This macro creates a spring with customizable, any turn may change the spring configuration can be saved in a file with the extension .FCSpring or in a coordonate file with the extension .FCSpringCoor
Raw
Macro_FCSpring_Helix_Variable.FCMacro
# -*- coding: utf-8 -*-
from __future__ import unicode_literals
from __future__ import division
"""
***************************************************************************
* Copyright (c) <mario52> 2014-2015-2016-2017 2018 2019 2020 2022 2023 *
* 2024 *
* *
* This file is a supplement to the FreeCAD CAx development system. *
* *
* This program is free software; you can redistribute it and/or modify *
* it under the terms of the GNU Lesser General Public License (LGPL) *
* as published by the Free Software Foundation; either version 2 of *
* the License, or (at your option) any later version. *
* for detail see the LICENCE text file. *
** **
* Use at your own risk. The author assumes no liability for data loss. *
* It is advised to backup your data frequently. *
* If you do not trust the software do not use it. *
** **
* This software is distributed in the hope that it will be useful, *
* but WITHOUT ANY WARRANTY; without even the implied warranty of *
* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the *
* GNU Library General Public License for more details. *
* *
* You should have received a copy of the GNU Library General Public *
* License along with this macro; if not, write to the Free Software *
* Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307 *
* USA *
***************************************************************************
* WARNING! All changes in this file will be lost and *
* may cause malfunction of the program *
***************************************************************************
"""
#
#OS: Windows 10 build 19045 #OS: Linux Mint 20.1 (X-Cinnamon/cinnamon)
#Word size of FreeCAD: 64-bit #Word size of FreeCAD: 64-bit
#Version: 0.22.0dev.33981 (Git) #Version: 0.22.0dev.37928 (Git) AppImage
#Build type: Release #Build type: Release
#Branch: master #Branch: main
#Hash: 5a153e50ffb6046b6cc4dba498344032f6edb952 #Hash: e7699b531eba4bee262f7214699f07b96f66ba7b
#Python 3.10.12, Qt 5.15.8, Coin 4.0.0, Vtk 9.2.5, OCC 7.6.3 #Python 3.11.9, Qt 5.15.13, Coin 4.0.2, Vtk 9.2.6, OCC 7.7.2
#Locale: French/Mars (fr_MA) #Locale: C/Default (C)
#
#
__Title__ = "FCSpring_Helix_Variable"
__Author__ = "Mario52"
__Url__ = "http://www.freecadweb.org/index-fr.html"
__Wiki__ = "http://www.freecadweb.org/wiki/index.php?title=Macro_FCSpring_Helix_Variable"
__GitHub__ = "https://gist.github.com/mario52a/68c81c32a0727a693d3a"
__Version__ = "01.19"
__Date__ = "2024/07/11" # YYYY/MM/DD
#
#
import PySide2
from PySide2 import QtWidgets, QtCore, QtGui
from PySide2.QtWidgets import * #(QWidget, QApplication, QSlider, QGraphicsView, QGraphicsScene, QVBoxLayout, QStyle)
from PySide2.QtGui import *
from PySide2.QtCore import *
#from PySide2.QtGui import (QPainter, QColor, QIcon)
#from PySide2.QtSvg import *
try:
import webbrowser
except Exception:
None
import os, sys #, time
import Draft, Part, FreeCAD, math, PartGui, FreeCADGui, FreeCAD
from math import sqrt, pi, sin, cos, asin, tan, degrees, radians, sqrt
from FreeCAD import Base
App = FreeCAD
####chrono################
import time
global depart ; depart = 0.0
global arrivee; arrivee = 0.0
def chrono(switch): # 0=depart autre=stop
#time.strftime('%X %x %Z')#'15:44:07 12/14/19 Paris, Madrid'
global depart
global arrivee
try:
if switch == 0:
depart = time.time()#time.clock()
App.Console.PrintMessage("Chrono begin : "+str(time.strftime('%X'))+"\n")
else:
arrivee = time.time()#time.clock()
App.Console.PrintMessage("Chrono end : "+str(time.strftime('%X'))+"\n")
parcouru = ((arrivee - depart)/60.0)
App.Console.PrintError("Time execution : "+str("%.3f" % parcouru)+" min"+"\n\n")
return parcouru
FreeCADGui.updateGui()
except Exception: None
####chrono################
##path###########################################################################
global path
#path = FreeCAD.ConfigGet("AppHomePath")
#path = FreeCAD.ConfigGet("UserAppData")
#path = "your path"
param = FreeCAD.ParamGet("User parameter:BaseApp/Preferences/Macro")# macro path
path = param.GetString("MacroPath","") + "/" # macro path
path = path.replace("\\","/") # convert the "\" to "/"
#print( "Path for the icons : " , path )
##path###########################################################################
global numberSpires ;numberSpires = 10 # number Spires of spring
global rayon ;rayon = 20.0 # radius of spring
global pas ;pas = 15.0 # " ! float " (pas) pitch of spire
global precision ;precision = 5.0 # " ! float " 360/precision number points for 1 turn
global typeLine ;typeLine = 0 # typeLine 0=BSpline or 1=Wire
global helixS ;helixS = 0.0 # tableau
global numberSpiresModified;numberSpiresModified = 1 # number (pas) pitch to modify
global pasSpire ;pasSpire = 0 #pas # (pas) pitch of spire to modify
global radiusS ;radiusS = 0.0 # tableau radius to modify
global rayonSpire ;rayonSpire = 0 #rayon # new radius
global affPoint ;affPoint = 0 # aff points
global debutAngle ;debutAngle = 0 # begin angle rotation
global finAngle ;finAngle = 360 # end angle rotation
global modifyAngle ;modifyAngle = 0 # interrupteur angle
global radius_2_Cone ;radius_2_Cone = rayon # radius_2_Cone en cas d'helice
global spireConeUne ;spireConeUne = 0 # interrupteur cone si une seule spire spireConeUne = 1
global spireConeComp ;spireConeComp = 0 # compensation pour cone
global spireReverse ;spireReverse = 0 # 0 = sens antihoraire si = 1 sens horaire
global lissageSpire ;lissageSpire = 0 # niveau de lissage
global lissageS ;lissageS = 0 # tableau
global fichierOpen ;fichierOpen = 0 # switch fichier precision
global nomF ;nomF = "Name File" # name file
global points ;points = [] # tableau points
global zoom ;zoom = 0 # zoom textEdit
global ressort ;ressort = ""
global s ;s = "" # resident
global ui ;ui = "" # resident
global sel ;sel = "" # resident selection
global pointsDirection ;pointsDirection = [] # tableau direction
global Direction_Begin ;Direction_Begin = 0 # direction tableau 0
global Direction_Distance ;Direction_Distance = 0.1 # precision Distance coupure et deplacement
global plr ;plr = "" # placement sur selection
global coor_Z ;coor_Z = 0.0 # pour calcul placement
global hauteurCylindre ;hauteurCylindre = 0.0 # adapter la hauteur du ressort
global vecteurSouris ;vecteurSouris = "" # vecteur Selobserver
global centerFaceOrPoint ;centerFaceOrPoint = 0 # centrage de l'axe sur face ou au point souris
global axisSpring ;axisSpring = "" # axe de l'objet pour le ressort
global switchReverse ;switchReverse = 0 # switchReverse
global switchAdaptRadius ;switchAdaptRadius = 0 # switchAdaptRadius
global selectedCircle ;selectedCircle = [] # tableau Circle
#### Configuration begin ################################################
#### NOT MODIFY THE CODE HERE ####
#### for modify : go to : FreeCAD >Menu >Tools >Edit parameters... >BaseApp/Preferences/Macros/FCMmacros/FCInfo ####
##
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"Version", __Version__ + " (" + __Date__ + ")")
##
global seTPositionFlyRightLeft #; seTPositionFlyRightLeft = 2 # 1 = fly, 2 = RightDock other= LeftDock
seTPositionFlyRightLeft = FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).GetInt(u"seTPositionFlyRightLeft")
if seTPositionFlyRightLeft == 0: seTPositionFlyRightLeft = 1
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetInt(u"seTPositionFlyRightLeft", seTPositionFlyRightLeft) #*1, 2, other
##
global seTWidgetPosition #; seTWidgetPosition = 0 # position the widget Left or Right
seTWidgetPosition = FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).GetBool(u"seTWidgetPosition")
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetBool(u"seTWidgetPosition", seTWidgetPosition) # True or False
##
global switchQFileDialogMint # special LinuxMint
switchQFileDialogMint = FreeCAD.ParamGet("User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).GetBool("switchQFileDialogMint")
if switchQFileDialogMint == 0:
FreeCAD.ParamGet("User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetBool("switchQFileDialogMint", switchQFileDialogMint)
try:
if os.uname()[1] == "mint":
switchQFileDialogMint = 1
FreeCAD.ParamGet("User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetBool("switchQFileDialogMint", switchQFileDialogMint) #*Special Mint
except Exception:
None
##
global setPathLatestDirectory #; setPathLatestDirectory = "C:\ ???"
setPathLatestDirectory = FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).GetString(u"setPathLatestDirectory")
if setPathLatestDirectory == "": setPathLatestDirectory = path
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"setPathLatestDirectory", setPathLatestDirectory) #*"C:\ ???"
##
#### Configuration end ################################################
##
try:
_fromUtf8 = QtCore.QString.fromUtf8
except AttributeError:
def _fromUtf8(s):
return s
try:
_encoding = QtGui.QApplication.UnicodeUTF8
def _translate(context, text, disambig):
return QtGui.QApplication.translate(context, text, disambig, _encoding)
except AttributeError:
def _translate(context, text, disambig):
return QtGui.QApplication.translate(context, text, disambig)
def errorDialog(msg):
diag = QtWidgets.QMessageBox(QtWidgets.QMessageBox.Critical,u"Error Message",msg )
diag.setWindowFlags(QtCore.Qt.WindowStaysOnTopHint) # PySide #cette fonction met la fenetre en avant
# diag.setWindowModality(QtCore.Qt.ApplicationModal) # la fonction a ete desactivee pour favoriser "WindowStaysOnTopHint"
diag.exec_()
class Ui_MainWindow(object):
def setupUi(self, MainWindow):
global path
global numberSpires
global rayon
global pas
global precision
global typeLine
global helixS
global pasSpire
global radiusS
global spireReverse
global nomF
global zoom
global sel
global Direction_Distance
global seTPositionFlyRightLeft
global seTWidgetPosition
self.window = MainWindow
####
if seTPositionFlyRightLeft == 1:
MainWindow.setObjectName(_fromUtf8(u"MainWindow")) # volant
# MainWindow.resize(500, 503)
# MainWindow.setMinimumSize(QtCore.QSize(500, 503))
#MainWindow.setMaximumSize(QtCore.QSize(380, 590))
#MainWindow.move(1300, 120) # deplace la fenetre
# MainWindow.setMinimumSize(QtCore.QSize(250, 600))
# MainWindow.resize(300, 650)
# MainWindow.setGeometry(960, 160, 270, 660)
# MainWindow.setMaximumSize(QtCore.QSize(270, 660))
self.centralWidget = QtWidgets.QWidget(MainWindow)
###################
grid = QtWidgets.QGridLayout()
self.centralWidget.setLayout(grid)
####
self.scrollArea = QtWidgets.QScrollArea(self.centralWidget) # cadre scrollarea contenant le widget GUI
self.scrollArea.setVerticalScrollBarPolicy(QtCore.Qt.ScrollBarAsNeeded)
self.scrollArea.setWidgetResizable(True)
grid.addWidget(self.scrollArea, 0, 0)
vbox = QtWidgets.QVBoxLayout()
self.scrollArea.setLayout(vbox)
####
self.scrollAreaWidgetContents_2 = QtWidgets.QWidget() #widget contenant le GUI
vbox.addWidget(self.scrollAreaWidgetContents_2)
vbox = QtWidgets.QVBoxLayout()
self.scrollAreaWidgetContents_2.setLayout(vbox)
###################
self.groupBox0 = QtWidgets.QGroupBox() #self.centralWidget
self.groupBox0.setFlat(False)
self.groupBox_01 = QtWidgets.QGroupBox() #self.groupBox0
self.groupBox_01.setFlat(False)
self.DS_Numb_Spires = QtWidgets.QSpinBox()
self.DS_Numb_Spires.setMinimum(1)
self.DS_Numb_Spires.setMaximum(9999999)
self.DS_Numb_Spires.setValue(numberSpires)
self.DS_Numb_Spires.valueChanged.connect(self.on_DS_Numb_Spires) #connection doubleSpinBox
self.DS_Pas_Spring = QtWidgets.QDoubleSpinBox()
self.DS_Pas_Spring.setDecimals(3)
# self.DS_Pas_Spring.setMinimum(0.001)
self.DS_Pas_Spring.setMaximum(9999999.99)
self.DS_Pas_Spring.setValue(pas)
self.DS_Pas_Spring.valueChanged.connect(self.on_DS_Pas_Spring) #connection doubleSpinBox
self.DS_Radius_Sping = QtWidgets.QDoubleSpinBox()
self.DS_Radius_Sping.setDecimals(3)
# self.DS_Radius_Sping.setMinimum(0.001)
self.DS_Radius_Sping.setMaximum(9999999.99)
self.DS_Radius_Sping.setValue(rayon)
self.DS_Radius_Sping.valueChanged.connect(self.on_DS_Radius_Sping) #connection doubleSpinBox
self.DS_Precision_Turn = QtWidgets.QSpinBox()
self.DS_Precision_Turn.setMinimum(1)
self.DS_Precision_Turn.setMaximum(360)
self.DS_Precision_Turn.setValue(precision)
self.DS_Precision_Turn.valueChanged.connect(self.on_DS_Precision_Turn) #connection doubleSpinBox
self.DS_Radius_2_Cone = QtWidgets.QDoubleSpinBox()
self.DS_Radius_2_Cone.setEnabled(False)
self.DS_Radius_2_Cone.setDecimals(3)
self.DS_Radius_2_Cone.setMaximum(9999999.99)
# self.DS_Radius_2_Cone.setMinimum(rayon)
self.DS_Radius_2_Cone.setValue(rayon)
self.DS_Radius_2_Cone.valueChanged.connect(self.on_DS_Radius_2_Cone) # connection
self.CH_Cone = QtWidgets.QCheckBox()
self.CH_Cone.setEnabled(True)
self.CH_Cone.clicked.connect(self.on_CH_Cone) # connection
self.LAB_Numb_Spires = QtWidgets.QLabel()
self.LAB_Pas_Spring = QtWidgets.QLabel()
self.LAB_Radius_Spring = QtWidgets.QLabel()
self.LAB_Precision_Turn = QtWidgets.QLabel()
self.LAB_Radius_2_Cone = QtWidgets.QLabel()
self.LAB_Radius_2_Cone.setVisible(False)
self.SP_Begin_Angle = QtWidgets.QSpinBox()
self.SP_Begin_Angle.setEnabled(False)
self.SP_Begin_Angle.setMinimum(0)
self.SP_Begin_Angle.setMaximum(360)
self.SP_Begin_Angle.setValue(0)
self.SP_Begin_Angle.valueChanged.connect(self.on_SP_Begin_Angle) # connection
self.SP_End_Angle = QtWidgets.QSpinBox()
self.SP_End_Angle.setEnabled(False)
