00_rl4f_odsc.md

Reinforcement Learning for Finance

Workshop at ODSC London 2024

Dr. Yves J. Hilpisch | The Python Quants | CPF Program

London, 06. September 2024

(short link to this Gist: http://bit.ly/odsc_ldn_2024)

Slides

You find the slides at:

http://certificate.tpq.io/odsc_ldn_2024.pdf

Book

You find an early (pre-print) version of my new book at:

https://certificate.tpq.io/rlfinance.html

The book on O'Reilly:

https://learning.oreilly.com/library/view/reinforcement-learning-for/9781098169169/

Resources

This Gist contains selected resources used during the workshop.

Social Media

https://cpf.tpq.io https://x.com/dyjh https://linkedin.com/in/dyjh/ https://github.com/yhilpisch https://youtube.com/c/yves-hilpisch https://bit.ly/quants_dev

Dislaimer

All the content, Python code, Jupyter Notebooks, and other materials (the “Material”) come without warranties or representations, to the extent permitted by applicable law.

None of the Material represents any kind of recommendation or investment advice.

The Material is only meant as a technical illustration.

(c) Dr. Yves J. Hilpisch

01_rl4f_odsc.ipynb

02_rl4f_odsc.ipynb

03_rl4f_odsc.ipynb

04_rl4f_odsc.ipynb

05_rl4f_odsc.ipynb

dqlagent.py

#
# Deep Q-Learning Agent
#
# (c) Dr. Yves J. Hilpisch
# Reinforcement Learning for Finance
#

import os
import random
import warnings
import numpy as np
import tensorflow as tf
from tensorflow import keras
from collections import deque
from keras.layers import Dense, Flatten
from keras.models import Sequential

warnings.simplefilter('ignore')
os.environ['TF_CPP_MIN_LOG_LEVEL'] = '3'


from tensorflow.python.framework.ops import disable_eager_execution
disable_eager_execution()

opt = keras.optimizers.legacy.Adam


class DQLAgent:
    def __init__(self, symbol, feature, n_features, env, hu=24, lr=0.001):
        self.epsilon = 1.0
        self.epsilon_decay = 0.9975
        self.epsilon_min = 0.1
        self.memory = deque(maxlen=2000)
        self.batch_size = 32
        self.gamma = 0.5
        self.trewards = list()
        self.max_treward = -np.inf
        self.n_features = n_features
        self.env = env
        self.episodes = 0
        self._create_model(hu, lr)

    def _create_model(self, hu, lr):
        self.model = Sequential()
        self.model.add(Dense(hu, activation='relu',
                             input_dim=self.n_features))
        self.model.add(Dense(hu, activation='relu'))
        self.model.add(Dense(2, activation='linear'))
        self.model.compile(loss='mse', optimizer=opt(learning_rate=lr))

    def _reshape(self, state):
        state = state.flatten()
        return np.reshape(state, [1, len(state)])

    def act(self, state):
        if random.random() < self.epsilon:
            return self.env.action_space.sample()
        return np.argmax(self.model.predict(state)[0])

    def replay(self):
        batch = random.sample(self.memory, self.batch_size)
        for state, action, next_state, reward, done in batch:
            if not done:
                reward += self.gamma * np.amax(
                    self.model.predict(next_state)[0])
                target = self.model.predict(state)
                target[0, action] = reward
                self.model.fit(state, target, epochs=1, verbose=False)
        if self.epsilon > self.epsilon_min:
            self.epsilon *= self.epsilon_decay

    def learn(self, episodes):
        for e in range(1, episodes + 1):
            self.episodes += 1
            state, _ = self.env.reset()
            state = self._reshape(state)
            treward = 0
            for f in range(1, 5000):
                self.f = f
                action = self.act(state)
                next_state, reward, done, trunc, _ = self.env.step(action)
                treward += reward
                next_state = self._reshape(next_state)
                self.memory.append(
                    [state, action, next_state, reward, done])
                state = next_state
                if done:
                    self.trewards.append(treward)
                    self.max_treward = max(self.max_treward, treward)
                    templ = f'episode={self.episodes:4d} | '
                    templ += f'treward={treward:7.3f}'
                    templ += f' | max={self.max_treward:7.3f}'
                    print(templ, end='\r')
                    break
            if len(self.memory) > self.batch_size:
                self.replay()
        print()

    def test(self, episodes, min_accuracy=0.0,
             min_performance=0.0, verbose=True,
             full=True):
        ma = self.env.min_accuracy
        self.env.min_accuracy = min_accuracy
        if hasattr(self.env, 'min_performance'):
            mp = self.env.min_performance
            self.env.min_performance = min_performance
            self.performances = list()
        for e in range(1, episodes + 1):
            state, _ = self.env.reset()
            state = self._reshape(state)
            for f in range(1, 5001):
                action = np.argmax(self.model.predict(state)[0])
                state, reward, done, trunc, _ = self.env.step(action)
                state = self._reshape(state)
                if done:
                    templ = f'total reward={f:4d} | '
                    templ += f'accuracy={self.env.accuracy:.3f}'
                    if hasattr(self.env, 'min_performance'):
                        self.performances.append(self.env.performance)
                        templ += f' | performance={self.env.performance:.3f}'
                    if verbose:
                        if full:
                            print(templ)
                        else:
                            print(templ, end='\r')
                    break
        self.env.min_accuracy = ma
        if hasattr(self.env, 'min_performance'):
            self.env.min_performance = mp
        print()
