Regular Expressions

Learning Objectives

Not be mystified by Regular Expressions
Write basic Regular Expression patterns
Use RegEx patterns to validate HTML <input> tags

What are Regular Expressions?

A sequence of characters that define a pattern that is used to search/match, and optionally replace, text in strings and files.
Grounded in Computer Science and used throughout computing by:
- Programming languages
- Word processors & text editors
- System utilities like Unix's grep
So comprehensive, they are their own computer language.
They are very useful for things like web scraping and validation!

Regular Expression Patterns

To start, we're going to use the code playground, codepen.io, to play with regex's in HTML <input> elements.
Create a new pen, and hide the JS pane.

In the HTML pane, let's add a simple form:

 <form>
 	text: <input type="text" required pattern="Fred">
 </form>

Put this in your pen's CSS pane:

body {
  font: 14pt Helvetica;
}
form {
  padding: 50px;
  border: 4px solid lightgreen;
  border-radius: 20px;
}
form:invalid {
  border-color: yellow;
}
input {
  font: 14pt Helvetica;
  margin: 10px;
  padding: 4px;
}
input:invalid {
  border-color: red;
}

Regular Expression Patterns (cont.)

We won't need to change our CSS going forward, so go ahead and hide the CSS pane.
Just to get orientated, this is what a regular expression to match/validate a typical 10-digit phone number like (310) 555-1212 looks like in JS and Ruby:
```
 /^$\d{3}$\s\d{3}-\d{4}$/
```
Crazy looking stuff - yes? Don't sweat it, by the end of the lesson, this gibberish will all make sense.

Validating Text in an <input>

Let's take a look at a common and practical use for regular expressions - one that you can start applying to your apps pronto.
HTML5 <input> elements have a pattern attribute just for regex patterns.

Validating Text in an <input>

If the text in the <input> does not completely match the regular expression:
- The submit button will not submit the form to the server.
- The <form> will have the :invalid CSS pseudo-class applied to it.

Patterns - Literal Characters

The first type of characters within a regex pattern up discussion are literal characters.
A literal is the most basic of the regex characters. They are literally the character we want to match.
The first regex we have put in our <input>, pattern="Fred", has a pattern, fred that consists entirely of literal characters.

Patterns - Literal Characters (cont.)

Type "Fred" and you will see the form's border turn green indicating a match!
Reminder: We are looking at regex's initially within the context of an HTML <input> element. If this were an ordinary regular expression, our pattern, Fred, would match the first occurrence of the letters Fred anywhere within a string such as
Say hi to Fredrick, aka Fred, when you see him.

Patterns - Character Class

Next up is a character class. They tell the regex engine to match only one of several characters placed within square brackets.
Lets change our pattern to gr[ae]y.
Check it out!

Patterns - Character Class (cont.)

You can use a hyphen inside of a character class to specify a range of characters. For example, [5-9] will match a single digit of 5 to 9.
You can use more than one range too. This pattern, [0-9a-fA-F], would would match any single hexadecimal digit regardless of case.
Character classes are great for matching frequently misspelled words like li[cs]en[cs]e.

Character Class - Question

What regular expression could be used to match your name whether it is capitalized or not?

Negated Character Class

Putting a ^ (caret) symbol after the opening [, means match any character except the character(s) in the brackets.
So, p[^ua] will match the letter p followed by any single character except a u or a.

Shorthand Character Classes

Because character classes are used so often, there are several shorthand character classes available. For example, instead of using [0-9] to match a digit, you can use \d instead.

Shorthand Character Classes

Here are more shorthand character classes:
- \w will match any alphanumeric character, including digits and the underscore character.
- \s will match any "whitespace" character, including a space, tab, newline and carriage return.
- . (period) will match any character except line breaks.
Google will be your friend when working with regular expressions, unless you work with them frequently, there's no way to remember all this stuff!

More Negativity

Interestingly, the uppercase versions of the previous shorthands match just the opposite of the lowercase versions:
- \D will match any character except a digit.
- \W will match anything but an alphanumeric character (and underscore).
- \S will match anything except a space, tab, newline or return.

Exercise (5 mins)

Based upon what you've learned already, work with a pair and:

Write a regex pattern that will match:
The word "File", followed by a space and two uppercase letters from the alphabet, followed by a hyphen and three digits, except that the first of the three digits cannot be a zero.
For example, this text would be a match:
File XY-123

Solution

File [A-Z][A-Z]-[1-9][0-9][0-9]
Note that there is no shortcut character class to match a letter from the alphabet only, so we must use:
[a-z] (lowercase),
[A-Z] (uppercase)
or [a-zA-Z] (upper or lowercase)

Quantifiers

In the previous exercise/solution, we repeated the same character classes when we wanted to match more than one. Well, there's a better way using quantifiers.
There are four different quantifiers:
- {}
- *
- +
- ?
Let's see how they work...