self.SP_End_Angle.setMinimum(1)
self.SP_End_Angle.setMaximum(360)
self.SP_End_Angle.setValue(360)
self.SP_End_Angle.valueChanged.connect(self.on_SP_End_Angle) # connection
self.LAB_Begin_Angle = QtWidgets.QLabel()
self.LAB_End_Angle = QtWidgets.QLabel()
self.CB_B_E_Angle = QtWidgets.QCheckBox()
self.CB_B_E_Angle.clicked.connect(self.on_CB_B_E_Angle) # connection radioButton
####
self.groupBox_02 = QtWidgets.QGroupBox()
self.RA_Wire = QtWidgets.QRadioButton()
# self.RA_Wire.setChecked(True)
self.RA_Wire.setIcon(QtGui.QIcon.fromTheme("Draft",QtGui.QIcon(":/icons/Draft_Wire.svg")))
self.RA_Wire.clicked.connect(self.on_RA_Wire) #connection radioButton
self.RA_BSpline = QtWidgets.QRadioButton()
self.RA_BSpline.setChecked(True)
self.RA_BSpline.setIcon(QtGui.QIcon.fromTheme("Draft",QtGui.QIcon(":/icons/Draft_BSpline.svg")))
self.RA_BSpline.clicked.connect(self.on_RA_BSpline) #connection radioButton
self.CH_Points = QtWidgets.QCheckBox()
self.CH_Points.setEnabled(True)
# self.CH_Points.setStatusTip(_fromUtf8(""))
self.CH_Points.setChecked(False)
self.CH_Points.setIcon(QtGui.QIcon.fromTheme("Draft",QtGui.QIcon(":/icons/Draft_Point.svg")))
self.CH_Points.clicked.connect(self.on_CH_Points) #
self.CH_Reverse = QtWidgets.QCheckBox()
self.CH_Reverse.setEnabled(True)
# self.CH_Reverse.setStatusTip(_fromUtf8(""))
self.CH_Reverse.setChecked(False)
self.CH_Reverse.clicked.connect(self.on_CH_Reverse) #
####
self.groupBox_03 = QtWidgets.QGroupBox()
self.PB_Adapt_Radius = QtWidgets.QPushButton()
self.PB_Adapt_Radius.setEnabled(False)
self.PB_Adapt_Radius.clicked.connect(self.on_PB_Adapt_Radius) #
self.PB_Center_Point = QtWidgets.QPushButton()
self.PB_Center_Point.setEnabled(False)
self.PB_Center_Point.clicked.connect(self.on_PB_Center_Point) #
self.CB_Position = QtWidgets.QCheckBox()
self.CB_Position.setEnabled(False)
self.CB_Position.clicked.connect(self.on_CB_Position) #
self.PB_CreaCircle = QtWidgets.QPushButton()
self.PB_CreaCircle.setEnabled(False)
self.PB_CreaCircle.clicked.connect(self.on_PB_CreaCircle) #
####
self.groupBox_04 = QtWidgets.QGroupBox()
self.groupBox_04.setEnabled(False)
#self.groupBox_04.setCheckable(True)
#self.groupBox_04.setChecked(False)
self.groupBox_04.setStyleSheet("QGroupBox {background-color: QPalette.Base}") # origin system
self.PB_Begin_End = QtWidgets.QPushButton()
self.PB_Begin_End.clicked.connect(self.on_PB_Begin_End) # connection
self.PB_Reverse_Spr = QtWidgets.QPushButton()
self.PB_Reverse_Spr.clicked.connect(self.on_PB_Reverse_Spr) # connection
self.DS_horizontalSlider = QtWidgets.QDoubleSpinBox()
self.DS_horizontalSlider.setDecimals(1)
self.DS_horizontalSlider.setMinimum(0)
self.DS_horizontalSlider.setMaximum(9999999999.0)
self.DS_horizontalSlider.setValue(0)
self.DS_horizontalSlider.setSingleStep(Direction_Distance)
self.DS_horizontalSlider.stepUp()
#self.DS_horizontalSlider.stepDown()
self.DS_horizontalSlider.valueChanged.connect(self.on_DS_horizontalSlider) #connection doubleSpinBox
self.PB_Reverse_Com = QtWidgets.QPushButton()
self.PB_Reverse_Com.clicked.connect(self.on_PB_Reverse_Com)
self.horizontalSlider = QtWidgets.QSlider()
self.horizontalSlider.setMaximum(100)
self.horizontalSlider.setMinimum(0)
self.horizontalSlider.setSliderPosition(0)
self.horizontalSlider.setSingleStep(Direction_Distance)
self.horizontalSlider.setOrientation(QtCore.Qt.Horizontal)
self.horizontalSlider.valueChanged.connect(self.on_horizontal_slider) # connection
####
self.groupBox_05 = QtWidgets.QGroupBox()
self.groupBox_05.setCheckable(False)
self.groupBox_05.setChecked(False)
self.SP_Numbering_Spire = QtWidgets.QSpinBox()
self.SP_Numbering_Spire.setMinimum(1)
self.SP_Numbering_Spire.setMaximum(numberSpires)
self.SP_Numbering_Spire.setPrefix("Num: ")
self.SP_Numbering_Spire.valueChanged.connect(self.on_S_Numbering_Spire) #connection SpinBox
self.CH_Smooting = QtWidgets.QCheckBox()
self.CH_Smooting.setEnabled(True)
self.CH_Smooting.clicked.connect(self.on_CH_Smooting) # connection
self.SP_Lissage = QtWidgets.QSpinBox()
self.SP_Lissage.setVisible(False)
self.SP_Lissage.setMinimum(0)
self.SP_Lissage.setMaximum(int(360/precision)-1)
self.SP_Lissage.valueChanged.connect(self.on_S_Lissage) #connection SpinBox
self.DS_Pas_Spire = QtWidgets.QDoubleSpinBox()
self.DS_Pas_Spire.setValue(0) #pas
self.DS_Pas_Spire.setDecimals(3)
self.DS_Pas_Spire.setMaximum(9999999.99)
self.DS_Pas_Spire.valueChanged.connect(self.on_DS_Pas_Spire) #connection doubleSpinBox
self.PU_To_Pas = QtWidgets.QPushButton()
self.PU_To_Pas.clicked.connect(self.on_PU_To_Pas) # connection
self.DS_Radius_Spire = QtWidgets.QDoubleSpinBox()
self.DS_Radius_Spire.setDecimals(3)
self.DS_Radius_Spire.setValue(0) #rayon
# self.DS_Radius_Spire.setMinimum(0.001)
self.DS_Radius_Spire.setMaximum(9999999.99)
self.DS_Radius_Spire.valueChanged.connect(self.on_DS_Radius_Spire) # connection doubleSpinBox
self.PU_To_Radius = QtWidgets.QPushButton()
self.PU_To_Radius.clicked.connect(self.on_PU_To_Radius) # connection
# section progressBar 1
self.PBA_progressBar = QtWidgets.QProgressBar()
self.PBA_progressBar.setCursor(QtCore.Qt.WaitCursor)
self.PBA_progressBar.setValue(0)
self.PBA_progressBar.setVisible(False)
self.PBA_progressBar.setOrientation(QtCore.Qt.Horizontal)
self.PBA_progressBar.setAlignment(QtCore.Qt.AlignCenter)
self.LAB_Numbering_Spire = QtWidgets.QLabel()
self.LAB_Pas_Spire = QtWidgets.QLabel()
self.LAB_Radius_Spire = QtWidgets.QLabel()
self.PU_Accept_Value = QtWidgets.QPushButton()
self.PU_Accept_Value.setIcon(QIcon(QApplication.style().standardIcon(QStyle.SP_DialogApplyButton))) #
self.PU_Accept_Value.clicked.connect(self.on_PU_Accept_Value) # connection
self.PB_Clear = QtWidgets.QPushButton()
self.PB_Clear.setIcon(QIcon(QApplication.style().standardIcon(QStyle.SP_DialogResetButton))) #
self.PB_Clear.clicked.connect(self.on_PB_Clear) # connection
self.PB_Zoom = QtWidgets.QPushButton()
self.PB_Zoom.setIcon(QIcon(QApplication.style().standardIcon(QStyle.SP_FileDialogContentsView))) #
self.PB_Zoom.clicked.connect(self.on_PB_Zoom) # connection
self.textEdit = QtWidgets.QTextEdit()
self.textEdit.setTextInteractionFlags(QtCore.Qt.TextSelectableByMouse)
####
self.groupBox_06 = QtWidgets.QGroupBox()
#self.label_11_Name = QtWidgets.QLabel()
self.PU_Read = QtWidgets.QPushButton()
self.image_02 = path+"FCSpring_Helix_Variable_Icon_02.png" # image
icon02 = QtGui.QIcon() #
icon02.addPixmap(QtGui.QPixmap(self.image_02),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Read.setIcon(icon02) #
self.PU_Read.clicked.connect(self.on_PU_Read) # connection
self.PU_Save = QtWidgets.QPushButton()
self.image_03 = path+"FCSpring_Helix_Variable_Icon_03.png" # image
icon03 = QtGui.QIcon() #
icon03.addPixmap(QtGui.QPixmap(self.image_03),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Save.setIcon(icon03) #
self.PU_Save.clicked.connect(self.on_PU_Save)
self.PU_Read_Coord = QtWidgets.QPushButton()
self.PU_Read_Coord.setEnabled(True)
self.image_02b = path+"FCSpring_Helix_Variable_Icon_02b.png" # image
icon02b = QtGui.QIcon() #
icon02b.addPixmap(QtGui.QPixmap(self.image_02b),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Read_Coord.setIcon(icon02b) #
self.PU_Read_Coord.clicked.connect(self.on_PU_Read_Coord) # connection
self.PU_Save_Coord = QtWidgets.QPushButton()
self.image_03b = path+"FCSpring_Helix_Variable_Icon_03b.png" # image
icon03b = QtGui.QIcon() #
icon03b.addPixmap(QtGui.QPixmap(self.image_03b),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Save_Coord.setIcon(icon03b) #
self.PU_Save_Coord.clicked.connect(self.on_PU_Save_Coord) # connection
####
self.CB_05_Position = QtWidgets.QCheckBox()
if seTPositionFlyRightLeft == 1:
self.CB_05_Position.setVisible(False)
self.CB_05_Position.setChecked(seTWidgetPosition)
self.CB_05_Position.clicked.connect(self.on_CB_05_Position) #connection checkBox
self.PU_Quit = QtWidgets.QPushButton()
self.image_04 = path+"FCSpring_Helix_Variable_Icon_04.png" # image
icon04 = QtGui.QIcon() #
icon04.addPixmap(QtGui.QPixmap(self.image_04),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Quit.setIcon(icon04) #
self.PU_Quit.clicked.connect(self.on_PU_Quit) # connection
self.PU_Reset = QtWidgets.QPushButton()
self.image_05 = path+"FCSpring_Helix_Variable_Icon_05.png" # image
icon05 = QtGui.QIcon() #
icon05.addPixmap(QtGui.QPixmap(self.image_05),QtGui.QIcon.Normal, QtGui.QIcon.Off) #
self.PU_Reset.setIcon(icon05) #
self.PU_Reset.clicked.connect(self.on_PU_Reset) # connection
self.PU_Launch = QtWidgets.QPushButton()
self.PU_Launch.setIcon(QIcon(QApplication.style().standardIcon(QStyle.SP_DialogOkButton))) #
self.PU_Launch.clicked.connect(self.on_PU_Launch) # connection
self.PU_Help = QtWidgets.QPushButton()
self.PU_Help.setIcon(QIcon(QApplication.style().standardIcon(QStyle.SP_MessageBoxQuestion))) # image
self.PU_Help.clicked.connect(self.on_PU_Help) # connection
#### Layout debut ########################
self.grid0 = QtWidgets.QGridLayout() #self.centralWidget
self.grid0.setContentsMargins(10, 10, 10, 10)
self.grid0.addWidget(self.groupBox0, 0, 0, 1, 1)
####
self.grid_00 = QtWidgets.QGridLayout(self.groupBox0)
#self.grid_00.setContentsMargins(10, 10, 10, 10)
self.grid_00.addWidget(self.groupBox_01, 0, 0, 1, 1)
vbox.addWidget(self.groupBox0) # englobe le cadre principal (titre + date)
####
self.grid_01 = QtWidgets.QGridLayout(self.groupBox_01)
#self.grid_01.setContentsMargins(10, 10, 10, 10)
self.grid_01.addWidget(self.DS_Numb_Spires, 0, 0, 1, 1)
self.grid_01.addWidget(self.LAB_Numb_Spires, 0, 1, 1, 1)
self.grid_01.addWidget(self.DS_Pas_Spring, 0, 2, 1, 1)
self.grid_01.addWidget(self.LAB_Pas_Spring, 0, 3, 1, 1)
self.grid_01.addWidget(self.DS_Radius_Sping, 2, 0, 1, 1)
self.grid_01.addWidget(self.LAB_Radius_Spring, 2, 1, 1, 2)
self.grid_01.addWidget(self.DS_Precision_Turn, 2, 2, 1, 1)
self.grid_01.addWidget(self.LAB_Precision_Turn, 2, 3, 1, 1)
self.grid_01.addWidget(self.DS_Radius_2_Cone, 4, 0, 1, 1)
self.grid_01.addWidget(self.CH_Cone, 4, 1, 1, 1)
self.grid_01.addWidget(self.LAB_Radius_2_Cone, 4, 2, 1, 1)
self.grid_01.addWidget(self.SP_Begin_Angle, 5, 0, 1, 1)
self.grid_01.addWidget(self.LAB_Begin_Angle, 5, 1, 1, 1)
self.grid_01.addWidget(self.SP_End_Angle, 5, 2, 1, 1)
self.grid_01.addWidget(self.LAB_End_Angle, 5, 3, 1, 1)
self.grid_01.addWidget(self.CB_B_E_Angle, 4, 2, 1, 1)
####
self.grid_00.addWidget(self.groupBox_02, 1, 0, 1, 1)
self.grid_02 = QtWidgets.QGridLayout(self.groupBox_02)
#self.grid_02.setContentsMargins(10, 10, 10, 10)
self.grid_02.addWidget(self.RA_BSpline, 0, 0, 1, 1)
self.grid_02.addWidget(self.RA_Wire, 0, 1, 1, 1)
self.grid_02.addWidget(self.CH_Points, 0, 2, 1, 1)
self.grid_02.addWidget(self.CH_Reverse, 0, 3, 1, 1)
####
self.grid_00.addWidget(self.groupBox_03, 2, 0, 1, 1)
self.grid_03 = QtWidgets.QGridLayout(self.groupBox_03)
#self.grid_03.setContentsMargins(10, 10, 10, 10)
self.grid_03.addWidget(self.PB_Adapt_Radius, 0, 0, 1, 1)
self.grid_03.addWidget(self.PB_Center_Point, 0, 1, 1, 1)
self.grid_03.addWidget(self.CB_Position, 0, 2, 1, 1)
self.grid_03.addWidget(self.PB_CreaCircle, 0, 3, 1, 1)
####
self.grid_00.addWidget(self.groupBox_04, 3, 0, 1, 1)
self.grid_04 = QtWidgets.QGridLayout(self.groupBox_04)
#self.grid_04.setContentsMargins(10, 10, 10, 10)
self.grid_04.addWidget(self.PB_Begin_End, 0, 0, 1, 1)
self.grid_04.addWidget(self.PB_Reverse_Spr, 0, 1, 1, 1)
self.grid_04.addWidget(self.DS_horizontalSlider, 0, 2, 1, 1)
self.grid_04.addWidget(self.PB_Reverse_Com, 0, 3, 1, 1)
self.grid_04.addWidget(self.horizontalSlider, 1, 0, 1, 4)
####
self.grid_00.addWidget(self.groupBox_05, 4, 0, 1, 1)
self.grid_05 = QtWidgets.QGridLayout(self.groupBox_05)
#self.grid_05.setContentsMargins(10, 10, 10, 10)
self.grid_05.addWidget(self.SP_Numbering_Spire, 0, 0, 1, 1)
self.grid_05.addWidget(self.LAB_Numbering_Spire, 0, 1, 1, 1)
self.grid_05.addWidget(self.SP_Lissage, 0, 3, 1, 1)
self.grid_05.addWidget(self.CH_Smooting, 0, 3, 1, 1)
self.grid_05.addWidget(self.DS_Pas_Spire, 1, 0, 1, 1)
self.grid_05.addWidget(self.LAB_Pas_Spire, 1, 1, 1, 1)
self.grid_05.addWidget(self.PU_To_Pas, 1, 3, 1, 1)
self.grid_05.addWidget(self.DS_Radius_Spire, 2, 0, 1, 1)
self.grid_05.addWidget(self.LAB_Radius_Spire, 2, 1, 1, 1)
self.grid_05.addWidget(self.PU_To_Radius, 2, 3, 1, 1)
####
self.grid_05.addWidget(self.PU_Accept_Value, 3, 0, 1, 4)
self.grid_05.addWidget(self.PBA_progressBar, 4, 0, 1, 4)
self.grid_05.addWidget(self.textEdit, 5, 0, 2, 3)
self.grid_05.addWidget(self.PB_Clear, 5, 3, 1, 1)
self.grid_05.addWidget(self.PB_Zoom,6 ,3, 1, 1)
####
self.grid_00.addWidget(self.groupBox_06, 5, 0, 1, 1)
self.grid_06 = QtWidgets.QGridLayout(self.groupBox_06)
#self.grid_06.setContentsMargins(10, 10, 10, 10)
self.grid_06.addWidget(self.PU_Read, 0, 0, 1, 2)
self.grid_06.addWidget(self.PU_Save, 0, 2, 1, 2)
self.grid_06.addWidget(self.PU_Read_Coord, 1, 0, 1, 2)
self.grid_06.addWidget(self.PU_Save_Coord, 1, 2, 1, 2)
##
self.grid_06.addWidget(self.CB_05_Position, 2, 0)
##
self.grid_06.addWidget(self.PU_Quit, 3, 0, 1, 1)
self.grid_06.addWidget(self.PU_Reset, 3, 1, 1, 1)
self.grid_06.addWidget(self.PU_Launch,3, 2, 1, 1)
self.grid_06.addWidget(self.PU_Help, 3, 3, 1, 1)
#### GridLayout fin
###########################################################scrollArea
self.scrollArea.setWidget(self.scrollAreaWidgetContents_2)
###########################################################scrollArea
if seTPositionFlyRightLeft == 1: # 1=MainWindow separate
MainWindow.setWindowTitle(__Title__ + u" rmu (" + __Version__ + ") (" + __Date__ + ")")
MainWindow.setCentralWidget(self.centralWidget)
