# Napisane przez: Mateusz Woźniak (20 kwi 2021) | |
# Program to działający silnik renderowania 3d, który używa tylko podobieństwa trójkątów | |
import threading | |
from tkinter import Tk, Canvas, Frame, BOTH | |
# Delaracja obiektu w 3d | |
pyramid = [ | |
[-500, -500, 1000], | |
[500, -500, 1000], | |
[500, -500, 2000], | |
[-500, -500, 2000], | |
[0, 3000, 2000], | |
] | |
fps = 144 | |
class Engine(Frame): | |
def __init__(self): | |
super().__init__() | |
self.master.title("Engine") | |
self.pack(fill=BOTH, expand=1) | |
self.canvas = Canvas(self) | |
# Rzeczy związane z animacją | |
self.translated = pyramid | |
self.x_translation = 10 | |
self.y_translation = 10 | |
self.render() | |
def render(self): | |
self.canvas.delete("all") | |
coords = [] | |
lines = [] | |
fov = 200 | |
# Rysowanie odcinków od każdego do każdego punktu | |
for p1 in self.translated: | |
for p2 in self.translated: | |
lines.append([p1, p2]) | |
# Projekcja odcinków z trójwymiaru na dwuwymiarowy ekran na podstawie podobieństwa trójkątów | |
for figure in lines: | |
for point in figure: | |
# wzór wyznaczony ze stosunku długości boków trójkąta | |
x = point[0] * fov / point[2] | |
y = point[1] * fov / point[2] | |
# wrzucenie każdego punktu do tablicy | |
coords.append((1920 / 2) + x) | |
coords.append((1080 / 2) - y) | |
# narysowanie linii na ekranie | |
self.canvas.create_line(*coords) | |
# | |
if self.translated[0][0] > 750 or self.translated[0][0] < -750: | |
self.x_translation = -self.x_translation | |
if self.translated[0][1] > 750 or self.translated[0][1] < -750: | |
self.y_translation = -self.y_translation | |
dup = self.translated.copy() | |
self.translated = [] | |
for point in dup: | |
self.translated.append([point[0] + self.x_translation, point[1] + self.y_translation, point[2]]) | |
self.canvas.pack(fill=BOTH, expand=1) | |
threading.Timer(1 / fps, self.render).start() | |
def main(): | |
root = Tk() | |
root.resizable(False, False) | |
root.geometry("1920x1080") | |
Engine() | |
root.mainloop() | |
if __name__ == '__main__': | |
main() | |
