Pinch + Zoom + Pan

This is a standalone pinch zoom pan React component with no other dependencies.

Demo

Open on Mobile

Features

1. Pinch to zoom
2. Breaking just out of min and max zooms and settling back
3. Double tap to reset
4. All interaction happens in the pinch zoom pan component and gets virtually computed to your underlying display.
5. Thanks to the beauty of function-as-child components, you choose how the x, y and scale are applied. I recommend CSS3 to get that sweet hardware acceleration, you know what I'm talking about?
6. Panning after zoom with limits sets by the size of the scaled content.

PinchZoomPan.js

import React from 'react';

const MIN_SCALE = 1;
const MAX_SCALE = 4;
const SETTLE_RANGE = 0.001;
const ADDITIONAL_LIMIT = 0.2;
const DOUBLE_TAP_THRESHOLD = 300;
const ANIMATION_SPEED = 0.04;
const RESET_ANIMATION_SPEED = 0.08;
const INITIAL_X = 0;
const INITIAL_Y = 0;
const INITIAL_SCALE = 1;

const settle = (val, target, range) => {
  const lowerRange = val > target - range && val < target;
  const upperRange = val < target + range && val > target;
  return lowerRange || upperRange ? target : val;
};

const inverse = (x) => x * -1;

const getPointFromTouch = (touch, element) => {
  const rect = element.getBoundingClientRect();
  return {
    x: touch.clientX - rect.left,
    y: touch.clientY - rect.top,
  };
};

const getMidpoint = (pointA, pointB) => ({
    x: (pointA.x + pointB.x) / 2,
    y: (pointA.y + pointB.y) / 2,
});

const getDistanceBetweenPoints = (pointA, pointB) => (
  Math.sqrt(Math.pow(pointA.y - pointB.y, 2) + Math.pow(pointA.x - pointB.x, 2))
);

const between = (min, max, value) => Math.min(max, Math.max(min, value));

class PinchZoomPan extends React.Component {
  constructor() {
    super(...arguments);
    this.state = this.getInititalState();

    this.handleTouchStart = this.handleTouchStart.bind(this);
    this.handleTouchMove = this.handleTouchMove.bind(this);
    this.handleTouchEnd = this.handleTouchEnd.bind(this);
  }

  zoomTo(scale, midpoint) {
    const frame = () => {
      if (this.state.scale === scale) return null;

      const distance = scale - this.state.scale;
      const targetScale = this.state.scale + (ANIMATION_SPEED * distance);

      this.zoom(settle(targetScale, scale, SETTLE_RANGE), midpoint);
      this.animation = requestAnimationFrame(frame);
    };

    this.animation = requestAnimationFrame(frame);
  }

  reset() {
    const frame = () => {
      if (this.state.scale === INITIAL_SCALE && this.state.x === INITIAL_X && this.state.y === INITIAL_Y) return null;
      const distance = INITIAL_SCALE - this.state.scale;
      const distanceX = INITIAL_X - this.state.x;
      const distanceY = INITIAL_Y - this.state.y;

      const targetScale = settle(this.state.scale + (RESET_ANIMATION_SPEED * distance), INITIAL_SCALE, SETTLE_RANGE);
      const targetX = settle(this.state.x + (RESET_ANIMATION_SPEED * distanceX), INITIAL_X, SETTLE_RANGE);
      const targetY = settle(this.state.y + (RESET_ANIMATION_SPEED * distanceY), INITIAL_Y, SETTLE_RANGE);

      const nextWidth = this.props.width * targetScale;
      const nextHeight = this.props.height * targetScale;

      this.setState({
        x: targetX,
        y: targetY,
        scale: targetScale,
        width: nextWidth,
        height: nextHeight,
      }, () => {
        this.animation = requestAnimationFrame(frame);
      });
    };

    this.animation = requestAnimationFrame(frame);
  }

  getInititalState() {
    return {
      x: INITIAL_X,
      y: INITIAL_Y,
      scale: INITIAL_SCALE,
      width: this.props.width,
      height: this.props.height,
    };
  }

  handleTouchStart(event) {
    this.animation && cancelAnimationFrame(this.animation);
    if (event.touches.length == 2) this.handlePinchStart(event);
    if (event.touches.length == 1) this.handleTapStart(event);
  }

  handleTouchMove(event) {
    if (event.touches.length == 2) this.handlePinchMove(event);
    if (event.touches.length == 1) this.handlePanMove(event);
  }

  handleTouchEnd(event) {
    if (event.touches.length > 0) return null;

    if (this.state.scale > MAX_SCALE) return this.zoomTo(MAX_SCALE, this.lastMidpoint);
    if (this.state.scale < MIN_SCALE) return this.zoomTo(MIN_SCALE, this.lastMidpoint);

    if (this.lastTouchEnd && this.lastTouchEnd + DOUBLE_TAP_THRESHOLD > event.timeStamp) {
      this.reset();
    }