#MainWindow.move(1000, 120) # deplace la fenetre
else:
MainWindow.setWindowTitle(__Title__ + u" rmu (" + __Version__ + ") (" + __Date__ + ")")
MainWindow.setWidget(self.centralWidget)
self.retranslateUi(MainWindow)
QtCore.QMetaObject.connectSlotsByName(MainWindow)
def retranslateUi(self, MainWindow):
global sel
MainWindow.setWindowFlags(QtCore.Qt.WindowStaysOnTopHint) # PySide cette fonction met la fenetre en avant
MainWindow.setWindowIcon(QtGui.QIcon(path+'FCSpring_Helix_Variable.png'))# change l'icone de la fenetre principale
MainWindow.setWindowTitle("FCSpring Helix Variable")
####
self.groupBox0.setTitle("ver : " + __Version__ + " : " + __Date__ + " (rmu)" )
self.groupBox_01.setTitle(_fromUtf8("Configure"))
self.DS_Numb_Spires.setToolTip(_fromUtf8("Number total of coil of the spring"))
self.DS_Numb_Spires.setSuffix(" coils")
self.LAB_Numb_Spires.setText(_fromUtf8("Number of coil"))
self.LAB_Numb_Spires.setToolTip(_fromUtf8("Number total of coil of the spring"))
self.LAB_Pas_Spring.setText(_fromUtf8("Pitch of spring"))
self.LAB_Pas_Spring.setToolTip(_fromUtf8("Pitch of spring (distance between two vertices)"))
self.DS_Pas_Spring.setToolTip(_fromUtf8("Pitch of spring (distance between two vertices)"))
self.DS_Pas_Spring.setSuffix(" mm")
self.DS_Radius_Sping.setToolTip(_fromUtf8("Radius of spring"))
self.DS_Radius_Sping.setSuffix(" mm")
self.LAB_Radius_Spring.setText(_fromUtf8("Radius of spring"))
self.LAB_Radius_Spring.setToolTip(_fromUtf8("Radius of spring"))
self.DS_Precision_Turn.setSuffix(" ( " + str(int(360/precision)) + " points )")
self.DS_Precision_Turn.setToolTip(_fromUtf8("Precision for the line (points = (360/precision))"+"\n"+
"Actual: " + str(int(360/precision)) + " points for 1 turn"+"\n"+
"Loading a file or angle checked the value displayd change color in blue just to inform"))
self.LAB_Precision_Turn.setText(_fromUtf8("Precision"))
self.LAB_Precision_Turn.setToolTip(_fromUtf8("The precision is the number point (360/precision) for create one turn of the spring"+"\n"+
"Loading a file or angle checked the value displayed change color in blue just to inform"))
self.DS_Radius_2_Cone.setToolTip(_fromUtf8("Radius for make a cone"+"\n"+
"This radius is always greater than the principal radius"))
self.DS_Radius_2_Cone.setSuffix(" mm")
self.CH_Cone.setText(_fromUtf8("Spring conical"))
self.CH_Cone.setToolTip(_fromUtf8("Check for create one conical helix"))
self.LAB_Radius_2_Cone.setText(_fromUtf8("Radius 2 of the cone"))
self.SP_Begin_Angle.setToolTip(_fromUtf8("Begin angle first coil"))
self.SP_Begin_Angle.setSuffix(_fromUtf8(" deg"))
self.LAB_Begin_Angle.setText(_fromUtf8("Begin"))
self.SP_End_Angle.setToolTip(_fromUtf8("End angle ultimate coil"))
self.SP_End_Angle.setStatusTip(_fromUtf8("End angle to ultimate coil"))
self.SP_End_Angle.setSuffix(_fromUtf8(" deg"))
self.LAB_End_Angle.setText(_fromUtf8("End"))
self.CB_B_E_Angle.setText(_fromUtf8("Angles")) #Beg/End
self.CB_B_E_Angle.setToolTip(_fromUtf8("Check the option modify to begin and ultimate angle of coils"+"\n"+
"The final result depend on the level of precision given"+"\n"+
"Optimal : 1 , Precision = 360 points (1 point by degree)"))
#####
self.groupBox_02.setTitle(_fromUtf8("Type line"))
self.RA_BSpline.setToolTip(_fromUtf8("Type line BSpline"))
self.RA_BSpline.setText(_fromUtf8("BSpline"))
self.RA_Wire.setText(_fromUtf8("Wire"))
self.RA_Wire.setToolTip(_fromUtf8("Type line Wire"))
self.CH_Points.setToolTip(_fromUtf8("Check to create points to alls nodes of the precision of turn"))
self.CH_Points.setText(_fromUtf8("Points"))
self.CH_Reverse.setToolTip(_fromUtf8("Check to create spring clockwise direction"))
self.CH_Reverse.setText(_fromUtf8("Reverse"))
#####
self.groupBox_03.setTitle(_fromUtf8("Options"))
self.PB_Adapt_Radius.setText(_fromUtf8("Normal")) #AdpRa
self.PB_Adapt_Radius.setToolTip(_fromUtf8("Mode normal"+"\n"+
""+"\n"+
"For create the spring to the circle radius selected:"+"\n"+
"1: configure the complete spring"+"\n"+
"2: select the circle, arc ... to work"+"\n"+
" (are detected : Circle, Arc, Ellipse, Sphere, Toroid, Cone, Ellipse (minor radius))"+"\n"+
"3: push this mode Normal button (it change to Adapt Rad.)"+"\n"+
"4: push the Launch button"))#adapt radius
self.PB_Center_Point.setText(_fromUtf8("Point Mouse")) #CFace
self.PB_Center_Point.setToolTip(_fromUtf8("Create Spring to the point mouse (Default)"+"\n"+
""+"\n"+
"For create the spring to center face:"+"\n"+
"1: configure the complete spring"+"\n"+
"2: select the face to work"+"\n"+
"3: push this Point Mouse button (it change to Center Face)"+"\n"+
"4: push the Launch button"))#center face
self.CB_Position.setText(_fromUtf8("Position"))
self.CB_Position.setToolTip(_fromUtf8("Move the position of the spring selected along the axis selected "+"\n"+
""+"\n"+
"For use this option:"+"\n"+
"1: select the axis to work"+"\n"+
"2: select the spring to move (or object)"+"\n"+
"This command not verify the objects selected "
"(Give always the number selection)"+"\n"))
self.CB_Position.setText(_fromUtf8("Position"))
self.PB_CreaCircle.setText(_fromUtf8("Circle"))
self.PB_CreaCircle.setToolTip(_fromUtf8("Create a circle on 3 points selected "+"\n"+
"First select tree points "+"\n"))
#####
self.groupBox_04.setTitle(_fromUtf8("Position ( " + str(len(sel)) + " )"))
self.groupBox_04.setToolTip(_fromUtf8("Position (number selection) number of points"))
self.PB_Begin_End.setToolTip(_fromUtf8("Align the spring to begin , end or center axis "+"\n"))
self.PB_Begin_End.setText(_fromUtf8("Begin / End"))
self.PB_Reverse_Spr.setText(_fromUtf8("Reverse Spr."))
self.PB_Reverse_Spr.setToolTip(_fromUtf8("Reverse the spring on its axis "+"\n"))
self.DS_horizontalSlider.setToolTip(_fromUtf8("Placement spring along the axis"+"\n"))
self.DS_horizontalSlider.setSuffix(" mm")
self.PB_Reverse_Com.setText(_fromUtf8("Reverse Count."))
self.PB_Reverse_Com.setToolTip(_fromUtf8("Reverse the counter of the spring on its axis "+"\n"))
#####
self.groupBox_05.setTitle(_fromUtf8("Coil special dimension"))
self.groupBox_05.setToolTip(_fromUtf8("This section allows you to adjust the distance from the coil named. EX: 1 spire = 2 mm"))
self.SP_Numbering_Spire.setToolTip(_fromUtf8("Numbering of coil for 1 to max = Number of coil ("+str(numberSpires)+")"))
self.LAB_Numbering_Spire.setToolTip(_fromUtf8("Numbering of coil for 1 to max = Number of coil"))
self.LAB_Numbering_Spire.setText(_fromUtf8("Number of coil"))
self.SP_Lissage.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
self.CH_Smooting.setText(_fromUtf8("Smooting"))
self.CH_Smooting.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
self.DS_Pas_Spire.setToolTip(_fromUtf8("Pitch of the coil (The pitch is the distance betwen 2 vertices)"))
self.DS_Pas_Spire.setSuffix(" mm")
self.LAB_Pas_Spire.setToolTip(_fromUtf8("Pitch of the coil (The pitch is the distance betwen 2 vertices)"))
self.LAB_Pas_Spire.setText(_fromUtf8("Pitch of coil"))
self.PU_To_Pas.setText(str(pas) + " mm")
self.PU_To_Pas.setToolTip(_fromUtf8("Align the value to pitch global configured"))
self.DS_Radius_Spire.setToolTip(_fromUtf8("Radius of coil "))
self.DS_Radius_Spire.setSuffix(" mm")
self.PU_To_Radius.setText(str(rayon) + " mm")
self.PU_To_Radius.setToolTip(_fromUtf8("Align the value to radius global configured"))
self.LAB_Radius_Spire.setToolTip(_fromUtf8("Radius of coil "))
self.LAB_Radius_Spire.setText(_fromUtf8("Radius of coil"))
#self.PBA_progressBar.setToolTip(_fromUtf8(" "))
self.PU_Accept_Value.setText(_fromUtf8("Accept the value modified"))
self.PU_Accept_Value.setToolTip(_fromUtf8("Accept the value for the coil "))
self.PB_Clear.setText(_fromUtf8("Clear"))
self.PB_Clear.setToolTip(_fromUtf8("Clear text edit"))
self.PB_Zoom.setText(_fromUtf8("Zoom"))
self.PB_Zoom.setToolTip(_fromUtf8("Zoom the text edit window"))
self.textEdit.setText(_fromUtf8(""))
self.textEdit.setToolTip(_fromUtf8("List alls modification of coil "))
####
self.groupBox_06.setTitle(_fromUtf8("Command"))
self.groupBox_06.setToolTip(_fromUtf8("Menu command"))
self.PU_Read.setText(_fromUtf8("Load"))
self.PU_Read.setToolTip(_fromUtf8("Read the file "))
self.PU_Save.setText(_fromUtf8("Save"))
self.PU_Save.setToolTip(_fromUtf8("Save the file"))
self.PU_Read_Coord.setText(_fromUtf8("Load coordinates"))
self.PU_Read_Coord.setToolTip(_fromUtf8("Load the coordinates file "))
self.PU_Save_Coord.setText(_fromUtf8("Save coordinates"))
self.PU_Save_Coord.setToolTip(_fromUtf8("Save the coordinates file "))
##
self.CB_05_Position.setText(u"Left/Right")
self.CB_05_Position.setToolTip(u"Change the window macro position Right of Left")
##
self.PU_Quit.setText(_fromUtf8("Quit"))
self.PU_Quit.setToolTip(_fromUtf8("Quit the macro"))
self.PU_Reset.setText(_fromUtf8("Reset"))
self.PU_Reset.setToolTip(_fromUtf8("Reset complete the data "))
self.PU_Launch.setText(_fromUtf8("Launch "))
self.PU_Launch.setToolTip(_fromUtf8("Launch the macro and create the spring"))
self.PU_Help.setText(_fromUtf8("Help "))
self.PU_Help.setToolTip(_fromUtf8("Dislay the wiki page in the FreeCAD browser"))
####
def on_PU_Reset(self, zero = 0): # Reset 0=Reset total 1=Reset mise a jour
global numberSpires
global rayon
global pas
global precision
global typeLine
global affPoint
global helixS
global numberSpiresModified
global pasSpire
global radiusS
global rayonSpire
global affPoint
global debutAngle
global finAngle
global modifyAngle
global radius_2_Cone
global spireConeUne
global spireConeComp
global spireReverse
global lissageSpire
global lissageS
global fichierOpen
global nomF
global zoom
global pointsDirection
global Direction_Begin
global plr
global sel
global switchAdaptRadius
global centerFaceOrPoint
global selectedCircle
if zero == 0: # 0 = Reset total
numberSpires = 10
rayon = 20.0
pas = 15.0
precision = 5.0
typeLine = 0
affPoint = 0
helixS = 0.0
radiusS = 0.0
numberSpiresModified = 1
pasSpire = 0 #pas
rayonSpire = 0 #rayon
modifyAngle = 0
radius_2_Cone = rayon
fichierOpen = 0
nomF = "Name File"
self.DS_Numb_Spires.setValue(numberSpires)
self.DS_Radius_Sping.setValue(rayon)
self.DS_Pas_Spring.setValue(pas)
self.DS_Precision_Turn.setValue(precision)
self.DS_Precision_Turn.setEnabled(True)
self.DS_Precision_Turn.setToolTip(_fromUtf8("Precision for the line (points = (360/precision))"+"\n"+
"Actual: " + str(int(360/precision)) + " points for 1 turn"+"\n"+
"Loading a file or angle checked the value displayd change color in blue just to inform"))
self.LAB_Numb_Spires.setText("Number of coil")
############### font and color Label
font = QtGui.QFont()
self.LAB_Precision_Turn.setFont(font)
self.LAB_Precision_Turn.setStyleSheet("QLabel {Base}")
############### font and color
############### font and color
palette = QtGui.QPalette()
brush = QtGui.QBrush(QtGui.QColor("Base"))
brush.setStyle(QtCore.Qt.SolidPattern)
palette.setBrush(QtGui.QPalette.Active, QtGui.QPalette.Text, brush)
self.DS_Precision_Turn.setPalette(palette)
font = QtGui.QFont()
font.setBold(False)
self.DS_Precision_Turn.setFont(font)
###############
self.CB_B_E_Angle.setChecked(False)
self.SP_Begin_Angle.setEnabled(False)
debutAngle = 0
self.SP_Begin_Angle.setValue(debutAngle)
self.SP_End_Angle.setEnabled(False)
finAngle = 360
self.SP_End_Angle.setValue(finAngle)
modifyAngle = 0
self.CH_Points.setChecked(False)
affPoint = 0
self.CH_Reverse.setChecked(False)
spireReverse = 0
###############
sel = ""
del pointsDirection[:]
plr = ""
Direction_Begin = 0
switchAdaptRadius = 0
self.PB_Adapt_Radius.setEnabled(False)
self.PB_Adapt_Radius.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
self.PB_Adapt_Radius.setText("Normal")
self.PB_Center_Point.setEnabled(False)
self.PB_Center_Point.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
centerFaceOrPoint = 0
self.PB_Center_Point.setText(_fromUtf8("Point Mouse"))
self.CB_Position.setEnabled(False)
self.CB_Position.setStyleSheet("QCheckBox {background-color: QPalette.Base}") # origin system
self.PB_CreaCircle.setEnabled(False)
self.PB_CreaCircle.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
del selectedCircle[:]
self.DS_horizontalSlider.setValue(0)
self.horizontalSlider.setValue(0)
self.groupBox_04.setEnabled(False)
self.groupBox_04.setStyleSheet("QGroupBox {background-color: QPalette.Base}") # origin system
self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")")
###############
self.SP_Numbering_Spire.setValue(numberSpiresModified)
self.SP_Numbering_Spire.setMaximum(numberSpires)
self.DS_Pas_Spire.setValue(0) #pas
self.DS_Radius_Spire.setValue(0) #rayon
self.textEdit.setText("")
self.textEdit.clear()
lissageSpire = 0
self.SP_Lissage.setValue(0)
self.SP_Lissage.setVisible(False)
self.SP_Lissage.setMaximum(int(360/precision)-1)
self.SP_Lissage.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
self.CH_Smooting.setChecked(False)
self.CH_Smooting.setVisible(True)
self.CH_Smooting.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
lissageS = []
del lissageS[:]
lissageS = numberSpires*[0]
self.SP_Lissage.setValue(0)
self.PBA_progressBar.setVisible(False)
self.PU_Accept_Value.setVisible(True)
zoom = 140
self.textEdit.setGeometry(QtCore.QRect(20, zoom, 211, 51))
helixS = []
del helixS[:]
helixS = numberSpires*[pas]
radiusS = []
del radiusS[:]
radiusS = numberSpires*[rayon]
self.CH_Cone.setChecked(False)
self.DS_Radius_2_Cone.setValue(rayon)
self.DS_Radius_2_Cone.setEnabled(False)
spireConeUne = 0
spireConeComp = 0
# App.Console.PrintMessage("on_PU_Reset "+"\n")
def on_DS_Numb_Spires(self,value): # nombre de spire total
