Excalidraw Obsidian Publish Support

readme.md

Watch the acompanying video to understand how to use these scripts.

Note that Obsidian Publish only supports the use of the publish.js script if you are publishing to a custom domain. However, this should not be an issue. You are able to secure a cheap domain name for as low as $1 per annum and make the necessary configurations for Obsdiian in Cloudflare for free.

• Here's the link to the Obsidian guide about setting up a custom domain - making the necessary configuration changes in Cloudflare
• I prefer Namecheap for purchasing domain names, but likely any other service provider will do just as well.

Step by step:

• Copy the publish.js and publish.css files to the root folder of your vault.
• In Excalidraw Plugin Settings set up "Auto-export SVG":
• Optionally, after setting up Auto-Export you can also set up the "Type of file to insert into the document" to SVG. Note, SVG will only be avialable as an option, if you first enable Auto-export in the previous step.
• When publishing your site you can use the Excalidraw: Obsidian Publish: Find SVG and PNG exports that are out of date Command Palette action to check that all your image exports are up to date. Images may get out of date if you've changed embedded content or links.

The publish.js and publish.css files are MVP solutions. I welcome responses to this Gist showcasing enhanced versions of these scripts.

Good Luck and Enjoy!

publish.css

@font-face {font-family: "Virgil";src: url("https://excalidraw.com/Virgil.woff2");}
@font-face {font-family: "Cascadia";src: url("https://excalidraw.com/Cascadia.woff2");}
@font-face {font-family: "Assistant";src: url("https://excalidraw.com/Assistant-Regular.woff2");}

div.markdown-embed-title {
  display: none;
}

div.markdown-embed {
  border: none;
  padding: 0px;
  background-color: inherit;
}

div.excalidraw-svg {
	/*width: fit-content;*/
	height: 100%>
}

svg.excalidraw-svg {
	max-width:100%;
	max-height: 90vh;
	width: var(--page-width);
}

svg.excalidraw-svg.ex-pageheight {
	width: initial;
	height: 100%;
}

svg.excalidraw-svg.ex-pagewidth {
	width: 90vw;
	height: initial;
}

.excalidraw-svg .text {
  width: 100%;
  text-align: center;
}

div.excalidraw-svg.enlarged {
    position: fixed;
    top: 0;
    left: 0;
    z-index: 10;
    width: 100%;
    height: 100%;
    display: flex;
    flex-direction: column;
    justify-content: center;
    align-items: center;
}

body {
	--background-primary: #FFF6F0;
}

a.site-body-left-column-site-name {
	display: none;
}

div.site-footer {
	display: none;
}

publish.js

const clickToEnlarge = "Click and hold to enlarge. SHIFT + wheel to zoom. ESC to reset.";
const clickToCollapse = "ESC to reset. Click and hold to collapse. SHIFT + wheel to zoom";

//check if in iFrame - if yes the page is assumed to be an embedded frame
if(window.self !== window.top) {
  const elements = [
    "div.site-body-right-column",
    "div.site-body-left-column",
    "div.site-header",
    "div.site-footer"
  ];
  elements.forEach(x=>{
    document.querySelectorAll(x).forEach(div=>{
      div.style.display = "none";
    });
  });
}

const baseUrl = `${window.location.origin}/`;

const [isDesktop, isMobile, isTablet] = (()=>{
  const userAgent = navigator.userAgent;
  const mobileKeywords = ['Mobile', 'Android', 'iPhone', 'iPad', 'Windows Phone'];

  const isMobile = mobileKeywords.some(keyword => userAgent.includes(keyword));
  const isTablet = /iPad/i.test(userAgent) || (isMobile && !/Mobile/i.test(userAgent));
  const isDesktop = !isMobile && !isTablet;

  return [isDesktop, isMobile, isTablet];
})();

const addNavigationToDiv = (container) => {
  const svgElement = container?.querySelector('.excalidraw-svg');
  if(!svgElement) return;
  container.addClass("excalidraw-svg");
  svgElement.removeAttribute("width");
  svgElement.removeAttribute("height");

  if(!isDesktop) return;

  const textDiv = document.createElement('div');
  textDiv.className = 'text';
  textDiv.textContent = clickToEnlarge;
  container.appendChild(textDiv);

  let isEnlarged = false;
  let timeout = null;
  let isReadyToPan = false;
  let isPanning = false;
  let zoomLevel = 1;
  let panX = 0;
  let panY = 0;
  let pinchStartDistance = 0;
  let panStartX = 0;
  let panStartY = 0;

  const clearEnlargeTimeout = () => {
    if(timeout) clearTimeout(timeout);
    timeout = null;
  }

  const enablePointerEvents = (val) => {
    svgElement.querySelectorAll("a").forEach(el=>{
      el.style.pointerEvents = val ? "all" : "none";
    });
  }

  const applyTransform = () => {
    svgElement.style.transform = `scale(${zoomLevel}) translate(${panX}px, ${panY}px)`;
    clearEnlargeTimeout();
  };