Quantifiers - {}

We use curly braces to specify a specific quantity, or range of quantities, to repeat a literal character, character class, etc.
For example, \d{3} would match three digits.
What regex pattern could you use to match a social security number with this format:
###-##-####

Quantifiers - {} (cont.)

We can also specify a range like [A-Z]{1,5}, which would match between 1 and 5 capital letters.
A range from a number to infinity can be created by leaving off the second number such as this {5,}.
Note that regular expressions by default are "greedy", that is, they will match as many characters as possible (longest possible match).

Other Quantifiers

In addition to the {min,max} quantifier, there are repetition operators:
- * - the star symbol will match the preceding character class zero or more times.
- + - the plus symbol will match the preceding character class one or more times.
- ? - the question mark will match the preceding character class zero or one time.
Take 2 minutes to figure out the curly brace equivalents for each of the above repetition operators (*, + and ?)

Exercise (5 mins)

With your pair:
Write a pattern that would match a street address where the address:
- Starts with 1 to 5 digits (no leading zero)
- Followed by a space
- Followed by a street name beginning with a capital letter, then 1-n characters, including spaces.
For example, this text would be a match:
123 Main Street

Possible Solution

[1-9][0-9]{0,4} [A-Z].+

Escaping Special Characters

We've seen how certain characters such as these, /*+?.[]{}, have special meaning in regular expressions.
That being the case, how do we match these special characters as a literal character? For example, what if you wanted a pattern to match a number that includes a decimal point?

Escaping Special Characters (cont.)

To accomplish this, you have to escape the special character by preceding it with a \ (backslash), for example, \+, would match the plus symbol.
Note that we do not have to escape special characters within a character class (square brackets). So, if you wanted to match a plus or minus sign, you could use this pattern
[+-].

Practice (3 mins)

Write the regular expression that would match a floating-point number with one or more digits on both sides of the decimal.
Write the regular expression that would match this text:
What?

Solution

\d+\.\d+
What\?

Regular Expressions in JavaScript

Before we begin to work with more complex regular expressions, lets use the console in Chrome's DevTools to check them out using JavaScript.
In JavaScript, regular expressions are special objects that can be created using a regular expression literal, or the RegExp() constructor function.

Regular Expressions in JavaScript (cont.)

The literal syntax uses forward slashes to delimit the regex:
```
 var re = /cats?/;
```
The literal syntax is the best option if you know the pattern you want to use in advance. However, using the constructor approach allows you to pass in a string variable to create a regex dynamically:
```
 var s = "cats?";
 var re = new RegExp(s);
```

Regular Expressions in JavaScript (cont.)

A regex object has a test() method that returns true if there is at least one match:
```
 var re = /cats?/;
 re.test('fatcat');   // returns true
```

Practice (3 mins)

Create a JS regex in the console that would match a phone number with the following format:
(###) ###-####

Hint, the parenthesis are special characters, so we have to _________ them.
Use the test method on the regex to test some phone numbers.

Solution

Note the use of backslashes to escape the parens:
```
 var re = /$\d{3}$ \d{3}-\d{4}/;
```
These docs discuss working with regular expressions in JavaScript, including the methods on Strings as well as the test() and exec() methods of the regular expression object.

JavaScript Methods Using Regular Expressions

Method	Description
`exec`	A `RegExp` method that executes a search for a match in a string. It returns an array of information.
`test`	A `RegExp` method that tests for a match in a string. It returns true or false.
`match`	A `String` method that executes a search for a match in a string. It returns an array of information or null on a mismatch.
`search`	A `String` method that tests for a match in a string. It returns the index of the match, or -1 if the search fails.
`replace`	A `String` method that executes a search for a match in a string, and replaces the matched substring with a replacement substring.
`split`	A `String` method that uses a regular expression or a fixed string to break a string into an array of substrings.

A Great Site for Regex's

As me move into more complex regular expressions, the regex101.com web app will provide us with a better tool to learn and practice with.
Open it up in place of codepen.

Alternation

Alternation allows us to easily search for one of several characters or words.
Let's say you want a single regex that will match any of these sentences:
I have a dog.
I have a cat.
I have a bird.
I have a fish.
This would do the trick
/I have a (dog|cat|bird|fish)\./.

Exercise (5 mins)

Write a regex that would match a CSS color hexadecimal (3 or 6 characters), such as
#f355Ac or #D39

Solution

Solution:
```
 /#([a-fA-F0-9]{6}|[a-fA-F0-9]{3})/
```
Why can't we use the alphanumeric character shortcut \w, in place of the much longer [a-fA-F0-9]?

Grouping

Parentheses are used inside regular expressions to create groups that can then have a quantifier applied to the group as a whole.
Whereas, the square brackets character class, [], represents a single character to match, the parentheses, (), represent a group of characters to match.

Grouping (cont.)

Let's say we wanted to match a computer's IP Address. Ignoring the fact that we should limit the numbers to between 0 and 255, we could write something like this:
/\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}/
But using grouping we can shorten this to:
/(\d{1,3}\.){3}\d{1,3}/

Exercise (2 mins)

Write a regular expression that would match this string:
hey!hey!hey!