global pas
global numberSpires
numberSpires = value
a = ui
a.on_PU_Reset(1)
self.SP_Numbering_Spire.setToolTip(_fromUtf8("Numbering of coil for 1 to max = Number of spires ("+str(numberSpires)+")"))
# App.Console.PrintMessage("on_DS_Numb_Spires "+str(numberSpires)+"\n")
def on_DS_Radius_Sping(self,value): # rayon axial du ressort
global rayon
rayon = value
self.PU_To_Radius.setText(str(rayon) + " mm")
a = ui
a.on_PU_Reset(1)
# App.Console.PrintMessage("on_DS_Radius_Sping "+str(rayon)+"\n")
def on_DS_Pas_Spring(self,value): # pas (pitch) du ressort
global pas
global numberSpires
global numberSpiresModified
global pasSpire
pas = value
self.PU_To_Pas.setText(str(pas) + " mm")
a = ui
a.on_PU_Reset(1)
# App.Console.PrintMessage("on_DS_Pas_Spring "+str(pas)+"\n")
def on_DS_Precision_Turn(self,value): # " ! float " 360/precision number points for 1 turn
global precision
precision = value
############### font and color Label
font = QtGui.QFont()
self.LAB_Precision_Turn.setFont(font)
self.LAB_Precision_Turn.setStyleSheet("QLabel {Base}")
############### font and color
############### font and color
palette = QtGui.QPalette()
brush = QtGui.QBrush(QtGui.QColor("QBrush {Base}"))
brush.setStyle(QtCore.Qt.SolidPattern)
# palette.setBrush(QtGui.QPalette.Active, QtGui.QPalette.WindowText, brush)
palette.setBrush(QtGui.QPalette.Active, QtGui.QPalette.Text, brush)
self.DS_Precision_Turn.setPalette(palette)
font = QtGui.QFont()
font.setBold(False)
# font.setWeight(75)
self.DS_Precision_Turn.setFont(font)
###############
self.DS_Precision_Turn.setSuffix(" ( " + str(int(360/precision)) + " points )")
self.DS_Precision_Turn.setToolTip(_fromUtf8("Precision for the line (points = (360/precision))"+"\n"+
"Actual: " + str(int(360/precision)) + " points for 1 turn"+"\n"+
"Loading a file or angle checked the value displayd change color in blue just to inform"))
self.SP_Lissage.setMaximum(int(360/precision)-1)
self.CH_Smooting.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
# App.Console.PrintMessage("on_DS_Precision_Turn "+str(precision)+"\n")
def on_CH_Cone(self): # Cone
global radius_2_Cone
global rayon
if self.CH_Cone.isChecked():
self.DS_Radius_2_Cone.setEnabled(True)
# self.LAB_Radius_2_Cone.setVisible(True)
else:
self.DS_Radius_2_Cone.setEnabled(False)
# self.LAB_Radius_2_Cone.setVisible(False)
radius_2_Cone = rayon
self.DS_Radius_2_Cone.setValue(radius_2_Cone)
# App.Console.PrintMessage("on_CH_Cone"+"\n")
def on_SP_Begin_Angle(self,value): #
global debutAngle
debutAngle = value
# App.Console.PrintMessage("on_SP_Begin_Angle "+str(debutAngle)+"\n")
def on_SP_End_Angle(self,value): #
global finAngle
finAngle = value
# App.Console.PrintMessage("on_SP_End_Angle "+str(finAngle)+"\n")
def on_CB_B_E_Angle(self): #
global debutAngle
global finAngle
global modifyAngle
global precision
global fichierOpen
if self.CB_B_E_Angle.isChecked():
modifyAngle = 1
self.SP_Begin_Angle.setEnabled(True)
self.SP_End_Angle.setEnabled(True)
if fichierOpen == 0:
precision = 1
fichierOpen = 0
self.DS_Precision_Turn.setValue(precision)
############### font and color Label
font = QtGui.QFont()
self.LAB_Precision_Turn.setFont(font)
self.LAB_Precision_Turn.setStyleSheet("QLabel {color : #0000ff}")
############### font and color
############### font and color DoubleSpinBox
palette = QtGui.QPalette()
brush = QtGui.QBrush(QtGui.QColor( 0, 0, 255))
brush.setStyle(QtCore.Qt.SolidPattern)
# palette.setBrush(QtGui.QPalette.Active, QtGui.QPalette.WindowText, brush)
palette.setBrush(QtGui.QPalette.Active, QtGui.QPalette.Text, brush)
self.DS_Precision_Turn.setPalette(palette)
font = QtGui.QFont()
font.setBold(True)
font.setWeight(75)
self.DS_Precision_Turn.setFont(font)
###############
else:
modifyAngle = 0
# self.DS_Precision_Turn.setEnabled(True)
self.SP_Begin_Angle.setEnabled(False)
self.SP_End_Angle.setEnabled(False)
self.CB_B_E_Angle.setChecked(False)
self.SP_Begin_Angle.setEnabled(False)
debutAngle = 0
self.SP_Begin_Angle.setValue(debutAngle)
self.SP_End_Angle.setEnabled(False)
finAngle = 360
self.SP_End_Angle.setValue(finAngle)
# App.Console.PrintMessage("CB_B_E_Angle "+"\n")
def on_RA_Wire(self): #
global typeLine
typeLine = 1
# App.Console.PrintMessage("on_RA_Wire "+str(typeLine)+"\n")
def on_RA_BSpline(self): #
global typeLine
typeLine = 0
# App.Console.PrintMessage("on_RA_BSpline "+str(typeLine)+"\n")
def on_CH_Points(self): #
global affPoint
if self.CH_Points.isChecked():
affPoint = 1
else:
affPoint = 0
# App.Console.PrintMessage("on_CH_Points "+"\n")
def on_CH_Reverse(self): # reverse the rotation Rigth/Left
global spireReverse
if self.CH_Reverse.isChecked():
spireReverse = 1
else:
spireReverse = 0
# App.Console.PrintMessage("on_CH_Reverse " + str(spireReverse)+"\n")
def on_DS_Radius_2_Cone(self,value): # Diametre num 2 , Helix Conique
global rayon
global numberSpires
global helixS
global radiusS
global radius_2_Cone
global spireConeUne
global spireConeComp
global lissageS
if self.CH_Cone.isChecked():
numberSpires = self.DS_Numb_Spires.value()
numberSpires += 1
self.SP_Numbering_Spire.setMaximum(numberSpires)
helixS = []
del helixS[:]
helixS = (numberSpires)*[pas]
radiusS = []
del radiusS[:]
radiusS = (numberSpires)*[rayon]
lissageS = []
del lissageS[:]
lissageS = numberSpires*[0]
if value < rayon:
radius_2_Cone = value = rayon
radius_2_Cone = value
self.DS_Radius_2_Cone.setValue(radius_2_Cone)
if numberSpires != 1:
spireConeUne = 0
cone = (radius_2_Cone - rayon) / (numberSpires -1)# +1
for i in range(numberSpires):
radiusS[i] = rayon + (cone * (i)) #
else:
spireConeUne = 1
spireConeComp = 1
# App.Console.PrintMessage("on_DS_Radius_2_Cone "+str(radius_2_Cone)+" "+str(spireConeUne)+"\n")
####
def on_PB_Adapt_Radius(self): # Adapt circle
global switchAdaptRadius
if switchAdaptRadius == 0:
switchAdaptRadius = 1
self.PB_Adapt_Radius.setText("Adapt Rad.")
else:
switchAdaptRadius = 0
self.PB_Adapt_Radius.setText("Normal")
# App.Console.PrintMessage("on_CB_Adapt_Radius "+str(switchAdaptRadius)+"\n")
def on_PB_Center_Point(self): # Center Face or Point
global centerFaceOrPoint
if centerFaceOrPoint == 0:
centerFaceOrPoint = 1
self.PB_Center_Point.setText(_fromUtf8("Center Face"))
else:
centerFaceOrPoint = 0
self.PB_Center_Point.setText(_fromUtf8("Point Mouse"))
# App.Console.PrintMessage("on_CB_Center_Point "+str(centerFaceOrPoint)+"\n")
def on_PB_Begin_End(self): # place the spring to left center rigth
global Direction_Begin
global pointsDirection
global ressort
global coor_Z
self.horizontalSlider.setMaximum(len(pointsDirection))
ressort.Placement.Base = pointsDirection[0]
if (Direction_Begin == 0):
Direction_Begin = 1
ressort.Placement.Base = pointsDirection[0]
self.horizontalSlider.setValue(0)
elif (Direction_Begin == 1):
ressort.Placement.Base = pointsDirection[int((len(pointsDirection) / 2))]
self.horizontalSlider.setValue(int((len(pointsDirection) / 2)))
Direction_Begin = 2
elif (Direction_Begin == 2):
Direction_Begin = 0
ressort.Placement.Base = pointsDirection[-1]
self.horizontalSlider.setValue(len(pointsDirection))
FreeCAD.ActiveDocument.recompute()
# App.Console.PrintMessage("on_CB_01_Begin_End"+"\n") FreeCAD.Vector(
def on_PB_Reverse_Spr(self): # reverse the spring
global ressort
a = FreeCAD.ActiveDocument.getObject(ressort.Name).Placement
b = App.Placement(App.Vector(0.0,0.0,0.0), App.Rotation(App.Vector(0.0,1.0,0.0),180.0), App.Vector(0,0,0))
c = a.multiply(b)
FreeCAD.ActiveDocument.getObject(ressort.Name).Placement = c
# App.Console.PrintMessage("on_PB_Reverse_Spr"+"\n")
def on_DS_horizontalSlider(self,val): #
global pointsDirection
global ressort
global Direction_Distance
if len(pointsDirection) != 0:
self.DS_horizontalSlider.setSingleStep(Direction_Distance)
self.horizontalSlider.setValue(val*10)
try:
ressort.Placement.Base = FreeCAD.Vector(pointsDirection[int(val*10)])
except Exception:
None
FreeCAD.ActiveDocument.recompute()
# App.Console.PrintMessage("on_DS_horizontalSlider"+"\n")
def on_PB_Reverse_Com(self): # reverse the compteur
global pointsDirection
global ressort
pointsDirection.reverse()
self.DS_horizontalSlider.setValue(0)
self.horizontalSlider.setValue(0)
ressort.Placement.Base = pointsDirection[0]
# App.Console.PrintMessage("on_PB_Reverse_Com"+"\n")
def on_horizontal_slider(self, val): # connection on_horizontal_slider
global pointsDirection
if len(pointsDirection) != 0:
self.DS_horizontalSlider.setValue(val/10)
# App.Console.PrintMessage("on_horizontal_slider " + str(val/10)+"\n")
def on_CB_Position(self): # Position
global switchAdaptRadius
global centerFaceOrPoint
global Direction_Distance
global Direction_Begin
global pointsDirection
global ressort
global sel
if self.CB_Position.isChecked():
self.PB_Adapt_Radius.setEnabled(False)
self.PB_Adapt_Radius.setChecked(False)
self.PB_Adapt_Radius.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
switchAdaptRadius = 0
self.PB_Center_Point.setEnabled(False)
self.PB_Center_Point.setChecked(False)
self.PB_Center_Point.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
centerFaceOrPoint = 0
self.groupBox_04.setEnabled(True)
self.groupBox_04.setStyleSheet("QGroupBox {background-color: white;\n"
"border:2px solid rgb(0, 187, 0);}") # bord white and green
selobject = FreeCADGui.Selection.getSelection() # Select an object
del pointsDirection[:]
sel = FreeCADGui.Selection.getSelectionEx()
self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")")
try:
Direction_Begin = 0
pointsDirection = sel[0].Object.Shape.discretize(Distance = Direction_Distance) #
ressort = selobject[1]
self.horizontalSlider.setValue(0)
self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")(Points: " + str(len(pointsDirection)) + ")")
self.horizontalSlider.setMaximum(len(pointsDirection))
self.DS_horizontalSlider.setMaximum(int(len(pointsDirection)/10))
self.DS_horizontalSlider.setValue(len(pointsDirection)/10)
except Exception:
del pointsDirection[:]
self.groupBox_04.setTitle("Position (" + str(0) + ")")
App.Console.PrintError("Wrong selection"+"\n")
else:
# centerFaceOrPoint = 0
self.groupBox_04.setEnabled(False)
self.groupBox_04.setStyleSheet("QGroupBox {background-color: QPalette.Base}") # origin system
FreeCADGui.Selection.clearSelection()
sel = selobject = ""
del pointsDirection[:]
self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")")
None
# App.Console.PrintMessage("on_CB_Position "+"\n")
def on_PB_CreaCircle(self): # create circle on 3 points
global selectedCircle
if len(selectedCircle) == 3:
if (selectedCircle[0]==selectedCircle[1]) or (selectedCircle[0]==selectedCircle[2]) or selectedCircle[1]==selectedCircle[2] :
App.Console.PrintError("Bad selection the points are egual"+"\n")
else:
try:
C1 = Part.Arc(FreeCAD.Vector(selectedCircle[0]),FreeCAD.Vector(selectedCircle[1]),FreeCAD.Vector(selectedCircle[2]))
S1 = Part.Shape([C1]) # create arc base
Part.show(S1)
obj = App.ActiveDocument.ActiveObject # select the object created
Gui.Selection.addSelection(obj)
sel = obj.Shape
CircleDirection = sel.Curve.Axis # decode the datas
CircleRayon = sel.Curve.Radius
CircleAxis = sel.Curve.Center
App.ActiveDocument.removeObject(obj.Label) # remove arc master
v = CircleDirection # give direction to circle
r = App.Rotation(App.Vector(0,0,1),v)
pl=FreeCAD.Placement()
pl.Base=FreeCAD.Vector(CircleAxis)
pl.Rotation.Q = r.Q
circle3Points = Draft.makeCircle(radius=CircleRayon, placement=pl, face=False, support=None)
circle3Points.ViewObject.LineColor = (1.0,0.0,0.0) # give color
circle3Points.Label = "SpringCircle (" + str(round(CircleRayon,3)) + " r)" # give label
except Exception:
App.Console.PrintError("Three points are collinear or bad selection"+"\n")
del selectedCircle[:]
FreeCAD.ActiveDocument.recompute()
#self.PB_CreaCircle.setEnabled(False)
# App.Console.PrintMessage("on_PB_CreaCircle "+"\n")
####
def on_S_Numbering_Spire(self,value): # numero de la spire a modifier
global numberSpires
global numberSpiresModified
global lissageSpire
self.SP_Numbering_Spire.setMaximum(numberSpires)
numberSpiresModified = value
lissageSpire = 0
self.SP_Lissage.setValue(lissageSpire)
self.SP_Lissage.setVisible(False)
self.CH_Smooting.setVisible(True)
self.CH_Smooting.setChecked(False)
# App.Console.PrintMessage("on_S_Nubering_Spire "+str(numberSpiresModified)+"\n")
def on_CH_Smooting(self): # lissage precision
global lissageSpire
global precision
self.SP_Lissage.setVisible(True)
self.CH_Smooting.setVisible(False)
self.CH_Smooting.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
lissageSpire = 0
# App.Console.PrintMessage("on_CH_Smooting "+str(lissageSpire)+"\n")
def on_S_Lissage(self,value): # option lissageS des raccords
global lissageSpire
global precision
lissageSpire = value
self.SP_Lissage.setMaximum(int(360/precision)-1)
self.SP_Lissage.setToolTip(_fromUtf8("Smoothing the line if the difference between two coils"+"\n"+
"The maximum value is egual of the precision number point given -1 (" + str(int(360/precision)-1)+")"+"\n"+
"The finish and precision are influenced by this value"+"\n"+
"PS: The result can be satisfying or completely wrong (prototype state)"))
# App.Console.PrintMessage("on_S_Lissage "+str(lissageSpire)+"\n")
def on_DS_Pas_Spire(self,value): # pas (pitch) de la spire a modifier
global pasSpire
pasSpire = value
# App.Console.PrintMessage("on_DS_Pas_Spire "+str(pasSpire)+"\n")
def on_PU_To_Pas(self): # aligne le pas (pitch) de la spire
global pasSpire
global pas
pasSpire = pas
self.DS_Pas_Spire.setValue(pasSpire)