    this.lastTouchEnd = event.timeStamp;
  }

  handleTapStart(event) {
    this.lastPanPoint = getPointFromTouch(event.touches[0], this.container);
  }

  handlePanMove(event) {
    if (this.state.scale === 1) return null;

    event.preventDefault();

    const point = getPointFromTouch(event.touches[0], this.container);
    const nextX = this.state.x + point.x - this.lastPanPoint.x;
    const nextY = this.state.y + point.y - this.lastPanPoint.y;

    this.setState({
      x: between(this.props.width - this.state.width, 0, nextX),
      y: between(this.props.height - this.state.height, 0, nextY),
    });

    this.lastPanPoint = point;
  }

  handlePinchStart(event) {
    const pointA = getPointFromTouch(event.touches[0], this.container);
    const pointB = getPointFromTouch(event.touches[1], this.container);
    this.lastDistance = getDistanceBetweenPoints(pointA, pointB);
  }

  handlePinchMove(event) {
    event.preventDefault();
    const pointA = getPointFromTouch(event.touches[0], this.container);
    const pointB = getPointFromTouch(event.touches[1], this.container);
    const distance = getDistanceBetweenPoints(pointA, pointB);
    const midpoint = getMidpoint(pointA, pointB);
    const scale = between(MIN_SCALE - ADDITIONAL_LIMIT, MAX_SCALE + ADDITIONAL_LIMIT, this.state.scale * (distance / this.lastDistance));

    this.zoom(scale, midpoint);

    this.lastMidpoint = midpoint;
    this.lastDistance = distance;
  }

  zoom(scale, midpoint) {
    const nextWidth = this.props.width * scale;
    const nextHeight = this.props.height * scale;
    const nextX = this.state.x + (inverse(midpoint.x * scale) * (nextWidth - this.state.width) / nextWidth);
    const nextY = this.state.y + (inverse(midpoint.y * scale) * (nextHeight - this.state.height) / nextHeight);

    this.setState({
      width: nextWidth,
      height: nextHeight,
      x: nextX,
      y: nextY,
      scale,
    });
  }

  render() {
    return (
      <div
        ref={(ref) => this.container = ref}
        onTouchStart={this.handleTouchStart}
        onTouchMove={this.handleTouchMove}
        onTouchEnd={this.handleTouchEnd}
        style={{
          overflow: 'hidden',
          width: this.props.width,
          height: this.props.height,
        }}
      >
        {this.props.children(this.state.x, this.state.y, this.state.scale)}
      </div>
    );
  }
}

PinchZoomPan.propTypes = {
  children: React.PropTypes.func.isRequired,
};

export default PinchZoomPan;

Usage.js

import React from 'react';

const Usage = ({width, height}) => (
  <div>
    <PinchZoomPan width={width} height={height}>
    {(x, y, scale) => (
        <img
          src={`https://placekitten.com/${width}/${height}`}
          style={{
            pointerEvents: scale === 1 ? 'auto' : 'none',
            transform: `translate3d(${x}px, ${y}px, 0) scale(${scale})`,
            transformOrigin: '0 0',
          }} />
    )}
    </PinchZoomPan>
  </div>
);

export default Usage;

To ensure that the image fits properly, i.e. if scale < 1, the image stays entirely inside the area, and if scale > 1, there is no blank space inside the area, limit nextX and nextY in function zoom:

zoom (scale, midpoint) {
  ...

  this.setState({
    width: nextWidth,
    height: nextHeight,
    x: checkBetween(0, this.props.width - nextWidth, nextX),
    y: checkBetween(0, this.props.height - nextHeight, nextY),
    scale,
  });
}

where

const checkBetween = (m1, m2, value) => {
  return m1 < m2 ? between(m1, m2, value ) : between(m2, m1, value)
}

Thanks for this! Works like a charm.

Hi,

Thank you for the code.

I have a problem and I hope somebody can help me.

I need to center the image I'm zooming.
When I zoom it on my mobile phone the image is moving to the left. I can move it to the center, but would like to know how to zoom and keep it centered.

Here is an example - https://codepen.io/denis-n/pen/aPZzMo

Hi,

I seem to be able to implement this, but unable to test its functionality because the entire view zooms when I pinch (iOS safari), not the image. Does anyone know of a fix for this? Setting a meta tag on the entire page doesn't seem to work, EG <meta name="viewport" content="width=device-width, user-scalable=no" />

Thanks

Is there a reason why lastPanPoint is not stored in the PinchZoom component's local state along with x, y, scale, width, and height?

you are mister a hero

Does it work with scrollable content? What if the child element has a PDF with multiple pages and we use it to zoom the content in it? i am going to try this out. If you guys can share some thoughts or findings, it will be helpful.

I cant make it work with scrollable content (pdf).
