3. [ ] task 3

3.2 TODO [1/3] Track completion of tasks

3.2.1 DONE Finished task

• State “DONE” from “TODO” [2012-03-07 Wed 07:56]

3.2.2 STARTED Started task

3.2.3 TODO Unstarted task

• State “TODO” from “DONE” [2012-03-07 Wed 08:02]

4 Fancy typesetting features

• bold ital underline code verbatim strike through

• : literal example
• ----- horizontal line (5 dashes)

5 Hyperlinks

hyperlink text External Links targetted link shell commands

6 Tables and Spreadsheets

6.1 Basic Table

Col1	Col 2
KW	Sep
TW	Aug

6.2 Spreadsheet

x	y
1	1
2	1.4142136
3	1.7320508
4	2

7 Source Code

plot(1:10)

return x + 1

8 Mathematical Equations

\begin{equation} ∫^x_0 x^2 dx = \frac{x^3}{3} \end{equation}