# App.Console.PrintMessage("on_PU_To_Pas "+str(pasSpire)+"\n")
def on_DS_Radius_Spire(self,value): # pas (pitch) du rayon a modifier
global rayonSpire
rayonSpire = value
# App.Console.PrintMessage("on_DS_Radius_Spire "+str(rayonSpire)+"\n")
def on_PU_To_Radius(self): # aligne le rayon
global rayonSpire
global rayon
rayonSpire = rayon
self.DS_Radius_Spire.setValue(rayonSpire)
# App.Console.PrintMessage("on_PU_To_Radius_Value "+str(rayonSpire)+"\n")
def on_PU_Accept_Value(self): # accepter la modification de la spire
global numberSpiresModified
global numberSpires
global pasSpire
global rayonSpire
global helixS
global radiusS
global lissageSpire
global lissageS
if rayonSpire != 0:
if numberSpiresModified == 1:
helixS[0] = pasSpire
radiusS[0]= rayonSpire
lissageS[0] = lissageSpire
self.textEdit.append("Coil number " + str(numberSpiresModified) + " = " + str(helixS[0]) + " " + str(radiusS[0]) + " " + str(lissageS[0]))
App.Console.PrintMessage("Coil number " + str(numberSpiresModified) + " = " + str(helixS[0]) + " " + str(radiusS[0]) + " " + str(lissageS[0])+"\n")
else:
helixS[numberSpiresModified-1] = pasSpire
radiusS[numberSpiresModified-1]= rayonSpire
lissageS[numberSpiresModified-1] = lissageSpire
self.textEdit.append("Coil number " + str(numberSpiresModified) + " = " + str(helixS[numberSpiresModified-1]) + " " + str(radiusS[numberSpiresModified-1]) + " " + str(lissageS[numberSpiresModified-1]))
App.Console.PrintMessage("Coil number " + str(numberSpiresModified) + " = " + str(helixS[numberSpiresModified-1]) + " " + str(radiusS[numberSpiresModified-1]) + " " + str(lissageS[numberSpiresModified-1])+"\n")
self.SP_Lissage.setValue(0)
self.SP_Lissage.setVisible(False)
self.CH_Smooting.setVisible(True)
self.CH_Smooting.setChecked(False)
lissageSpire = 0
else:
self.textEdit.setTextColor(QColor("red"))
self.textEdit.append("Coil number " + str(numberSpiresModified) + " Radius zero not allowed do " )
self.textEdit.setTextColor(QColor("Base"))
App.Console.PrintError("Coil number " + str(numberSpiresModified) + " Radius zero not allowed do "+"\n")
# App.Console.PrintMessage("on_PU_Accept_Value "+"\n")
def on_PB_Clear(self): #
self.textEdit.setText("")
self.textEdit.clear()
# App.Console.PrintMessage("on_PB_Clear "+"\n")
def on_PB_Zoom(self): #
global zoom
if zoom == 0:
zoom = 1
self.PU_Accept_Value.setText(_fromUtf8("Accept"))
self.grid_05.addWidget(self.PU_Accept_Value, 3, 3, 1, 1)
self.grid_05.addWidget(self.textEdit, 0, 0, 7, 3)
else:
zoom = 0
self.grid_05.addWidget(self.PU_Accept_Value, 3, 0, 1, 4)
self.PU_Accept_Value.setText(_fromUtf8("Accept the value modified"))
self.grid_05.addWidget(self.textEdit, 5, 0, 2, 3)
# App.Console.PrintMessage("on_PB_Loupe "+"\n")
def on_PU_Quit(self): # Quit
global s
App.Console.PrintMessage("\n"+"Fin FCSpring_Helix_Variable"+"\n"+"___________________________"+"\n")
FreeCADGui.Selection.removeObserver(s) # desinstalle la fonction residente
try:
self.window.setAttribute(QtCore.Qt.WA_DeleteOnClose, True) # destroy
self.window.deleteLater() # destroy
self.window.destroy() # destroy
except Exception:
self.window.hide()
None
# App.Console.PrintMessage(" "+"\n")
def on_PU_Read(self): # lecture
global path
global numberSpires
global rayon
global pas
global precision
global typeLine
global affPoint
global helixS
global radiusS
global debutAngle
global finAngle
global modifyAngle
global radius_2_Cone
global spireConeUne
global spireConeComp
global spireReverse
global lissageS
global fichierOpen
global nomF
global setPathLatestDirectory
OpenName = ""
#### mint
if switchQFileDialogMint == True: # Mint
OpenName, Filter = QtWidgets.QFileDialog.getOpenFileName(None, u"Read a file FCSpring", setPathLatestDirectory, "(FCSpring *.FCSpring);;")#PySide2 Mint
#OpenName, Filter = PySide2.QtWidgets.QFileDialog.getOpenFileName(None, u"Read a file FCSpring", setPathLatestDirectory, "*.FCSpring;;*")#PySide2 Mint
print(OpenName, Filter)
#### mint
else:
OpenName, Filter = QtWidgets.QFileDialog.getOpenFileName(None, u"Read a file FCSpring", setPathLatestDirectory, "*.FCSpring;;")#PySide2
try:
if OpenName != "":
####new2
pathFile = os.path.dirname(OpenName) + "/" #1# = C:/Provisoire400/
setPathLatestDirectory = pathFile
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"setPathLatestDirectory", setPathLatestDirectory) #*"C:\ ???"
#racineDrive = os.path.splitdrive(OpenName)[0] #2# = C:
#formatFichier = os.path.splitext(OpenName)[1] #4# = .png
#OpenName = os.path.splitext(OpenName)[0] #5# = /home/kubuntu/.FreeCAD/Macro/Texture_007_H #= C:/Provisoire400/image3D
#nomFichier = os.path.basename(OpenName) #3# = image3D
#SaveNameformatFichier = OpenName + formatFichier #6# = C:/Provisoire400/image3D.png
#pathFileSaveNameformatFichier = pathFile + nomFichier + formatFichier #7# = C:/Provisoire400/image3D.png
####new2
try:
#### Chrono begin ##################################
chrono(0) # chrono begin ##
####################################################
file = open(OpenName, "r") # read
Header = file.readline().rstrip('\n\r') #1
if (Header == "FCString") or (Header == "FCString2") or (Header == "FCString3") or (Header == "FCString4"):
a = ui
a.on_PU_Reset(0)
App.Console.PrintMessage("____________________"+"\n")
self.textEdit.clear()
op = OpenName.split("/")
op2 = op[-1].split(".")
nomF = op2[0]
App.Console.PrintMessage(nomF+"\n")
App.Console.PrintMessage(str(Header)+"\n")
numberSpires = file.readline().rstrip('\n\r') # 2
numberSpires = int(numberSpires)
self.DS_Numb_Spires.setValue(numberSpires)
App.Console.PrintMessage(str(numberSpires)+"\t"+"Number coil"+"\n")
rayon = file.readline().rstrip('\n\r') # 3
rayon = float(rayon)
radiusS = numberSpires*[rayon]
self.DS_Radius_Sping.setValue(rayon)
App.Console.PrintMessage(str(rayon)+"\t"+"Radius"+"\n")
pas = file.readline().rstrip('\n\r') # 4
pas = float(pas)
helixS = numberSpires*[pas]
self.DS_Pas_Spring.setValue(pas)
App.Console.PrintMessage(str(pas)+"\t"+"Pitch"+"\n")
precision = file.readline().rstrip('\n\r') # 5
precision = float(precision)
self.DS_Precision_Turn.setValue(precision)
App.Console.PrintMessage(str(precision)+"\t"+"Precision"+"\n")
if (Header == "FCString3") or (Header == "FCString4"):
typeLine, spireReverse = file.readline().rstrip(',\n\r').split() # 6
spireReverse = int(spireReverse)
if spireReverse == 0:
self.CH_Reverse.setChecked(False)
else:
self.CH_Reverse.setChecked(True)
else:
typeLine = file.readline().rstrip('\n\r')
typeLine = int(typeLine)
if typeLine == 0:
self.RA_BSpline.setChecked(True)
else:
self.RA_Wire.setChecked(True)
if (Header == "FCString2") or (Header == "FCString3") or (Header == "FCString4"):
self.CH_Points.setChecked(False) # reset point
affPoint = 0
debutAngle = file.readline().rstrip('\n\r') # 7
debutAngle = int(debutAngle)
self.SP_Begin_Angle.setValue(int(debutAngle))
finAngle = file.readline().rstrip('\n\r') # 8
finAngle = int(finAngle)
self.SP_End_Angle.setValue(int(finAngle))
modifyAngle = file.readline().rstrip('\n\r') # 9
modifyAngle = int(modifyAngle)
if modifyAngle == 1:
self.CB_B_E_Angle.setChecked(True)
fichierOpen = 1
else:
self.CB_B_E_Angle.setChecked(False)
fichierOpen = 0
a = ui
a.on_CB_B_E_Angle()
try:
sp, sc, ra = file.readline().rstrip(',\n\r').split() # 10
spireConeUne = int(sp) # cone
spireConeComp = int(sc) # compensation
radius_2_Cone = float(ra) # radius 2 cone
except Exception:
spireConeUne = 0
spireConeComp = 0
radius_2_Cone = 0
if (spireConeUne == 1) or (spireConeComp == 1):
self.DS_Radius_2_Cone.setEnabled(True)
self.DS_Radius_2_Cone.setValue(radius_2_Cone)
self.CH_Cone.setChecked(True)
self.LAB_Numb_Spires.setText("Number real ("+str(numberSpires - 1)+")")
self.LAB_Numb_Spires.setToolTip(_fromUtf8("The number of coil for a spring conical registered"+"\n"
"is number of coil displayed minus 1"))
else:
self.DS_Radius_2_Cone.setEnabled(False)
self.DS_Radius_2_Cone.setValue(rayon)
self.CH_Cone.setChecked(False)
# self.CH_Cone.setEnabled(False)
self.LAB_Numb_Spires.setText("Number of coil")
self.LAB_Numb_Spires.setToolTip(_fromUtf8("Number of coil"))
App.Console.PrintMessage(str(spireConeUne)+" "+str(radius_2_Cone)+"\t"+"Radius cone"+"\n\n")
dummy = file.readline().rstrip('\n\r') # 11
del lissageS[:]
lissageS = numberSpires*[0]
i = 0
for ligne in file:
if (Header == "FCString4"):
a , b , c = ligne.rstrip('\n\r').split()
helixS[i] = float(a)
radiusS[i] = float(b)
lissageS[i] = int(c)
App.Console.PrintMessage(str(i+1)+": "+str(helixS[i])+" "+str(radiusS[i])+" "+str(lissageS[i])+"\n")
self.textEdit.append("Coil number " + str(i+1) + " = " + str(helixS[i]) + " " + str(radiusS[i])+" "+str(lissageS[i])) # 12
else:
a , b = ligne.rstrip('\n\r').split()
helixS[i] = float(a)
radiusS[i] = float(b)
App.Console.PrintMessage(str(i+1)+": "+str(helixS[i])+" "+str(radiusS[i])+"\n")
self.textEdit.append("Coil number " + str(i+1) + " = " + str(helixS[i]) + " " + str(radiusS[i])) # 12
i += 1
App.Console.PrintMessage("____________________"+"\n")
self.textEdit.verticalScrollBar().setValue(0) #
self.textEdit.verticalScrollBar().setSliderPosition(0) #
else:
self.PU_Reload.setEnabled(False)
App.Console.PrintMessage("Error file not FCSpring or not FCSpring2.3.4"+"\n")
errorDialog("Error file not FCSpring or not FCSpring2.3.4 "+"\n")
finally:
file.close()
#### Chrono(1) end #################################
chrono(1) # chrono(1) end ##
####################################################
#self.label_11_Name.setText(nomF)
except Exception:
App.Console.PrintMessage("Error in reading the file "+OpenName+"\n")
errorDialog("Error in reading the file "+OpenName)
def on_PU_Save(self): # enregistrement
global path
global numberSpires
global rayon
global pas
global precision
global typeLine
global helixS
global radiusS
global debutAngle
global finAngle
global modifyAngle
global radius_2_Cone
global spireConeUne
global spireConeComp
global spireReverse
global lissageS
global setPathLatestDirectory
SaveName = ""
#### mint
if switchQFileDialogMint == True: # Mint
SaveName, Filter = QtWidgets.QFileDialog.getSaveFileName(None, "Save a file FCSpring", setPathLatestDirectory, "(*.FCSpring)")#PySide2 Mint
if ".FCSpring" in SaveName:
None
else:
Filter = Filter[Filter.find("."):Filter.find(")")]
SaveName = SaveName + Filter
#### mint
else:
SaveName, Filter = QtWidgets.QFileDialog.getSaveFileName(None, "Save a file FCSpring", setPathLatestDirectory, "*.FCSpring;;FCSpring (*.FCSpring);;")#PySide2
if SaveName == "":
App.Console.PrintMessage(u"Process aborted" + "\n")
errorDialog(u"Process aborted")
else:
App.Console.PrintMessage(u"Registration of " + SaveName + "\n")
####new2
pathFile = os.path.dirname(SaveName) + "/" #1# = C:/Provisoire400/
setPathLatestDirectory = pathFile
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"setPathLatestDirectory", setPathLatestDirectory) #*"C:\ ???"
#racineDrive = os.path.splitdrive(SaveName)[0] #2# = C:
#formatFichier = os.path.splitext(SaveName)[1] #4# = .png
#SaveName = os.path.splitext(SaveName)[0] #5# = /home/kubuntu/.FreeCAD/Macro/Texture_007_H #= C:/Provisoire400/image3D
#nomFichier = os.path.basename(SaveName) #3# = image3D
#SaveNameformatFichier = SaveName + formatFichier #6# = C:/Provisoire400/image3D.png
#pathFileSaveNameformatFichier = pathFile + nomFichier + formatFichier #7# = C:/Provisoire400/image3D.png
####new2
#self.label_11_Name.setText(SaveName)
try:
file = open(SaveName, 'w') # write
try:
file.write("FCString4"+"\n") # 1
file.write(str(numberSpires)+"\n") # 2
file.write(str(rayon)+"\n") # 3
file.write(str(pas)+"\n") # 4
file.write(str(precision)+"\n") # 5
file.write(str(typeLine)+"\t"+str(spireReverse)+"\n") # 6
file.write(str(debutAngle)+"\n") # 7
file.write(str(finAngle)+"\n") # 8
file.write(str(modifyAngle)+"\n") # 9
file.write(str(spireConeUne)+"\t"+str(spireConeComp)+"\t"+str(radius_2_Cone)+"\n") # 10
file.write("Coil"+"\t"+"Radius"+"\t"+"Smooting"+"\t"+"(If you change the file, always use Tab no space)"+"\n") # 11
for i in range(numberSpires):
file.write(str(helixS[i])+"\t"+str(radiusS[i])+"\t"+str(lissageS[i])+"\n") # 12
finally:
file.close()
except Exception:
App.Console.PrintError("Error Registration file "+SaveName+"\n")
errorDialog("Error Registration file "+SaveName)
def on_PU_Save_Coord(self): # Save coordinates x y z
global points
global setPathLatestDirectory
if len(points) > 2:
SaveName = ""
#### mint
if switchQFileDialogMint == True: # Mint
SaveName, Filter = QtWidgets.QFileDialog.getSaveFileName(None, "Save a file FCSpringCoor", setPathLatestDirectory, "(*.FCSpringCoor)")#PySide2 Mint
if ".FCSpringCoor" in SaveName:
None
else:
Filter = Filter[Filter.find("."):Filter.find(")")]
SaveName = SaveName + Filter
#### mint
else:
SaveName, Filter = QtWidgets.QFileDialog.getSaveFileName(None, "Save a file FCSpringCoor", setPathLatestDirectory, "*.FCSpringCoor;;FCSpringCoor (*.FCSpringCoor);;")#PySide2
if SaveName == "":
App.Console.PrintMessage(u"Process aborted" + "\n")
errorDialog(u"Process aborted")
else:
App.Console.PrintMessage(u"Registration of " + SaveName + "\n")
####new2
pathFile = os.path.dirname(SaveName) + "/" #1# = C:/Provisoire400/
setPathLatestDirectory = pathFile
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"setPathLatestDirectory", setPathLatestDirectory) #*"C:\ ???"
#racineDrive = os.path.splitdrive(SaveName)[0] #2# = C:
#formatFichier = os.path.splitext(SaveName)[1] #4# = .png
#SaveName = os.path.splitext(SaveName)[0] #5# = /home/kubuntu/.FreeCAD/Macro/Texture_007_H #= C:/Provisoire400/image3D
#nomFichier = os.path.basename(SaveName) #3# = image3D