Solution

/(hey!){3}/

Anchors and Boundaries

Anchors and boundaries are unique in that they don't match a character, instead they match a position.
They allow us to write patterns that match strings that contain only the characters we are interested in and only if they are isolated the way we want them to be.

Anchors and Boundaries (cont.)

The ^ symbol is used to match the start of the line. This is very useful for processing a file containing multiple lines.
The $ symbol matches the end of the line.
For example, without boundaries, the regex /dog/ will return true when tested against any of these strings: "dog", "dogs" and "My dog is named Spot". However, the regex /^dog$/ will match only the string "dog" and when there is no other text in the line.

Anchors and Boundaries (cont.)

Let's test the pattern, cat, with anchors (/^cat$/), and without (/cat/), against the strings "cat" and "catsup".

Anchors and Boundaries (cont.)

There is also \b, which matches a position called a
word boundary. The \b will match any of the following:
- Before the first character in the string.
- After the last character in the string.
- Between two characters in the string where one character is a word character and the other is a non-word character such as a space, tab, or newline.

Anchors and Boundaries (cont.)

The \b easily allows us to search for whole words only.
This is how could use the string match() method to return the matches by passing in a regex:

// try with no word boundary
var re = /cat/g;
var matches = "The catsup was eaten by the cat".match(re);
// ["cat", "cat"]

// try using word boundary
var re = /\bcat\b/g;
var matches = "The catsup was eaten by the cat".match(re);
// ["cat"]

The g at the end of the regex is the global flag and it tells the regex to search for all matches, instead of just the first.

Capturing

Parentheses can also be used to define capture groups.
Capturing is when matched text is "captured" into numbered groups.
These groups can then be reused with a process called backreferencing.
Capturing is beyond the scope of this lesson. Here's one of several articles out there should the mood strike you.

Moving Forward

We've visited the core of regular expressions, however, we've really only scratched the surface.
You will surely cross paths with regular expressions during your career as a developer. And when you do, as usual, Google and documentation will be your friend.
There are several regex playgrounds like regex101.com that we used this morning. Here's another one you can check out: http://www.regexr.com/

Final Questions

What is a Regular Expression?
What Regular Expression could be used to match a string representing a social security number in this format:
xxx-xx-xxxx
Four exercises follow...

Additional Exercises

Now you can have some fun practicing writing four more regular expressions.
A possible solution follows each of the four exercises.

Additional Practice - 1 of 4

Match an American Express Credit Card Number which always begin with 34 or 37 and totals 15 digits.

Solution - 1 of 4

/3[47]\d{13}/

Additional Practice - 2 of 4

Match a full U.S. Phone Number:
+1-(555)-555-5555

Solution - 2 of 4

/\+1-$\d{3}$-\d{3}-\d{4}/

Additional Practice - 3 of 4

A date in the format:
YYYY-MM-DD.
YYYY can start with either 19 or 20 only.
DD can be anything from 01 to 31, regardless of the month.

Solution - 3 of 4

/(19|20)\d\d-(0[1-9]|1[012])-(0[1-9]|[12][0-9]|3[01])/

Additional Practice - 4 of 4

An integer between 0 and 255
This is difficult, remember to use the "alternation" (|) operator.

Solution - 4 of 4

/(2[0-4][0-9]|25[0-5]|[01]?[0-9]?[0-9])/

jim-clark/regex.md

Regular Expressions

Learning Objectives

What are Regular Expressions?

Regular Expression Patterns

Regular Expression Patterns (cont.)

Validating Text in an <input>

Validating Text in an <input>

Patterns - Literal Characters

Patterns - Literal Characters (cont.)

Patterns - Character Class

Patterns - Character Class (cont.)

Character Class - Question

Negated Character Class

Shorthand Character Classes

Shorthand Character Classes

More Negativity

Exercise (5 mins)

Solution

Quantifiers

Quantifiers - {}

Quantifiers - {} (cont.)

Other Quantifiers

Exercise (5 mins)

Possible Solution

Escaping Special Characters

Escaping Special Characters (cont.)

Practice (3 mins)

Solution

Regular Expressions in JavaScript

Regular Expressions in JavaScript (cont.)

Regular Expressions in JavaScript (cont.)

Practice (3 mins)

Solution

JavaScript Methods Using Regular Expressions

A Great Site for Regex's

Alternation

Exercise (5 mins)

Solution

Grouping

Grouping (cont.)

Exercise (2 mins)

Solution

Anchors and Boundaries

Anchors and Boundaries (cont.)

Anchors and Boundaries (cont.)

Anchors and Boundaries (cont.)

Anchors and Boundaries (cont.)

Capturing

Moving Forward

Final Questions

Additional Exercises

Additional Practice - 1 of 4

Solution - 1 of 4

Additional Practice - 2 of 4

Solution - 2 of 4

Additional Practice - 3 of 4

Solution - 3 of 4

Additional Practice - 4 of 4

Solution - 4 of 4

References
