Benchmarking

Components

The benchmarking infrastructure is made of these components:

Benchmarks, a web application that contains different scenarios to benchmark.
BenchmarksServer, a web application that queues jobs that are able to run custom web applications to be benchmarked.
BenchmarksClient, a web application that queues jobs that can create custom client loads on a web application.
BenchmarksDriver, a command-line application that can enqueue server and client jobs and displays the results locally.
A database server that can run any or all of PostgreSql, Sql Server, MySql, MongoDb

Setting up the infrastructure

This will assume you have Docker installed and are familiar with it.

Setup the Benchmark Server

Clone https://github.com/aspnet/benchmarks on the dev branch
Run cd docker/benchmarks
Run ./build.sh, which will build a Docker image containing the benchmarking dependencies
Add the following environment variables to the file /etc/environment
- Set the environment variable DBHOST=10.0.0.103 by replacing the IP with the one used to communicate with the database server
- Set the environment variable server_ip=10.0.0.102 by replacing the IP with the one used to communicate with the benchmark server
- Set the environment variable hardware_version=HPZ440 by replacing with a description of the hardware. This will be used when storing the results to distinguish environments
Edit the file /etc/hosts and add 10.0.0.103 TFB-database with the IP to the database server
Run ./run-server.sh

The application should start on port 5001. Open a browser on this page and OK should be displayed.

Setup the Benchmark Client

Clone https://github.com/aspnet/benchmarks on the dev branch
Run cd docker/benchmarks
Run ./build.sh, which will build a Docker image containing the benchmarking dependencies
Then run ./run-client.sh

The application should start on port 5002. Open a browser on this page and OK should be displayed.

Setup the Database Server

Clone https://github.com/aspnet/benchmarks on the dev branch

PostgreSql

Run cd docker/postgres-techempower
Run ./build.sh
Then run ./run.sh

This will create and run a Docker image containing PostgreSql and the Fortunes database that is used by Tech Empower scenarios.

Run a job

On your computer,

Clone https://github.com/aspnet/benchmarks on the dev branch
Run cd src/BenchmarkDriver
Then run the following command after replacing the IP addresses to the ones you are using,

dotnet run -c Debug `
 --server "http://10.0.0.102:5001" `
 --client "http://10.0.0.101:5002" `
 --jobs "../Benchmarks/benchmarks.Json.json" `
 -n Json

This will start the Json scenario using the Benchmarks application that is provided in https://github.com/aspnet/benchmarks/tree/dev/src/Benchmarks. You can use another application by setting the correct arguments described on this page.

Selecting a database provider

Some of the Benchmarks application scenarios require the database to be selected from the driver. By default no database driver will be configured and these scenarios will fail. For instance, running the DbFortunesEF scenario will require the driver to have the --database argument.

A good default is --database PostgreSql which will use NpgSql, but other providers are available. See the command line arguments for the available ones.

Storing the results

The driver application can store the results of a job by passing a -q [connectionstring] argument. The connection string must point to an existing SQL Server database. The first time it's called the required table will be created. From there you can create reports using the tools of your choice.