#SaveNameformatFichier = SaveName + formatFichier #6# = C:/Provisoire400/image3D.png
#pathFileSaveNameformatFichier = pathFile + nomFichier + formatFichier #7# = C:/Provisoire400/image3D.png
####new2
#self.label_11_Name.setText(SaveName)
try:
file = open(SaveName, 'w') # write
try:
for i in points:
file.write(str(i[0])+" "+str(i[1])+" "+str(i[2])+"\n") # save the coordinates x y z
finally:
file.close()
except Exception:
App.Console.PrintMessage("Error Registration file "+SaveName+"\n")
errorDialog("Error Registration file "+SaveName)
else:
App.Console.PrintError("Not data to save"+"\n")
# App.Console.PrintMessage("on_PU_Save_Coord"+"\n")
def on_PU_Read_Coord(self): # Read coordinates x y z
global typeLine
global nomF
global points
global setPathLatestDirectory
OpenName = ""
#### mint
if switchQFileDialogMint == True: # Mint
OpenName, Filter = QtWidgets.QFileDialog.getOpenFileName(None, u"Read a file FCSpringCoor", setPathLatestDirectory, "(FCSpringCoor *.FCSpringCoor);;")#PySide2 Mint
#### mint
else:
OpenName, Filter = QtWidgets.QFileDialog.getOpenFileName(None, u"Read a file FCSpringCoor", setPathLatestDirectory, "*.FCSpringCoor")#PySide2
try:
if OpenName != "":
####new2
pathFile = os.path.dirname(OpenName) + "/" #1# = C:/Provisoire400/
setPathLatestDirectory = pathFile
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetString(u"setPathLatestDirectory", setPathLatestDirectory) #*"C:\ ???"
#racineDrive = os.path.splitdrive(OpenName)[0] #2# = C:
#formatFichier = os.path.splitext(OpenName)[1] #4# = .png
#OpenName = os.path.splitext(OpenName)[0] #5# = /home/kubuntu/.FreeCAD/Macro/Texture_007_H #= C:/Provisoire400/image3D
#nomFichier = os.path.basename(OpenName) #3# = image3D
#SaveNameformatFichier = OpenName + formatFichier #6# = C:/Provisoire400/image3D.png
#pathFileSaveNameformatFichier = pathFile + nomFichier + formatFichier #7# = C:/Provisoire400/image3D.png
####new2
try:
#### Chrono(0) begin ###############################
chrono(0) # chrono(0) begin ##
####################################################
file = open(OpenName, "r") # read
a = ui
a.on_PU_Reset(0)
App.Console.PrintMessage("____________________"+"\n")
self.DS_Numb_Spires.setValue(numberSpires)
self.DS_Pas_Spring.setValue(pas)
self.DS_Radius_Sping.setValue(rayon)
self.textEdit.clear()
op = OpenName.split("/")
op2 = op[-1].split(".")
nomF = op2[0]
points = []
del points[:]
App.Console.PrintMessage(nomF+"\n")
self.PU_Accept_Value.setVisible(False)
self.PBA_progressBar.setVisible(True)
self.PBA_progressBar.setMaximum(0)
self.PBA_progressBar.setMinimum(0)
# self.PBA_progressBar.setValue(0)
X = Y = Z = 0.0
for ligne in file:
X , Y , Z = ligne.rstrip('\n\r').split()
points.append(FreeCAD.Vector(float(X),float(Y),float(Z))) # append the coordinates
if typeLine == 1:
ressort = Draft.makeWire(points,closed=False,face=False,support=None)# creation spring makeWire
else:
ressort = Draft.makeBSpline(points,closed=False) # creation spring Draft " makeBSpline " remis pour facilite avec axes
# ressort = Part.BSplineCurve() # creation spring Part " BSplineCurve "
# ressort.interpolate(points,False)
# ressort0 = Part.Edge(ressort)
# Part.show(ressort0)
try:
App.ActiveDocument.ActiveObject.Label = "Spring_" + unicode(nomF)
except Exception:
try:
App.ActiveDocument.ActiveObject.Label = "Spring_" + nomF
except Exception:
App.ActiveDocument.ActiveObject.Label = "Spring_XX"
FreeCAD.ActiveDocument.recompute()
self.PBA_progressBar.setVisible(False)
self.PU_Accept_Value.setVisible(True)
#### Chrono(1) end #################################
chrono(1) # chrono(1) end ##
####################################################
finally:
file.close()
#self.label_11_Name.setText(nomF)
self.textEdit.append("Coordinates file")# + "\n")
self.textEdit.setTextColor(QColor("blue"))
self.textEdit.append("PS: For Info The values showing in the configuration menu do not match the data of the spring"+"\n")
self.textEdit.setTextColor(QColor("Base"))
except Exception:
App.Console.PrintMessage("Error in reading the file "+OpenName+"\n")
errorDialog("Error in reading the file "+OpenName)
App.Console.PrintMessage("on_PU_Read_Coord"+"\n")
def on_PU_Launch(self): # Execute
global numberSpires
global rayon
global pas
global precision
global typeLine
global helixS
global pasSpire
global radiusS
global affPoint
global debutAngle
global finAngle
global modifyAngle
global radius_2_Cone
global spireConeUne
global spireConeComp
global spireReverse
global lissageSpire
global lissageS
global points
global nomF
global ressort
global pointsDirection
global Direction_Begin
global Direction_Distance
global plr
global coor_Z
global ui
global sel
global hauteurCylindre
global vecteurSouris
global centerFaceOrPoint
global axisSpring
global switchReverse
global switchAdaptRadius
if rayon != 0:
doc = FreeCAD.ActiveDocument
if doc == None:
doc = FreeCAD.newDocument()
ressort = ""
############ Section object selected Begin ####################################################
sel = FreeCADGui.Selection.getSelectionEx() #0# Select an object or sub object
try:
if len(sel) != 0:
#### Chrono begin ##################################
chrono(0) # chrono begin ##
####################################################
subObjet = sel[0].SubObjects[0]
selobject = FreeCADGui.Selection.getSelection() # Select an object
FCSpring = doc.addObject("App::DocumentObjectGroup","FCSpring")
switchReverse = 0
xL = yL = 0.0
hauteurCylindre = sum(helixS) # calcul hauteur Cylindre / axe
if hasattr(sel[0].SubObjects[0],"Surface"):
subObjet = sel[0].SubObjects[0]
if (str(subObjet.Surface) == "<Cylinder object>") or (str(subObjet.Surface) == "<SurfaceOfExtrusion object>"): # face
try:
GlobalCenter = LineCoorX = LineCoorY = CircleCenter = CircleRadius = EllipseCenter = EllipseRadius = 0.0
for a0 in subObjet.Edges:
if (str(a0.Curve)[1:5]) == "Line" :
# print( "xLine" )
LineCoorX = a0.Vertexes[1].Point
LineCoorY = a0.Vertexes[0].Point
if (str(a0.Curve)[0:6]) == "Circle" :
# print( "xCircle" )
GlobalCenter = CircleCenter = a0.Curve.Center
CircleRadius = a0.Curve.Radius
xL = CircleCenter
rayonX = CircleRadius
if (str(a0.Curve)[1:8]) == "Ellipse" :
# print( "xEllipse" )
GlobalCenter = EllipseCenter = a0.Curve.Center
EllipseRadius = a0.Curve.MinorRadius
#EllipseRadius = a0.Curve.MajorRadius #option
rayonX = EllipseRadius
xL = EllipseCenter
if LineCoorX.distanceToPoint(GlobalCenter) > LineCoorY.distanceToPoint(GlobalCenter):
Direction = LineCoorX.sub(LineCoorY)
else:
Direction = LineCoorY.sub(LineCoorX)
if switchAdaptRadius == 1:
rayon = rayonX
self.DS_Radius_Sping.setValue(rayon)
yL = Direction + xL
points=[xL,yL]
except Exception:
App.Console.PrintError("<Cylinder object> + <SurfaceOfExtrusion object"+"\n")
elif str(subObjet.Surface) == "<Plane object>": # extremites
try:
# print( "<Plane object>" )
subObjet = sel[0].SubObjects[0]
obj = selobject[0]
comp = subObjet
if centerFaceOrPoint != 0:
yL = sel[0].SubObjects[0].CenterOfMass # Center Of face
else:
yL = vecteurSouris # clic point
uv = comp.Surface.parameter((yL))
nv = comp.normalAt(uv[0], uv[1]).normalize().multiply(hauteurCylindre)
xL = nv + yL
points=[xL,yL]
except Exception:
App.Console.PrintError("<Plane object>"+"\n")
elif (str(subObjet.Surface)[0:6] == "Sphere"): # Sphere
try:
# print( "Sphere" )
subObjet = sel[0].SubObjects[0]
if switchAdaptRadius == 1:
rayon = selobject[0].Radius.Value # selobject[0].Radius2.Value # option
self.DS_Radius_Sping.setValue(rayon)
obj = selobject[0]
comp = subObjet
if centerFaceOrPoint != 0:
xL = subObjet.Surface.Center # Center
direction = subObjet.Surface.Axis.normalize().multiply(hauteurCylindre)
yL = direction + xL
else:
xL = vecteurSouris # clic point
uv = comp.Surface.parameter((xL))
nv = comp.normalAt(uv[0], uv[1]).normalize().multiply(hauteurCylindre)
yL = nv + xL
points=[xL,yL]
except Exception:
App.Console.PrintError("Sphere"+"\n")
elif (str(subObjet.Surface) == "<Toroid object>") or (str(subObjet.Surface) == "<Cone object>"): # Toroid + Cone
try:
# print( str(subObjet.Surface) )
subObjet = sel[0].SubObjects[0]
if switchAdaptRadius == 1:
rayon = selobject[0].Radius1.Value # selobject[0].Radius2.Value # option
self.DS_Radius_Sping.setValue(rayon)
obj = selobject[0]
comp = subObjet
if centerFaceOrPoint != 0:
xL = subObjet.Surface.Center # Center
direction = subObjet.Surface.Axis.normalize().multiply(hauteurCylindre)
yL = direction + xL
else:
xL = vecteurSouris # clic point
uv = comp.Surface.parameter((xL))
nv = comp.normalAt(uv[0], uv[1]).normalize().multiply(hauteurCylindre)
yL = nv + xL
points=[xL,yL]
except Exception:
App.Console.PrintError(str(subObjet.Surface)+"\n")
else:
try:
# print( "Terminus" )
obj = selobject[0]
comp = subObjet
xL = vecteurSouris # clic point
uv = comp.Surface.parameter((xL))
nv = comp.normalAt(uv[0], uv[1]).normalize().multiply(hauteurCylindre)#hauteurCylindre
yL = nv + xL
points=[xL,yL]
except Exception:
App.Console.PrintError("Face"+"\n")
else:
###OK tous points#############################################
if (len(sel[0].SubObjects) == 2):
xL = sel[0].SubObjects[0].Vertexes[0].Point
yL = sel[0].SubObjects[1].Vertexes[0].Point
points=[xL,yL]
elif (len(sel) == 2):
xL = sel[0].SubObjects[0].Vertexes[0].Point
yL = sel[1].SubObjects[0].Vertexes[0].Point
points=[xL,yL]
elif (len(sel) == 1):
try:
if (hasattr(subObjet.Curve,"Center")) and (hasattr(subObjet.Curve,"Radius")): # arc or circle
# print( "Circle/Arc" )
subObjet = sel[0].SubObjects[0]
if switchAdaptRadius == 1:
rayon = subObjet.Curve.Radius
self.DS_Radius_Sping.setValue(rayon)
yL = subObjet.Curve.Center
direction = subObjet.Curve.Axis.normalize().multiply(hauteurCylindre) # option
edgeO = selobject[0] # edge
edgeObject = edgeO.Shape.Edges[0]
e = edgeObject
xL = direction + yL
points=[xL,yL]
elif (str(subObjet.Curve)[1:5]) == "Line" :
# print( "Line" )
xL = subObjet.Vertexes[1].Point
yL = subObjet.Vertexes[0].Point
points=[xL,yL]
elif (str(subObjet.Curve) == "<Ellipse object>"): # Ellipse
# print( "Ellipse" )
subObjet = sel[0].SubObjects[0]
if switchAdaptRadius == 1:
rayon = subObjet.Curve.MinorRadius
self.DS_Radius_Sping.setValue(rayon)
xL = subObjet.Curve.Center
direction = subObjet.Curve.Axis.normalize().multiply(hauteurCylindre) # option
edgeO = selobject[0] # edge
edgeObject = edgeO.Shape.Edges[0]
e = edgeObject
yL = direction + xL
points=[xL,yL]
else:
# print( "Ouf.Curve" )
xL = sel[0].SubObjects[0].Vertexes[0].Point
yL = xL + (FreeCAD.Vector(0.0, 0.0, hauteurCylindre))
points=[xL,yL]
except Exception:
xL = sel[0].SubObjects[0].Vertexes[0].Point
try:
yL = sel[0].SubObjects[0].Vertexes[1].Point
except Exception:
yL = xL + (FreeCAD.Vector(0.0, 0.0, hauteurCylindre))
points=[xL,yL]
###OK tous points#############################################
axisSpring = sel = ""
axisSpring = Draft.makeWire(points,closed=False,face=False,support=None) # make line
axisSpring.ViewObject.LineColor = (1.0,0.0,0.0) # give axis LineColor
axisSpring.ViewObject.DrawStyle = "Dashdot"
axisSpring.Label = "Spring Axis (" + str(axisSpring.Length.Value) + ")"
FCSpring.addObject(axisSpring)
FreeCADGui.updateGui() # rafraichi l'ecran
FreeCAD.ActiveDocument.recompute()
#doc.removeObject(axisSpring.Name) # remove axis if .. option
obj = App.ActiveDocument.getObject(axisSpring.Name)
Gui.Selection.addSelection(obj) # select the object
sel = FreeCADGui.Selection.getSelectionEx()
pointsDirection = sel[0].Object.Shape.discretize(Distance = Direction_Distance) # discretize
v=pointsDirection[0].sub(pointsDirection[1])
r=App.Rotation(App.Vector(0,0,1),v)
plr=FreeCAD.Placement()
plr.Rotation.Q = r.Q
self.horizontalSlider.setMaximum(len(pointsDirection))
self.DS_horizontalSlider.setMaximum(int(len(pointsDirection)/10))
self.DS_horizontalSlider.setValue(len(pointsDirection)/10)
# self.groupBox_04.setEnabled(True)
# self.groupBox_04.setStyleSheet("QGroupBox {background-color: white;\n"
# "border:2px solid rgb(0, 187, 0);}") # bord white and green
else:
plr = "xx"
# self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")(Points: " + str(len(pointsDirection)) + ")")
except Exception:
App.Console.PrintError("Error selection " + "\n")
switchReverse = 0
sel = ""
FreeCAD.ActiveDocument.recompute()
FreeCADGui.updateGui() # rafraichi l'ecran
Gui.updateGui() # rafraichi l'ecran
############ Section object selected End ######################################################
self.PU_Accept_Value.setVisible(False)
self.PBA_progressBar.setVisible(True)
self.PBA_progressBar.setMaximum(numberSpires * (360 / int(precision)))
self.PBA_progressBar.setValue(0)
coor_X = coor_Y = coor_Z = 0.0
angleTr = 0
points = []
del points[:]
pas2 = 0.0
PBA = 0 # compteur PgrogressBar
App.Console.PrintMessage("____________________"+"\n")
App.Console.PrintMessage("Pitch " + str(pas)+"\n")
App.Console.PrintMessage("Radius " + str(rayon)+"\n")
App.Console.PrintMessage("Precision " + str(precision)+"\n")
App.Console.PrintMessage("DebutAngle " + str(debutAngle)+"\n")
App.Console.PrintMessage("FinAngle " + str(finAngle)+"\n")
App.Console.PrintMessage("List Helix " + str(helixS)+"\n")
App.Console.PrintMessage("List Radius " + str(radiusS)+"\n")
App.Console.PrintMessage("List Smoot1 " + str(lissageS)+"\n")
for spir in range(numberSpires-spireConeComp): # number spires Helix
pas2 = helixS[spir]
PBA += 1
if spir != numberSpires - 1: # pas travail normal
pastr = ((radiusS[spir + 1]-radiusS[spir]) / (360/precision))
elif spireConeUne == 1: # cone une seule spire
pastr = (radius_2_Cone / (360/precision))
else:
pastr = 0.0