  //Wheel zoom
  svgElement.addEventListener('wheel', (event) => {
    if(!event.shiftKey ) return;
    if (event.deltaY > 0) {
    zoomLevel -= zoomLevel > 4
	  ? (zoomLevel > 6
	    ? (zoomLevel > 10 ? 0.4 : 0.3)
		: 0.2)
	  : 0.1;
    } else {
    zoomLevel += zoomLevel > 4
	  ? (zoomLevel > 6
	    ? (zoomLevel > 10 ? 0.4 : 0.3)
		: 0.2)
	  : 0.1;
    }
    applyTransform();
  });

  // Panning
  svgElement.addEventListener('mousedown', (event) => {
    isReadyToPan = true;
    panStartX = event.clientX;
    panStartY = event.clientY;
  });

  svgElement.addEventListener('mousemove', (event) => {
    const deltaX = event.clientX - panStartX;
    const deltaY = event.clientY - panStartY;
    const distance = Math.sqrt(deltaX**2+deltaY**2);
    if (isReadyToPan && (distance > 20)) {
      if(!isPanning) {
        enablePointerEvents(false);
        isPanning = true;
      }
      panX += deltaX/zoomLevel;
      panY += deltaY/zoomLevel;
      panStartX = event.clientX;
      panStartY = event.clientY;

      applyTransform();
    }
  });

  svgElement.addEventListener('mouseup', () => {
    enablePointerEvents(true);
    isPanning = false;
    isReadyToPan = false;
  });

  svgElement.addEventListener('mouseleave', () => {
    enablePointerEvents(true);
    isPanning = false;
    isReadyToPan = false;
  });

  //abort on Escape
  document.addEventListener('keydown', (event) => {
    if (event.key === 'Escape') {
      enablePointerEvents(true);
      isEnlarged = false;
      isPanning = false;
      isReadyToPan = false;
      container.classList.remove("enlarged");
      textDiv.textContent = clickToEnlarge;
      zoomLevel = 1;
      panX = 0;
      panY = 0;
      applyTransform();
    }
  });


  //Enlarge on long click
  svgElement.addEventListener('mouseup', () => clearEnlargeTimeout());
  svgElement.addEventListener('mousedown', () => {
    timeout = setTimeout(()=> {
      timeout = null;
      if(isPanning) return;
      isReadyToPan = false;
      if (isEnlarged) {
        // Collapse the image
        container.classList.remove("enlarged");
        textDiv.textContent = clickToEnlarge;
      } else {
        // Enlarge the image
        container.addClass("enlarged");
        textDiv.textContent = clickToCollapse;
      }
      isEnlarged = !isEnlarged;
    },1000);
  });

  applyTransform();
}

const processIMG = (img) => {
  const svgURL = img.src;
  const container = img.parentElement;

  fetch(svgURL)
    .then((response) => {
      if (response.ok) {
        return response.text();
      }
      throw new Error('Failed to fetch SVG');
    })
    .then((svgContent) => {
      svgContainer = document.createElement('div');
      svgContainer.innerHTML = svgContent;
      svgContainer.querySelectorAll(`a[href^="obsidian://open?vault="`).forEach(el=>{
        el.setAttribute("href",unescape(el.getAttribute("href").replace(/.*&file=/,baseUrl).replaceAll(" ","+")));
      });
      svgContainer.querySelectorAll(`iframe[src^="obsidian://open?vault="`).forEach(el=>{
        el.setAttribute("src",unescape(el.getAttribute("src").replace(/.*&file=/,baseUrl).replaceAll(" ","+")));
      });
      container.removeChild(img);
      container.appendChild(svgContainer);
      addNavigationToDiv(svgContainer);

    })
    .catch((error) => {
      console.error('Error: ' + error);
    });
}

const addImgMutationObserver = () => {
  const targetElement = document.body;
  const handleImgAddition = (mutationsList, observer) => {
    for (const mutation of mutationsList) {
      if (mutation.type === 'childList') {
    mutation.addedNodes.forEach(node => {
      if (node instanceof Element && node.querySelector(`img[alt$=".svg"]`)) {
        processIMG(node.querySelector(`img[alt$=".svg"]`));
      };
        });
      }
    }
  }
  const observer = new MutationObserver(handleImgAddition);
  const config = { childList: true, subtree: true };
  observer.observe(targetElement, config);
}

//process images after loading
document.body.querySelectorAll(`img[alt$=".svg"`).forEach(img => {
  processIMG(img);
});

addImgMutationObserver();