pasRadius = radiusS[spir] # pas pour le rayon
i = 0
debutAngleX = 0
finAngleX = 360
if modifyAngle == 1:
if (spir == 0) :
debutAngleX = debutAngle
if (spir == numberSpires - 1 - spireConeComp): #or (spir == numberSpires):
finAngleX = finAngle + int(precision)
for angleTr in range(0,finAngleX,int(precision)): # boucle for 1 turn (360/precision) degrees
pasRadius = radiusS[spir]+((pastr*i))
i+=1
self.PBA_progressBar.setValue( PBA )
PBA += 1
vecligne=[FreeCAD.Vector(0,0,0),FreeCAD.Vector(pasRadius ,0.0,0.0)]
ligne = Draft.makeWire(vecligne,closed=False,face=False,support=None) #creation de la ligne de base
#ligneName = ligne.Name
if spireReverse == 0: # counterclockwise
ligne.Placement = FreeCAD.ActiveDocument.Line.Placement=App.Placement(App.Vector(0.0,0.0,0.0), App.Rotation(App.Vector(0,0,1),angleTr), App.Vector(0,0,0))
else: # clockwise direction
ligne.Placement = FreeCAD.ActiveDocument.Line.Placement=App.Placement(App.Vector(0.0,0.0,0.0), App.Rotation(App.Vector(0,0,1),-angleTr), App.Vector(0,0,0))
FreeCAD.activeDocument().recompute(None,True,True)
try:
a = ligne.Shape.Edges[0].Vertexes[1] # fin de ligne
except Exception:
a = ligne.End # fin de ligne
try:
coor_X = (a.Point.x)
coor_Y = (a.Point.y)
except Exception:
coor_X = (a.x)
coor_Y = (a.y)
if angleTr >= debutAngleX:
points += [FreeCAD.Vector(coor_X,coor_Y,coor_Z)] # coordinates makeBSpline contener
if (affPoint == 1) and (angleTr >= debutAngleX):
point = Draft.makePoint(coor_X,coor_Y,coor_Z) # create point repere for test
FreeCADGui.activeDocument().getObject(point.Name).PointColor = (1.0,0.0,0.0)
coor_Z += (pas2 / (360/precision)) # pas of spring
App.ActiveDocument.removeObject(ligne.Name) # remove ligne de base directrice
#App.ActiveDocument.removeObject(ligneName) # remove ligne de base directrice
############# Smooting begin ### prototype#############################################################################################
if (numberSpires >= 2) and (sum(lissageS[:]) != 0):
compBar = compBar1 = 0 # progressBar
compBar = sum(lissageS[:]) # progressBar
self.PBA_progressBar.setMaximum(compBar) # progressBar
self.PBA_progressBar.setValue(0) # progressBar
decalageM = 0 # decalage montant
pointTravailBase = int(360/precision) # nombre de points dans la boucle
if debutAngle != 0:
decalageM = (pointTravailBase - int((360-debutAngle)/precision)) # decalageM debutAngle
if lissageS[0] != 0: # lissage spire 1
if lissageS[0] > int((360-debutAngle)/precision):
lissageS[0] = int((360-debutAngle)/precision) - 1
if (lissageS[1] != 0): # lissage spire 2
if lissageS[1] > int((360-debutAngle)/precision):
lissageS[1] = int((360-debutAngle)/precision) - 1
if finAngle != 360:
if lissageS[-1] != 0: # lissage derniere spire
if lissageS[-1] > (pointTravailBase - int((360-finAngle)/precision)):
lissageS[-1] = (pointTravailBase - int((360-finAngle)/precision)) - 1
if lissageS[-2] != 0: # lissage avant derniere spire
if lissageS[-2] > (pointTravailBase - int((360-finAngle)/precision)):
lissageS[-2] = (pointTravailBase - int((360-finAngle)/precision)) - 1
try:
if (lissageS[-3] != 0) and ((spireConeUne == 1) or (spireConeComp == 1)): # lissage avant derniere spire cas cone (N_spire-1)
if lissageS[-3] > (pointTravailBase - int((360-finAngle)/precision)):
lissageS[-3] = (pointTravailBase - int((360-finAngle)/precision)) - 1
except Exception:
None
App.Console.PrintError("Error0 smooting"+"\n")
############################################# lissage Gauche Superieur
x0 = 2 # division premiere spire
x1 = 0 # avance G/D
x2 = 1 # largeur en points
x3 = 2 # division
for ii in range(1 , numberSpires):
pointTravail = pointTravailBase * ii
compBar1 += 1 # progressBar
self.PBA_progressBar.setValue(compBar1) # progressBar
if lissageS[ii-1] != 0:
x1 = 0 # avance G/D
boucler = lissageS[ii-1]
if (ii-1 == 0) and (debutAngle != 0): # nombre de points
if (boucler) > (pointTravailBase - int((360-debutAngle)/precision)):
boucler = lissageS[0] - (pointTravailBase - int((360-debutAngle)/precision))
try:
for i in (range(boucler)):
compBar1 += 1 # progressBar
self.PBA_progressBar.setValue(compBar1) # progressBar
if i == 0:
a = points[pointTravail-1-decalageM][2] # G # C
b = points[pointTravail+1-decalageM][2] # D # C
c = (((b - a)/x0) + a) # C
points[pointTravail+(i)-decalageM][2] = c # C
else:
x1 += 1
a = points[pointTravail+(x1-x2)-decalageM][2] # G # D
b = points[pointTravail+(x1+x2)-decalageM][2] # D # D
c = (((b - a)/x3) + a) # D
points[pointTravail+(x1)-decalageM][2] = c # D
a = points[pointTravail+(-x1-x2)-decalageM][2] # G # G
b = points[pointTravail+(-x1+x2)-decalageM][2] # D # G
c = (((b - a)/x3) + a) # G
points[pointTravail+(-x1)-decalageM][2] = c # G
except Exception:
App.Console.PrintError("Error1 smooting coil num : "+str(ii)+" value : "+str(lissageS[ii-1])+"\n"+
"Choose a lower smoothing value"+"\n")
############################################# lissage Droit Inferieur
compBar1 = 0
for ii in range(1 , numberSpires):
pointTravail = pointTravailBase * (ii )
compBar1 += 1 # progressBar
self.PBA_progressBar.setValue(compBar1) # progressBar
if lissageS[ii] != 0:
x1 = 0 # avance G/D
boucler = lissageS[ii]
try:
for i in (range(boucler)):
compBar1 += 1 # progressBar
self.PBA_progressBar.setValue(compBar1) # progressBar
if i == 0:
a = points[pointTravail-1-decalageM][2] # G # C
b = points[pointTravail+1-decalageM][2] # D # C
c = (((a - b)/x0) + b) # C
points[pointTravail+(i)-decalageM][2] = c # C
else:
############################################# # lissage Gauche Sup
x1 += 1
a = points[pointTravail+(x1-x2)-decalageM][2] # G # D
b = points[pointTravail+(x1+x2)-decalageM][2] # D # D
c = (((a - b)/x3) + b) # D
points[pointTravail+(x1)-decalageM][2] = c # D
a = points[pointTravail+(-x1-x2)-decalageM][2] # G # G
b = points[pointTravail+(-x1+x2)-decalageM][2] # D # G
c = (((a - b)/x3) + b) # G
points[pointTravail+(-x1)-decalageM][2] = c # G
except Exception:
App.Console.PrintError("Error2 smooting coil num : "+str(ii)+" value : "+str(lissageS[ii-1])+"\n"+
"Choose a lower smoothing value"+"\n")
App.Console.PrintMessage("List Smoot2 " + str(lissageS)+"\n")
App.Console.PrintMessage("____________________"+"\n")
############ Smooting end ##########################################################################################################
if typeLine == 1:
ressort = Draft.makeWire(points,closed=False,face=False,support=None)# creation spring makeWire
else:
ressort = Draft.makeBSpline(points,closed=False) # creation spring Draft " makeBSpline " remis pour facilite avec axes
# ressortT = Part.BSplineCurve() ## # creation spring Part " BSplineCurve "
# ressortT.interpolate(points,False) ##
# ressort = Part.Edge(ressortT) ##
# Part.show(ressort) ##
if (plr != "xx") and (len(pointsDirection)!= 0): # placement if axis selected
pointsDirection.reverse()
plr.Base = pointsDirection[-1]#
ressort.Placement = plr
self.horizontalSlider.setValue(0)
if nomF != "Name File": # name file
App.ActiveDocument.ActiveObject.Label = "Spring_" + nomF
else:
App.ActiveDocument.ActiveObject.Label = "Spring (" + str(rayon) + " r)"
try:
FCSpring.addObject(ressort)
FCSpring.Label = "Spring (" + str(rayon) + " r)"
except Exception:
None
FreeCAD.ActiveDocument.recompute()
self.PBA_progressBar.setVisible(False)
self.PU_Accept_Value.setVisible(True)
#### Chrono(1) end #################################
chrono(1) # chrono(1) end ##
####################################################
else:
App.Console.PrintError("Radius zero not allowed do"+"\n")
self.textEdit.setTextColor(QColor("red"))
self.textEdit.append("Radius zero not allowed do " )
self.textEdit.setTextColor(QColor("Base"))
####on_PU_Launch end ###################################################################################
def selectOk(self, val):
global switchAdaptRadius
global centerFaceOrPoint
global sel
global vecteurSouris
global selectedCircle
try:
sel = FreeCADGui.Selection.getSelectionEx() # display the type line selected
self.textEdit.append(str(sel[0].SubObjects[0].Curve))
except Exception:
try:
self.textEdit.append(str(sel[0].SubObjects[0].Surface))
except Exception:
None
if val == 1:
self.PB_Adapt_Radius.setEnabled(True)
self.PB_Adapt_Radius.setStyleSheet("QPushButton {background-color: white;\n"
"border:2px solid rgb(0, 187, 0);}") # bord white and green
self.PB_Center_Point.setEnabled(True)
self.PB_Center_Point.setStyleSheet("QPushButton {background-color: white;\n"
"border:2px solid rgb(0, 187, 0);}") # bord white and green
if len(sel) == 2:
self.CB_Position.setEnabled(True)
self.CB_Position.setStyleSheet("QCheckBox {background-color: white;\n"
"border:2px solid rgb(0, 187, 0);}") # bord white and green
if len(selectedCircle) == 3:
self.PB_CreaCircle.setEnabled(True)
self.PB_CreaCircle.setStyleSheet("QPushButton {background-color: white;\n"
"border:2px solid rgb(0, 187, 0);}") # bord white and green
elif len(selectedCircle) > 3:
self.PB_CreaCircle.setEnabled(False)
self.PB_CreaCircle.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
del selectedCircle[:]
else:
self.PB_Adapt_Radius.setEnabled(False)
self.PB_Adapt_Radius.setChecked(False)
self.PB_Adapt_Radius.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
self.PB_Adapt_Radius.setText("Normal")
switchAdaptRadius = 0
self.PB_Center_Point.setEnabled(False)
self.PB_Center_Point.setChecked(False)
self.PB_Center_Point.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
self.PB_Center_Point.setText(_fromUtf8("Point Mouse"))
centerFaceOrPoint = 0
self.CB_Position.setEnabled(False)
self.CB_Position.setChecked(False)
self.CB_Position.setStyleSheet("QCheckBox {background-color: QPalette.Base}") # origin system
self.PB_CreaCircle.setEnabled(False)
self.PB_CreaCircle.setChecked(False)
self.PB_CreaCircle.setStyleSheet("QPushButton {background-color: QPalette.Base}") # origin system
switchAdaptRadius = 0
self.groupBox_04.setTitle("Position (" + str(len(sel)) + ")") #(Points: " + str(len(pointsDirection)) + ")
def on_CB_05_Position(self):
global FCmw
global seTPositionFlyRightLeft
global seTWidgetPosition
if seTPositionFlyRightLeft != 1:
if self.CB_05_Position.isChecked():
FCmw.addDockWidget(QtCore.Qt.LeftDockWidgetArea,myNewFreeCADWidget) # add the widget to the main window Left
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetInt(u"seTPositionFlyRightLeft", 3) #*1, 2, other
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetBool(u"seTWidgetPosition", True) # True or False
else:
FCmw.addDockWidget(QtCore.Qt.RightDockWidgetArea,myNewFreeCADWidget)# add the widget to the main window Right
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetInt(u"seTPositionFlyRightLeft", 2) #*1, 2, other
FreeCAD.ParamGet(u"User parameter:BaseApp/Preferences/Macros/FCMmacros/" + __Title__).SetBool(u"seTWidgetPosition", False) # True or False
def on_PU_Help(self):
try:
webbrowser.open("http://www.freecadweb.org/wiki/index.php?title=Macro_FCSpring_Helix_Variable")
App.Console.PrintMessage("http://www.freecadweb.org/wiki/index.php?title=Macro_FCSpring_Helix_Variable" + "\n")
except Exception:
App.Console.PrintMessage(u"Not access")
class SelObserver:
print( "run.." )
def addSelection(self,document, object, element, position): # Selection
global ui
global vecteurSouris
global selectedCircle
vecteurSouris = FreeCAD.Vector(position)
selectedCircle.append(vecteurSouris)
ff = ui
ff.selectOk(1)
# App.Console.PrintMessage("addSelection"+"\n")
def clearSelection(self,doc): # Si clic sur l'ecran, effacer la selection
global ui
global selectedCircle
del selectedCircle[:]
ff = ui
ff.selectOk(0)
doc = FreeCAD.ActiveDocument
if doc == None:
doc = FreeCAD.newDocument(__Title__)
helixS = []
del helixS[:]
helixS = numberSpires*[pas]
radiusS = []
del radiusS[:]
radiusS = numberSpires*[rayon]
lissageS = []
del lissageS[:]
lissageS = numberSpires*[0]
s=SelObserver()
FreeCADGui.Selection.addObserver(s) # installe the function in resident mode
#MainWindow = QtWidgets.QMainWindow()
#MainWindow.setObjectName(__Title__) # macro internal Name
#ui = Ui_MainWindow()
#ui.setupUi(MainWindow)
#MainWindow.show()
mw = FreeCADGui.getMainWindow()
dw=mw.findChildren(QtWidgets.QDockWidget)
for i in dw:
if str(i.objectName()) == __Title__:
if i.isVisible():
i.setVisible(False)
else:
if seTPositionFlyRightLeft == 1: # MainWindow
None
else:
myNewFreeCADWidget = QtWidgets.QDockWidget() # create (restore) a new dockwidget
myNewFreeCADWidget.setObjectName(__Title__)
ui = Ui_MainWindow()
ui.setupUi(myNewFreeCADWidget)
FCmw = FreeCADGui.getMainWindow()
i.setVisible(True)
break
if i.objectName() != __Title__: # macro internal Name
#
#####MainWindow################################################################################
if seTPositionFlyRightLeft == 1: # MainWindow
MainWindow = QtWidgets.QMainWindow() # create a new window volant
MainWindow.setObjectName(__Title__) # macro internal Name
ui = Ui_MainWindow()
ui.setupUi(MainWindow)
MainWindow.show()
#####DockWidget################################################################################
#
else:
myNewFreeCADWidget = QtWidgets.QDockWidget() # create a new dockwidget
myNewFreeCADWidget.setObjectName(__Title__)
ui = Ui_MainWindow()
ui.setupUi(myNewFreeCADWidget)
FCmw = FreeCADGui.getMainWindow()
if seTPositionFlyRightLeft == 2: # RightDock
FCmw.addDockWidget(QtCore.Qt.RightDockWidgetArea,myNewFreeCADWidget) # add the widget to the main window Right
else: # LeftDock
FCmw.addDockWidget(QtCore.Qt.LeftDockWidgetArea,myNewFreeCADWidget) # add the widget to the main window Left
@mario52a
Copy link
Author

mario52a commented Jan 2, 2016 •
edited
Loading

This macro utility is intended for the use of the program FreeCAD http://www.freecadweb.org/
The icon for your toolbar, it is to place in your macros directory (in the same location of the macro)

Wiki (http://www.freecadweb.org/wiki/index.php?title=Macro_FCSpring_Helix_Variable)

fcspring_helix_variable rename in FCSpring_Helix_Variable.png

The image for the macro, it is to place in your macros directory (in the same location of the macro)
fcspring_helix_variable_icon_01 rename in FCSpring_Helix_Variable_Icon_01.png
fcspring_helix_variable_icon_02 rename in FCSpring_Helix_Variable_Icon_02.png
fcspring_helix_variable_icon_02b rename in FCSpring_Helix_Variable_Icon_02b.png
fcspring_helix_variable_icon_03 rename in FCSpring_Helix_Variable_Icon_03.png
fcspring_helix_variable_icon_03b rename in FCSpring_Helix_Variable_Icon_03b.png
fcspring_helix_variable_icon_04 rename in FCSpring_Helix_Variable_Icon_04.png
fcspring_helix_variable_icon_05 rename in FCSpring_Helix_Variable_Icon_05.png
fcspring_helix_variable_icon_06 rename in FCSpring_Helix_Variable_Icon_06.png

@snelweg
Copy link

snelweg commented Oct 17, 2020 •
edited
Loading

Getting an error in 0.19, I know nothing about python.

22:43:12 Traceback (most recent call last):
File "/home/x/.FreeCAD/Macro/Macro_FCSpring_Helix_Variable.FCMacro", line 56, in
if int(FreeCAD.Version()[1]) < 18: # Version de FreeCAD
<class 'ValueError'>: invalid literal for int() with base 10: '10.16'
22:43:53 Traceback (most recent call last):
File "/home/x/.FreeCAD/Macro/Macro_FCSpring_Helix_Variable.FCMacro", line 56, in
if int(FreeCAD.Version()[1]) < 18: # Version de FreeCAD
<class 'ValueError'>: invalid literal for int() with base 10: '10.16'

OS: Debian GNU/Linux 10 (buster) (XFCE/lightdm-xsession)
Word size of OS: 64-bit
Word size of FreeCAD: 64-bit
Version: 2020.10.16.22739 +2665 (Git) AppImage
Build type: Release
Branch: LinkStage3
Hash: b8b5bcea8529cac946ddbd62515187aca4ef6df8
Python version: 3.8.6
Qt version: 5.12.9
Coin version: 4.0.0
OCC version: 7.4.0
Locale: English/United States (en_US)
`

@snelweg
Copy link

snelweg commented Oct 18, 2020 •
edited
Loading

12:30:52 run..
12:31:02 Traceback (most recent call last):
12:31:02 File "/home/X/.FreeCAD/Macro/Macro_FCSpring_Helix_Variable.FCMacro", line 1718, in on_PU_Launch
12:31:02 depart = time.clock() # chrono begin ##
12:31:02 AttributeError: module 'time' has no attribute 'clock'
12:31:06
Fin FCSpring_Helix_Variable

update, edited line 1718 and 2179
was

= time.time() # chrono begin ##

replaced with:

= time.process_time() # chrono begin ##

@mario52a
Copy link
Author

Hi

many thanks for report this bug all is corrected (cause version Python)

the first error is : the test on FC 18, i suppress the test line 56

the second as you see is the timer, i suppress the timer chrono and i wait one little

thanks mario

@NickUfer
Copy link

FYI, this macro currently does not work correctly with the FreeCAD Link Branch realthunder/FreeCAD#530 . But I think this has nothing to do with your macro, it seems to be some change or optimization in the fork.

@mario52a
Copy link
Author

mario52a commented Aug 14, 2022 •
edited
Loading

Hi

thanks for report, maybe in rapport with this

Macro_FCSpring_Helix_Variable_20

have you try : check: Wire for see if it is the BSline (and check Points also) for following

thanks mario

@GithubUser99999999
Copy link

2024 and it cannot even be found in the linkstage3 FreeCAD :/

@mario52a
Copy link
Author

mario52a commented Apr 17, 2024 •
edited
Loading

Hi

thanks for report, have you contact realthunder ?

mario

Sign up for free to join this conversation on GitHub. Already have an account? Sign in to comment
